Model No.
OUTDOOR UNIT
Single Split (Single-phase)
Type PZH2
U-160PZH2R5
Single Split (3-phase)
Type PZH2
U-160PZH2R8
U-180PZH2R8
U-200PZH2R8
U-224PZH2R8
Connectable indoor unit lineup
This booklet is the operating instructions for outdoor unit. Regarding the indoor unit, see the
operating instructions supplied with the indoor unit.
INDOOR UNIT
Ducted
High Static Pressure Ducted
Before operating the unit, read these operating instructions thoroughly and keep them for future reference.
OI_00_310578_en.indb 1
Panasonic Corporation
1006 Kadoma, Kadoma City, Osaka, Japan
Operating Instructions
Air Conditioner
ACXF55-23660
2018/12/19 9:57:11

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the U-160PZH2R5 and is the answer not in the manual?

Questions and answers

Summary of Contents for Panasonic U-160PZH2R5

  • Page 1 Operating Instructions Air Conditioner Model No. OUTDOOR UNIT Single Split (Single-phase) Type PZH2 U-160PZH2R5 Single Split (3-phase) Type PZH2 U-160PZH2R8 U-180PZH2R8 U-200PZH2R8 U-224PZH2R8 Connectable indoor unit lineup ● This booklet is the operating instructions for outdoor unit. Regarding the indoor unit, see the operating instructions supplied with the indoor unit. INDOOR UNIT Ducted High Static Pressure Ducted Before operating the unit, read these operating instructions thoroughly and keep them for future reference. Panasonic Corporation ACXF55-23660 1006 Kadoma, Kadoma City, Osaka, Japan OI_00_310578_en.indb 1 2018/12/19 9:57:11...
