Standard control cable length is 15 feet.
Longer available for order if required.
We discourage splicing or trying to make your
own longer cable.
Sensor cable is standard 15'. No option. No
need for longer as specified location is close
to heater.
Note: If using outdoors, you may require a WiFi range extender to obtain signal.
COMBI ELITE TROUBLESHOOTING
(prepared by Saunafin)
Control & Elite sensor cable can also
be connected to any of 6, 7, 8, 9
240v Supply wire
Confirm 3X copper
connectors installed
For use only if you
want to use sauna
control to operate your
light (not dimmable).
Requires separate 120v
supply. (Do NOT take
120v from main 240v
supply.)
Advertisement
Related Manuals for Tylo Combi 7
Summary of Contents for Tylo Combi 7
- Page 1 COMBI ELITE TROUBLESHOOTING (prepared by Saunafin) Control & Elite sensor cable can also be connected to any of 6, 7, 8, 9 240v Supply wire For use only if you want to use sauna control to operate your Confirm 3X copper Standard control cable length is 15 feet.
- Page 2 Temperature Sensor Location Sensor location is very specific and very important for proper function of the sauna heater. Sensor must be 3” to the front or open side of heater (not in corner), 1” down from ceiling. Humidity + Temperature Sensor Installation (Combi Elite Only) Sensor cable wires are very small.
-
Page 3: Maintenance
Annually Combi water reservoir should be descaled at least once a year using “Tylo De-Scaler” (see full manual). Clean water level probe using a cloth (see full manual). Check stone compartment. Remove all stones. Remove all small stones, gravel and lime-scale from rock compartment. - Page 4 Error codes Should an error occur in a device or associated equipment (control panel, temperature sensor, etc.) an error message will be displayed (see Error list). The following error codes are used: No. Error Comments/Troubleshooting Temperature sensor in the Is the sensor at the input intact/interrupted? Is it indica- room not connected or faulty.
- Page 5 Error codes (continued) No. Error Comments/Troubleshooting Contact with the add-on board Check the RJ45 cable between the circuit board and the has been lost. add-on board. Is the green LED lit on the add-on board? Try to start ON operation again to try and restore the contact.
- Page 6 Troubleshooting the sauna heater Information! Contact the dealer during the guarantee period in the event of faults. See the instructions for the control panel for details of faults not covered in this user guide. Table 1: Troubleshooting the sauna heater Symptom Possible cause Remedy...
