MORE PAD INDOOR

ELECTRICAL INDOOR

RADIANT HEATING SYSTEM

INSTRUCTION MANUAL

MI3857_01 MORE PAD INDOOR

Table of Contents

Need help?

Do you have a question about the PAD INDOO and is the answer not in the manual?

Questions and answers

Summary of Contents for RBM PAD INDOO

Page 1 MORE PAD INDOOR ELECTRICAL INDOOR RADIANT HEATING SYSTEM INSTRUCTION MANUAL MI3857_01 MORE PAD INDOOR...
Page 2 MORE PAD INDOOR ELECTRICAL INDOOR RADIANT HEATING SYSTEM • Maximum self-adjusted temperature at 30°C. • Suitable for radiant heating of floors, walls and/or ceilings of rooms, also for discontinuous use. • Suitable for heating and defrosting mirrors. • Suitable for radiant heating of wet areas, shower cubicles, caldarium areas with any type of final finish. •...
Page 3: Installation
MORE PAD INDOOR PAD INDOOR “IN BRIEF” • semiconductor technopolymer, modulating and self- FUNCTIONL regulating, with heating by the passage of electric current by PRINCIPLE molecular vibration • Integration of domestic heating systems; • Heating of wet rooms (shower rooms, tepidarium, wellness areas, etc.);...
Page 4: Information And Warnings
MORE PAD INDOOR 2.INFORMATION AND WARNINGS 2.1 IDENTIFICATION OF PICTOGRAMS The symbols below, together with their associated wording, indicate the potential risk arising from failure to comply with the prescription to which they have been combined. Warns that failure to comply with the requirement entails a risk of damage to Warning the equipment constituting the mixing unit.
Page 5 MORE PAD INDOOR 2.3 GENERAL WARNINGS FOR SAFE USE Improper installation can cause damage to people, animals or property. The manufacturer is not liable for damage caused by installation errors, non-compliance Danger with these instructions and improper use of the system and individual devices. Risk of electric shock Also note the following:...
Page 6 MORE PAD INDOOR AD INDOOR is a mat that self-modulates electrical consumption and self-adjusts maximum surface temperature; Absorption and surface temperature depend on the ability of the environment to absorb Warning the energy released by the mat. The lower the starting temperature, the higher the initial absorption (see chapter 7) and the lower the surface temperature reached.
Page 7: General Information
MORE PAD INDOOR 2.4 GENERAL INFORMATION • • PAD INDOOR is a radiant system that can PAD INDOOR is an electric radiant heating system; be combined with very low inertia finishes, • PAD INDOOR consists of a thin mat, with final thicknesses limited to just 15 mm electrically powered at very low voltage, (dry finish with plasterboard wall panel, that self- modulates electrical consumption...
Page 8: General Information For Installation
MORE PAD INDOOR 2.6 GENERAL INFORMATION FOR INSTALLATION • • Read the labels on the packaging to It can also be curved and bent at right check that the product is correct for the angles (between slats) to fit the profile to be installation being carried out;...
Page 9 PAD INDOOR. For any further clarification, the customer can contact the manufacturer’s Technical Sales Support: RBM S.p.A. - Via S.Giuseppe, 1 - 25075 NAVE ( BRESCIA ) - ITALY Tel ++39 030 2537211 - Fax ++39 030 2531799 info@rbm.eu...
Page 10: System Components
The components of the PAD INDOOR system are listed below in this manual. For further accessories that are not strictly related to the PAD INDOOR system, which may be necessary for the installation of underfloor heating systems, refer to the general RBM MORE catalogue. PRODUCT TABLE...
Page 11: Technical Features
MORE PAD INDOOR 4. TECHNICAL FEATURES Semiconductor material Conductor material Copper braid Braid equivalent section Mat specific weight 1,15 Kg/m Width Thickness Roll Lenght 10/30 PAD INDOOR Nominal temperature (at 20°C) 29,8 °C Max temperature (with limited heat exchange with the environment) °C Electrical power supply V DC...
Page 12 MORE PAD INDOOR Electrical power supply 90 ÷ 305 Controllable rated power 601,2 Absorption 16,7 Feeder driver consumption in stand-by Full load efficiency Adjustable output voltage 30,6 ÷ 37,8 Feeder electrical protection IP 65 Type of protection SELV DRIVER Short-circuit protection of power supply 600W Overload protection...
Page 13 Contacts RBM SpA - via S.Giuseppe 1 - NAVE (BS) - ITALIA...
Page 14: Possible Applications
MORE PAD INDOOR 5. CERTIFICATIONS EC declaration of conformity with directives: • EU Regulation 1188/2015 implementing Directive 2009/125/EC (ErP) with regard to ecodesign requirements for space heating appliances. • Restriction of Hazardous Substances (RoHS) Directive 2011/65/EU. • Directive on waste electrical and electronic equipment (WEEE) 2012/19/EU. •...
Page 15: Application Details
MORE PAD INDOOR 6.1 LEGISLATIVE INFORMATION In the case of renovation or energy refurbishment, it is possible to derogate from the minimum internal living space height of 10 cm. This possibility is of fundamental importance when it is necessary to insert a radiant floor or ceiling system inside an existing building.
Page 16: Regulatory Information
MORE PAD INDOOR INTEGRATION AND ELIMINATION OF FOGGING Example of wall heating with bonded mirror fixed with silicone. CALDARIUM AND SHOWER AREAS The PAD INDOOR has a complete ability to adhere to the shapes of seats and false ceilings with the possibility of covering them with any type of finish.
Page 17 MORE PAD INDOOR INDOOR PAD INSTALLATION ( refer to IEC 64-8 PART 7 ) Area where installation is not possible Installation Area with Driver 320 or Free zone installation Electrical characteristics of the PAD INDOOR system Supply voltage 36 VDC Insulation class class III SELV Protection class IPX7 Class III with SELV protection is solely achieved by coupling the Indoor PAD with the 320 or 600 DRIVER.
Page 18 MORE PAD INDOOR 7. DIMENSIONING Power output of the PAD INDOOR mat The nominal nameplate power, corresponding to the power consumption value at 36VDC, is delivered at a temperature between 5 and 10 C, the value at which the building envelope is normally placed in non-heated or frost- free conditions. The chart below shows the self-adjusting capacity of the technopolymer as the contact temperature of the mat changes.
Page 19 MORE PAD INDOOR For dimensioning, proceed in the following logical sequence: • Determine the peak demand, in W, of the room to be heated; • Calculate the development in metres of PAD INDOOR as a function of the W/m yield; increase the development by at least 30% to take into account the share of energy dispersed towards the separation insulation with the building envelope.
Page 20 MORE PAD INDOOR Example: If we were to imagine a wall heating system consisting of 9 strips of PAD INDOOR, each 2 metres long (60 W) and connected to a 600W power supply driver, we could assume the following line combinations: PAD INDOOR power cord length of DRIVER cord section mm2...
Page 21 MORE PAD INDOOR 8. POWER SUPPLY DRIVERS • The PAD INDOOR must be supplied via the system’s power supply DRIVERS; • DRIVER 320, DRIVER 600 and DRIVER 1000 are rectifier transformers with the output line, 36 VDC side,protected against short circuit, overload, overvoltage and overtemperature; •...
Page 22 MORE PAD INDOOR DRIVER 600 It is a watertight version of the equipment to be preferred if: • The location must be in a humid place and/or with the possibility of surface condensation; • The environment in which it is located lacks or has limited ventilation for the correct operation of the equipment (false ceiling, built-in electrical box, etc.);...
Page 23 MORE PAD INDOOR DRIVER 1000 This is an “open” version of the appliance, which is preferable if it can be installed in ventilated rooms, favouring vertical installation to facilitate convective exchange and avoid dust deposits. AC/L IN line power supply AC/N 230 VAC line connection PAD INDOOR connection...
Page 24 MORE PAD INDOOR Warning In order to ensure optimal conditions and a long service life for the power drivers, it is important to: • Install them so that the heat is dissipated effectively; • Do not locate the power supply in a place where the ambient temperature tends to exceed 25°C; •...
Page 25 MORE PAD INDOOR 9. PAD INDOOR SYSTEM INSTALLATION Check the flatness and cleanliness of the insulation required for thermal decoupling between the radiant system and the building envelope. In the case of underfloor installation, a vapour barrier should be laid underneath the insulation layer to protect against rising damp.
Page 26 MORE PAD INDOOR • Remove a small portion of polymer in the corner next to the braid, to make it easier to position the crimp terminal so that it remains in line with the braid of the upright embedded in the polymer.
Page 27 MORE PAD INDOOR • Connect the cables in parallel with each other in the sequence shown in the image opposite. • Alternate the colours of the cables on the strings side by side so that they always have the same colour next to each other (red-black... black-red...
Page 28 MORE PAD INDOOR It is possible to wire several strings of PAD INDOOR in SERIES, whose overall length does not exceed the maximum length of 7 metres solution to be adopted in the event of an excessive voltage drop being detected It is possible to wire several strings of PAD INDOOR in SERIES/PARALLEL, whose overall length does not exceed the maximum length of 7 metres...
Page 29 MORE PAD INDOOR crimping terminal for 2.5 mm2 PAD INDOOR heating element cross- section lanyard with vulca- connection nized bituminous tape signature cable, cross-section 2.5 mm² electrical upright for con- nection to power drivers PARALLEL of several strings of PAD INDOOR, each with a maximum length of 7 metres, is possible junction box for changing the cross- section of the power cable electrical upright for con-...
Page 30 MORE PAD INDOOR Alternatively, with ON-OFF direction from PAD INDOOR RBM MORE SET2 control system. In the case of integration with Pad Indoor, room temperature management comes from the same temperature probe as the radiant system Alternatively, room control from...
Page 31 MORE PAD INDOOR Using the self-amalgamating bitumen tape supplied (series 3861), insulate the copper parts of the cable and the crimp terminal from oxidation. Press well to release the air trapped in the “sandwich” in order to make the bituminous parts adhere to make the contact watertight.
Page 32 MORE PAD INDOOR Valid for floor, wall or ceiling Fasten the strings with metal staples on both sides and at each metre, taking care to lap only the outside of the polymer by 2/3 mm, without touching the braids of the electrical struts. Alternatively, use plastic nails or paper tape about 5 cm long.
Page 33 MORE PAD INDOOR Valid for the wall and/or ceiling Plasterboard finish The string centre distance will depend on the peak thermal power to be delivered; if there are no specific requirements, it is advisable to ensure a longitudinal centre distance of approximately 400 mm (axis-axis), a measurement that matches the majority of metal counter spreader structures (structure present in the case of false ceilings).
Page 34 MORE PAD INDOOR Valid for wall only Temporarily secure mats to the substrate with solvent-free reinforced double-sided tape, such as MAPEI Mapecontact, 240 mm wide. Once the electrical wiring and functional test is complete, finish by laying a 5x5 mm section fibreglass mesh reinforcement for coats, to be fixed with (stainless steel) metal clips or plastic dowels for coats.
Page 35 RBM spa reserves the right to improve and change the products described and relevant technical data at any moment and without prior notice. The information and images contained in this document are intended for information purpo- ses only, are not binding and in any case do not exempt the user from strictly following the regulations in force and good practice standards.
