Tenor Call Relay Session Border Controllers

CALL MANAGEMENT FEATURES

• Call Detail Records
• Support for public and private dial plans

TECHNICAL SPECIFICATIONS

Call Relay Specifications

• H.323 v3 compliant
• H.323/SIP signal translation for inter-networking
• SIP RFC3261 compliant endpoint
• Enterprise Call Relay 60 supports up to
16 simultaneous VoIP calls, software upgradeable to 60
• Call Relay SP supports up to 120 simultaneous
VoIP calls, software upgradeable to 672
• VoIP firewall with intelligent NATAccess™ and remote NAT
• PacketSaver™ packet multiplexing*
• Maximum Call Rate:
Call Relay 60: 3,600 calls/hour
Call Relay SP: 18,000 calls/hour
• Local H.323 Gatekeeper Option* supports full gatekeeper
routed call model

GENERAL SPECIFICATIONS

General Specifications
• Operating Temperature: 40° - 104° F (5° - 40° C)
• Operating Humidity: 20% - 80% non-condensing
• EMC: EN55022, FCC Part 15, EN55024, EN61000-2-3,
EN61000-3-3
• Safety: EN60950, UL60950, AS/NZS60950
Enterprise Call Relay 60
• Dimensions:
W 17 " x H 1 " x D 10
3/8 3/4
W 44.5cm x H 4.5cm x D 27.6cm
• Weight: 8.25 lbs. (3.75 kg)
• AC Power: 100-240 Volts AC, 50/60 Hz, 35 Watts
"
3/4
71 James Way, Eatontown, New Jersey 07724
1-877-SPEAK-IP . Tel 732.460.9000 . Fax 732.544.9119
www.Quintum.com

IP Network Specifications

• LAN Interface: 10/100 Mbps autosensing Ethernet
• Standard RJ-45 interface (IEEE 802.3) for 10Base-T
or 100Base-T connections
• QoS Support: IP TOS, DiffServ

Configuration/Management

• Remote Management
• SNMPv2 Agent
• Command Line Interface
• Remote Telnet Access
• Serial Console Port: RS-232/DB-9
• Compatible with external Quintum Call Routing Server*
• Compatible with Quintum Tenor Monitor
High Capacity Call Relay SP
• Dimensions:
W 17 " x H 1 " x D 11
1/2 3/4
W 44.5cm x H 4.5cm x D 30.2cm
• Maximum weight: 11.5 lbs (5.25kg)
• AC Power: 100-240 Volts AC, 50/60 Hz, 175 Watts
• DC Power: -40 - -60 Volts DC, 175 Watts
"
7/8
* Quintum product purchased separately
Rev. 9
