- Page 1 Quintum Technologies, Inc. Risk Free VoIP www.quintum.com...
- Page 2 Introducing The Tenor DX Series Quintum’s New Line Of Digital Products Will Support Up To 120 VoIP Channels and 8 T1/E1/PRI spans. “MultiPath Switch” OR “Gateway” Configurations. Fills The Gap Between The Tenor D Series and The Tenor CMS. Includes the “New” Tenor Configuration Manager •...
- Page 3 New Tenor DX Is Designed For Enterprises and Small Service Providers New higher density platform in the same Tenor footprint Choice of Configurations. MultiPath Switch – Available Ports for PBX & PSTN Connectivity Gateway – Matching VoIP and Trunk ports New features TDM Circuit switching...
- Page 4 Tenor DX Series Is Available With 1, 2, 3 or 4 Pairs of T1/E1/PRI Trunks 2 T1/E1 Ports 4 T1/E1 Ports 6 T1/E1 Ports 8 T1/E1 Ports www.quintum.com...
- Page 5 Tenor DX Series Is Available In A Variety Of Options For Just The Right Fit Configurations 2 Port T1/E1 Switch with 8, 16, 24, 30, 48 or 60 VoIP channels 4 Port T1/E1 Switch with 48, 60, 96 or 120 VoIP channels...
- Page 6 Symmetrical configuration with equal numbers of station side T1/E1 ports and trunk side T1/E1 ports The number of VoIP ports is half the total number of telephony ports Calls can be routed in any direction between any of the ports Easy drop-in installation, no PBX changes required www.quintum.com...
- Page 7 New Tenor DX Series “MultiPath Switch” DX Series VoIP MultiPath Switches T1/E1 DX2008 DX2016 DX2024 DX2030 DX4048 DX4060 DX6120 DX8120 www.quintum.com Options VoIP Application T1/E1 T1/E1 2 x T1 2 x E1 T1/E1 T1/E1...
- Page 8 VoIP Gateway Configuration (Station Side) Configured for station side PTSN to VoIP Network communications The number of VoIP ports is equal to the number of telephony ports Calls can be routed in any direction between any of the ports www.quintum.com...
- Page 9 VoIP Gateway Configuration (Trunk Side) Configured for trunk side PTSN to VoIP Network communications The number of VoIP ports is equal to the number of telephony ports Calls can be routed in any direction between any of the ports www.quintum.com...
- Page 10 New Tenor DX Series “Gateway” Options DX Series VoIP Gateways T1/E1 DX2048 DX2060 DX4096 DX4120 www.quintum.com VoIP Application 2 x T1 2 x E1 4 x T1 4 x E1...
- Page 11 The basic DX2008 is not software upgradeable. It is a fixed configuration that will only support 8 VoIP channels. The DX 2016 is upgradeable to DX2024 or DX2030 The DX 2024 is upgradeable to DX2030 The DX4096 is upgradeable to DX4120 www.quintum.com...
- Page 12 Offers a complete MultiPath solution for easy deployment in large enterprises. Offers the option for additional trunks to support TDM switching for service provides and PSTN backup for local access providers. Offers a cost effective “gateway” option for service providers who do not require switching. www.quintum.com...
- Page 13 Tenor Configuration Manager Makes Tenor Even Easier To Configure Quintum has developed a completely new Graphical User Interface for the new DX Series products. This web-based tool enables the user to set configuration parameters using an intuitive graphical interface. The Tenor Configuration Manager can configure a remote unit anywhere in the IP network from the user’s PC.
- Page 14 The Tenor Configuration Monitor Offers A Easy To Use GUI www.quintum.com...
- Page 15 The Tenor DX Series And Tenor Configuration Manager Are Now Available Tenor DX Available – Now Official Announcement – November The Tenor Configuration Manager will be included with the Tenor DX at no additional charge. www.quintum.com...
