EN ORIGINAL INSTRUCTIONS
IMPORTANT - These instructions are for your safety.
Please read through them thoroughly prior to handling
the product and retain them for future reference.
V10323_5063022106056_MAND1_2223
5063022106056_MNL_IN_V03.indd 1
5063022106056_MNL_IN_V03.indd 1
4
5
XX/XX/23
XX/XX/23
Impala Ref: PRJ27459
NAME
NAME
EAN: 5063022106056
Page Size: A5
KNG: KNG-2208-0006
EN 18V Cordless Shear
& Shrub Cutter
MSC18-Li
5063022106056
5063022106414
TTSC18-Li
5063022106407
5063022113931
30-03-2023 23:46:42
30-03-2023 23:46:42
Advertisement
Table of Contents
Related Manuals for Kingfisher MSC18-Li
Summary of Contents for Kingfisher MSC18-Li
- Page 1 Impala Ref: PRJ27459 Mohit NAME NAME KNG: KNG-2208-0006 EN 18V Cordless Shear & Shrub Cutter MSC18-Li 5063022106056 5063022106414 EN ORIGINAL INSTRUCTIONS IMPORTANT - These instructions are for your safety. Please read through them thoroughly prior to handling TTSC18-Li the product and retain them for future reference.
- Page 2 EN Parts 01. x1 02. x1 03. x1 04. x1 05. x1 EN You will need EN Contents Product description Safety Technical specification Before you start Functions & Settings Operation Care and maintenance Guarantee Declaration of conformity 5063022106056_MNL_IN_V03.indd 2 5063022106056_MNL_IN_V03.indd 2 30-03-2023 23:46:43 30-03-2023 23:46:43...
- Page 3 EN Product description 1. Grass shear blade 8. Hedge trimmer blade a. Release button (x2) a. Release button (x2) b. Locating pin* (x2) b. Locating pin (x2) 2. Motor unit 9. Grass shear blade cover a. Spindle* 10. Hedge trimmer blade cover b.
-
Page 4: Save All Warnings And Instructions For Future Reference
EN Safety General power tool safety warnings WARNING! Read all safety warnings, instructions, illustrations and specifications provided with this power tool. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. -
Page 5: Personal Safety
c) Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the risk of electric shock. d) Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool. Keep cord away from heat, oil, sharp edges or moving parts. - Page 6 g) If devices are provided for the connection of dust extraction and collection facilities, ensure these are connected and properly used. Use of dust collection can reduce dust-related hazards. h) Do not let familiarity gained from frequent use of tools allow you to become complacent and ignore tool safety principles.
- Page 7 g) Use the power tool, accessories and tool bits etc. in accordance with these instructions, taking into account the working conditions and the work to be performed. Use of the power tool for operations different from those intended could result in a hazardous situation. h) Keep handles and grasping surfaces dry, clean and free from oil and grease.
-
Page 8: Hedge Trimmer Safety Warnings
g) Follow all charging instructions and do not charge the battery pack or tool outside the temperature range specified in the instructions. Charging improperly or at temperatures outside the specified range may damage the battery and increase the risk of fire. Service a) Have your power tools serviced by a qualified repair person using only identical replacement parts. - Page 9 e) Hold the hedge trimmer by insulated gripping surfaces only, because the blade may contact hidden wiring. Blades contacting a “live” wire may make exposed metal parts of the hedge trimmer “live” and could give the operator an electric shock. Keep all power cords and cables away from cutting area.
- Page 10 g) Carry the grass shear by the handle with the blade stopped and taking care not to operate the power switch. Proper carrying of the grass shear will decrease the risk of inadvertent starting and resultant personal injury from the blades. h) When transporting or storing the grass shear, always use the blade cover.
-
Page 11: Vibration And Noise Reduction
Vibration and noise reduction To reduce the impact of noise and vibration emission, limit the time of operation, use low-vibration and low-noise operating modes as well as wear personal protective equipment. Take the following points into account to minimise the vibration and noise exposure risks: 1. -
Page 12: Residual Risks
Residual risks Even if you are operating this product in accordance with all the safety requirements, potential risks of injury and damage remain. The following dangers can arise in connection with the structure and design of this product: 1. Health defects resulting from vibration emission if the product is being used over long periods of time or not adequately managed and properly maintained. - Page 13 Read the instruction manual. Note / Remark. Caution / Warning. Manufacturing date code; year of manufacturing (20xx) and week of manufacturing xxWyy (Wyy). Wear hearing protection. Wear eye protection. Wear a dust mask. Wear protective gloves. Wear protective, slip-resistant footwear. Wear tight-fitted protective clothes.
- Page 14 The product complies with the applicable European directives and an evaluation method of conformity for these directives was done. UK Conformity Assessed. Rating label explanation Cordless Shear & Shrub Cutter: MSC18-Li / TTSC18-Li M = Brand name (MAC Allister) TT = Brand name (TITAN) SC = Shrub Cutter...
- Page 15 EN Technical specifications General : > Rated voltage : 18V > Rated no load speed n : 1300 min > Protection class : III > Degree of protection : IPX0 > Weight : approx. 2.2 kg Grass shear blade : >...
- Page 16 > Measured sound power level L : 86.03 dB(A) > Uncertainty K : 3 dB(A) Sound values as hedge trimmer : > Sound pressure level L : 77.29 dB(A) > Uncertainty K : 3 dB(A) > Measured sound power level L : 86.2 dB(A) >...
- Page 17 You will need (items not supplied) (items supplied) Suitable personal protective equipment Grass shear blade (1) Lubricant for blade Hedge trimmer blade (8) Grass shear blade cover (9) Hedge trimmer blade cover (10) Battery pack (11) Charger (12) and its manual NOTE: The accessories required depend on the intended application.
- Page 18 Inserting the blade 1. Align and insert the two locating pins (1b / 8b) to the two slot of motor unit (2) (Fig. 2, step 1). 2. Make sure that the form (2b) is in place and not damaged. 3. Press both release buttons (1a / 8a) and hold them in position (Fig. 2, step 2), then push the blade (1 / 8) onto the motor unit (2) until it engages with an audible click (Fig.
-
Page 19: Battery Pack
NOTE: Always attach the blade cover (9 / 10) when the product is not in use, for storage and transportation. To attach the blade cover (9 / 10), align and insert the blade cover (9 / 10) onto the blade (1 / 8). Battery pack Attaching / releasing the battery pack 1. -
Page 20: Intended Use
EN Functions & Settings Intended use This cordless grass shear & shrub cutter MSC18-Li / TTSC18-Li is designated with a rated voltage of 18 V . It is designed only to be used with the battery pack which is listed in the chapter of “Technical specifications”. -
Page 21: General Operation
EN Operation General operation 1. Check the product, its battery pack and charger as well as accessories for damage before each use. Do not use the product if it is damaged or shows wear. Take care of any problem you find or have the product checked by qualified specialist. -
Page 22: After Use
NOTE: When shaping it is advisable to achieve a trapezoidal shape (Fig. 8). A trapezoidal cut corresponds to the natural growth of plants and results in optimal hedge growth, as it will expose more light to the lower end of the hedge. Fig. -
Page 23: General Cleaning
EN Care and maintenance The golden rules for care WARNING! Always switch the product off, remove the battery pack (11) and let the product cool down before performing inspection, maintenance and cleaning work! 1. Keep the product clean. Remove debris from it after each use and before storage. 2. -
Page 24: Troubleshooting
3. Cleaning and lubricating the blade (1 / 8), then attach the blade cover (9 / 10) onto the blade (1 / 8). 4. Store the product and its accessories in a dark, dry, frost-free, well-ventilated place. 5. Always store the product in a place that is inaccessible to children. The ideal storage temperature is between 10 °C and 30 °C. -
Page 25: Recycling And Disposal
Recycling and disposal Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist. Check with your Local Authority or local store for recycling advice. For further information visit www.recycle-more.co.uk. The product comes in a package that protects it against damage during shipping. Keep the package until you are sure that all parts have been delivered and the product is working properly. - Page 26 EN Guarantee We take special care to select high quality materials and use manufacturing techniques that allow us to create products incorporating design and durability. This product has a manufacturer’s guarantee of 2 years against manufacturing defects, from the date of purchase (if bought in store) or date of delivery (if bought online), at no additional cost for normal (non-professional or commercial) household use.
- Page 27 A better way to repair your tools Kingfisher takes special care in creating high-quality garden power tools that are designed to last. But if a fault develops with your garden power tool and you need to claim under the guarantee, the Customer Care and Technical Helpline can support with technical assistance or if required, arrange a free courier collection from your home, assess your garden power tool for fault, repair it, and return it.
- Page 28 Manufacturer: EN www.diy.com www.screwfix.com UK Manufacturer: www.screwfix.ie Kingfisher International Products Limited, To view instruction manuals online, 1 Paddington Square, London, W2 1GG, visit www.kingfisher.com/products United Kingdom EU Manufacturer: Kingfisher International Products B.V. Rapenburgerstraat 175E 1011 VM Amsterdam The Netherlands 5063022106056_MNL_IN_V03.indd 28 5063022106056_MNL_IN_V03.indd 28...
