DN200 Weather Station
Revision B
Installation Manual
(Including 4G and Satellite models)
DN200 Code Version: 3.074 and above
Note: Please use the latest revision number to ensure you have the latest
information. Copies of this manual are available from Rimik and may be
available from the Rimik website.
DN200 Weatherstation Installation Manual Revision B
Page 1
Advertisement
Related Manuals for Rimik DN200
Summary of Contents for Rimik DN200
- Page 1 DN200 Code Version: 3.074 and above Note: Please use the latest revision number to ensure you have the latest information. Copies of this manual are available from Rimik and may be available from the Rimik website. DN200 Weatherstation Installation Manual Revision B...
- Page 2 Any representation, statement, opinion or advice, expressed or implied in this publication is made in good faith and on the basis that Rimik, its agents and employees, are not liable (whether by reason of negligence, lack of care or otherwise) to any person for any damage or loss whatsoever which has occurred or may occur in relation to that person taking or not taking (as the case may be) action in respect of any representation, statement or advice referred to above.
-
Page 3: Table Of Contents
Table of Contents Site Orientation ............................4 Construction Order: ..........................4 DN200 enclosure cabling and wiring ...................... 5 Commissioning: ............................7 DN200 Status LEDs ..........................8 Telemetry Checks specific to 4G and Satellite carriers ..............10 4G ..............................10 Satellite ............................10 Photos .............................. -
Page 4: Site Orientation
Make sure you fit a rubber grommet to the cables once they exit the cross member so that it can be fitted into the pole. Fit the cross member using the galvanised T Clamps provided. You should now be ready to wire the cable into the DN200. DN200 Weatherstation Installation Manual Revision B Page 4... -
Page 5: Dn200 Enclosure Cabling And Wiring
Place the black rubber over the SMA connector and then screw the antenna down until it seals. Move to the DN200 and press on all the modules on the front board to make sure they are firmly seated. Some movement may occur during transport. - Page 6 Satellite system wire this into the white twin terminal on the end of the red and blace solar panel cable. Make sure you wire as follows: BROWN to RED (positive) BLUE to BLACK (negative) DN200 Weatherstation Installation Manual Revision B Page 6...
-
Page 7: Commissioning
Commissioning: Replace the fuses. Turn on the DN200 in the following manner. Switch the power slider to ON (down) then press and hold the Start button for about 2 seconds. Monitor the light activity. You should see a series of flashes then lights will generally remain constant for 1 minute. -
Page 8: Dn200 Status Leds
DN200 Status LEDs The status LEDs on the DN200 fall into two categories, ones that are always active and ones that are only active on-demand. Always active LEDs always reflect the relevant system status. On-demand status LEDs will only reflect the relevant system status at startup or when the START/CHECK button has been pressed. - Page 9 For Swarm Satellite State Meaning On solid The Swarm module is powered on. Flashing Does not operate for Swarm satellite. The Swarm Satellite module is not present, not powered on or is faulty. DN200 Weatherstation Installation Manual Revision B Page 9...
-
Page 10: Telemetry Checks Specific To 4G And Satellite Carriers
If the red LED is still flashing after a few minutes there may be an issue with the GPS antenna and connections. To check the Swarm modem signal strength. DN200 Weatherstation Installation Manual Revision B Page 10... - Page 11 RSSI reading. If it is zero then the modem has not yet heard from any satellites. If the Swarm modem does not appear to be transmitting messages. E.g. no data is received by the Swarm or Rimik servers even after a known satellite pass it may be necessary to check the antenna connections.
-
Page 12: Photos
Photos DN200 Weatherstation Installation Manual Revision B Page 12... - Page 13 DN200 Weatherstation Installation Manual Revision B Page 13...
- Page 14 DN200 Weatherstation Installation Manual Revision B Page 14...
- Page 15 DN200 Weatherstation Installation Manual Revision B Page 15...
- Page 16 DN200 Weatherstation Installation Manual Revision B Page 16...
- Page 17 DN200 Weatherstation Installation Manual Revision B Page 17...
- Page 18 DN200 Weatherstation Installation Manual Revision B Page 18...
- Page 19 DN200 Weatherstation Installation Manual Revision B Page 19...
- Page 20 DN200 Weatherstation Installation Manual Revision B Page 20...
