Moonraker WS200 PRO Manual

Professional weather station
Hide thumbs

Advertisement

Table of Contents

About this manual
Thank you and congratulations on selecting this professional weather station! We are positive you will
enjoy the benefits of accurate weather readings and the precise radio controlled time information that
our instruments offer.
This manual will guide you step-by-step through setting up your device. Use this manual to become
familiar with your professional weather station, and save it for future reference.
Safety
Do not expose the main unit to rain or moisture
Use only recommended batteries
Remove the batteries if the weather station is not to be used for a long time. Old batteries can begin
to leak and damage the product.
Remember to insert the batteries according to the markings in the battery compartment. The wrong
polarity (+/-) can damage the weather station.
Damage that has occurred by careless handling is not covered by the guarantee
Production Description.
Display of indoor and outdoor temperature, wind speed, wind direction, humidity, rainfall amounts,
time and date
Alarm function for certain weather conditions as well as records of all minimum and maximum
values along with time and date of their recordings
Radio control time and date (DCF/WWVB/MSF version optional
Save the data when batteries is changed
Operates on 5x LR6/AA alkaline batteries (not included)
Contents
Main unit
Transmitter(thermo-hydro sensor)
Rain collector
Sensor for wind speed and wind direction
Sensor bracket
Adjustable hoops
Transmitter (thermo-hydro sensor) inside a radiation shield
Rain collector
Sensor for wind speed
Sensor for wind direction
Sensor bracket
Bubble level
Solar panel
PROFESSIONAL WEATHER STATION
Model no: WS200 PRO
- 1 -
)
but only one
 

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WS200 PRO and is the answer not in the manual?

Questions and answers

Summary of Contents for Moonraker WS200 PRO

  • Page 1 PROFESSIONAL WEATHER STATION Model no: WS200 PRO About this manual Thank you and congratulations on selecting this professional weather station! We are positive you will enjoy the benefits of accurate weather readings and the precise radio controlled time information that our instruments offer.

  • Page 2: Lcd Display

    LCD Display The following illustration shows the full segments of the LCD for description purpose only and will not appear like this during normal operation and use. 1. Time alarm on icon 15. Indoor humidity 2. DST icon (only available on WWVB version) 16.
  • Page 3 Transmitter/outdoor unit 1. Turn the screwdriver counter clockwise to loosen the screw, turn aside the sheet metal (Figure 1) 2. Pull out the battery compartment (Figure 2) 3. Insert 2xAA rechargeable battery in the battery compartment. (Figure 3) Push the battery compartment into the rain collector unit.
  • Page 4 Figure 7 Insert 2xLR6 (AA size) batteries into the transmitter, the LED located in the back of rain collector will be turned on for 4 seconds, then it will be off and start to work normally. The transmitter will make a data transmission and then start radio controlled time reception routine.
  • Page 5 distance of up to 330 feet providing that there are no interfering obstacles such as buildings, trees, vehicles, high voltage lines, etc. Radio interferences such as PC screens, radios or TV sets can, in bad cases, entirely cut off radio communication.

  • Page 6: Program Mode

    Program Mode The base station has five keys for easy operation: SET key, + key, HISTORY key, ALARM key, MIN/MAX key Note: When setting certain units in the manual setting mode, hold the + or MIN/MAX key for 2s will increase/decrease digits in greater steps.

  • Page 7: Humidity Calibration

     Wind Speed Calibration (default is 1.0, adjustment rang 0.75 to 1.25)  Rainfall data Calibration (default is 1.0, adjustment rang 0.75 to 1.25)  History rainfall Calibration  Outdoor humidity Calibration  Outdoor temperature Calibration  Indoor humidity Calibration ...

  • Page 8: Alarm Modes

    develop an average for how far off the readings are. Do not compare rainfall readings to reading obtained from television, radio, newspapers, or neighbors’ readings. Such readings are not located in your specific environment and therefore are not an accurate measurement of the weather readings taking place in your surroundings.

  • Page 9: Min/Max Mode

    Indoor temperature low alarm ( -9.9˚C--60˚C) - In the alarm modes, press + key or MIN/MAX key to change or scroll the alarm value. Hold the + key or MIN/MAX key for 2 second will increase/decrease digits in great steps. Press the ALARM key to select the alarm on or off (if alarm is enabled, the speaker icon on the LCD will be turned on indicating the alarm function has been enabled).

  • Page 10: Specifications

    Specifications Outdoor data Transmission distance in open field : 100m(300 feet) Frequency 433MHz Temperature range -40˚C--65˚C (-40℉ to +149℉) Accuracy + / - 1 °C Resolution 0.1˚C Measuring range rel. humidity 1%～99% Accuracy +/- 5% Rain volume display 0 – 9999mm (show --- if outside range) Accuracy + / - 10% Resolution...
  • Page 11 Appendix How to replace the sensor Replace Rain collector and thermo-hydro sensor    - 11 -...
  • Page 12   - 12 -...
  • Page 13 Replace wind sensor  Before replace the wind sensor, need to unplug the cable from rain sensor as illustration - 13 -...
