PD156 PRO Precautions 1. Please read this manual carefully before using, and keep it well for future reference. 2. Before cleaning the pen display please unplug the power cord and wipe with a soft damp cloth, do not use any kind of detergents.
1. Product Overview 1.1 Product Introduction Thanks for buying GAOMON PD156 PRO Pen Display. This is a new generation of professional battery- free pen display, which can greatly improve your work efficiency of painting and creation, and full of fun. You can freely painting and writing, depicting different lines and colors, just as the pen writes on the paper, which brings you a real shock experience.
Page 5
PD156 PRO 1.2.2 Digital Pen The digital pen is battery-free and boasts 8192 levels of pressure sensitivity. Upper button : Right mouse key function(default) Lower button : Eraser function(default) Pen nib : Left mouse key function 1.2.3 Accessories Replacement Nibs...
Page 6
PD156 PRO 1.2.4 Power Adapter Please select the appropriate plug according to your country or region, and assemble it to the power adapter (the plug that comes with the product will be different depends on countries and regions). UK Standard...
PD156 PRO 1.3 Display Connection Setting up Display 1. Open up the stand, and then put the display on the stand. 2. Connect the display to your computer with 3-in-1 cable. 3. Connect the power adapter to the power cable.
PD156 PRO 1.4 Driver Installation 1.4.1 OS Support Windows 7 or later, macOS 10.12 or later. 1.4.2 Install Driver Please download the driver from our website: www.gaomon.net/download After finishing installation, you can find the grey driver icon in the system tray area, which means the driver was installed successfully;...
PD156 PRO 1.5 Pen Nib Replacement 1. The nib will wear off after using for a long time, then you need to replace a new nib. 2. Unscrew the pen holder and take out a new nib. 3. Insert the old pen nib into the hole at the bottom of the pen holder and tilt the pen to pull out the nib.
PD156 PRO 2. OSD Setting ⑤ ④ ③ ② ① Enter OSD Menu: 1. Press ① “Function Button” around three seconds until the OSD menu appears and meanwhile the indicator will be on. The function of the Keys ②③④⑤ will become OSD function.
PD156 PRO 3. Function Settings 3.1 Device Connection Prompt 1. No Device Detected : The computer does not recognize the pen display. 2. Device connected : The computer has recognized the pen display. www.gaomon.net...
PD156 PRO 3.2 Working Area Setting 3.2.1 Using Multiple Monitors The location of cursor depends on the screen mode you chose when connected the pen display to an external display (such as laptop or all-in-one PC), for instance: In Duplicate Mode, the pen display and the external display will show the same picture, and the cursor will be displayed on each monitor simultaneously.
Page 13
PD156 PRO 3.2.2 Working Area Setting Define the tablet area that will be mapped to the screen area. 1. Full Area : the entire active area of the tablet. This is the default setting. 2. Custom Area : Drag the corners of the foreground graphic to select the screen area.
Page 14
PD156 PRO 3.2.3 Rotate Working Area By changing the direction of the pen display to provide more choices for users. Four directions are available. 3.2.4 Shortcuts Keys Function Setting Default Setting : Place the cursor on the shortcut key or click the express key to find the default values.
PD156 PRO 3.3 Pen Buttons Function Setting Customized Setting : Select the function to be achieved on the pop-up dialog box, and it will be saved automatically. www.gaomon.net...
PD156 PRO 3.4 Pressure Sensitivity Setting The pressure sensitivity will be changed by dragging the points of the pressure curve. Drag the points to the upper left for higher sensitivity. Drag the points to the lower right for lower sensitivity.
PD156 PRO 3.6 Calibration Screen Calibration : Click the red cross on the screen to complete calibration. Factory Reset : Click ‘Factory Reset’ to reset the pen display. Cancel Calibration : Click ‘Cancel Calibration’ or press ‘ESC’ to stop the calibration.
PD156 PRO 3.7 Enable the Windows Ink Feature The function is for software that supports Windows Ink, such as Microsoft Office, Windows Journal, Adobe Photoshop CC, SketchBook 6 and so on. www.gaomon.net...
PD156 PRO 3.8 Mouse Mode As shown below, check the checkbox in front of the mouse mode to open the mouse mode. Under mouse mode, when you move the pen, the cursor moves following the relative coordinate principle, similar to moving the cursor with the mouse. This means you can click icons or select options at the edge of the screen without moving the pen to the edge of the working area.
PD156 PRO 3.9 Customize Shortcut Keys and Pressure Curve You can customize the function of shortcut keys and pressure curve for different program. Select a program, customize the function of shortcut keys, and adjust the pressure curve, the settings will be automatically saved.
PD156 PRO 3.10 Data Export and Import The driver supports exporting and importing your custom configuration data of the product, which is convenient for you to use different software and avoid the trouble of repeated settings. www.gaomon.net...
PD156 PRO 4. Specifications Model PD156 PRO Panel Size 15.6inch Resolution 1920 x 1080(16 : 9 ) LCD Type Active Area 344.16 × 193.59mm Contrast Ratio 1000 :1 Screen Brightness 220cd/m Response Time 25ms 89° / 89°(H) / 89° / 89°(V) Viewing Angle (Typ.)(CR>10)
Mac OS: System Preference---Displays--- Arrangement--- Check "Mirror Displays" 3. If you decide to use in Extended mode. Make sure to choose pen display as Work Area in GAOMON Driver. It is usually ''Display 2''. Images are blurred Please set the display resolution with 1920 x 1080.
10 mm There is a deviation between the Try calibration tip and the cursor GAOMON driver indicates ''device connected'', but the pen doesn’t respond in Mac OS 10.14 or above versions. Find answer here: https://www.gaomon.net/question/macos_mojave_catalina_solution.html...
PD156 PRO 6. Contact Us for After-sales Service GUANGZHOU GAOMON ELECTRONIC TECHNOLOGY CO., LTD. www.facebook.com/Gaomonpentablet twitter.com/Gaomonpentablet service@gaomon.net https://www.gaomon.net www.gaomon.net...
Page 28
Pen Display PD156 PRO User Manual Windows 7 or later, macOS 10.12 or later...
Page 29
PD156 PRO Précautions 1. Lisez attentivement ce manuel avant utilisation et conserver le pour toute référence ultérieure. 2. Avant de nettoyer la tablette graphique avec écran, veuillez débrancher le cordon d'alimentation et l'essuyer avec un chiffon doux et humide, n'utilisez aucun type de détergent.
Page 30
PD156 PRO Contenu ............................. 106 Précautions 1. Vue d'ensemble du produit ....................108 ..........................1.1 Introduction au produit ..........................1.2 Produits et accessoires ..........................1.3 Connexions d’affichage ............................ 1.4 Installation du pilote ..................... 1.5 Remplacement de la pointe du stylo 2. Réglages OSD ....................
1. Aperçu du produit 1.1 Introduction du produit Merci d'avoir acheté la tablette graphique avec écran GAOMON PD156 PRO, c'est une nouvelle génération de tablettes graphiques professionnelles sans pile, qui peut grandement améliorer l'efficacité de votre travail de peinture et de création, et vous apporter du plaisir. Vous pouvez peindre et écrire librement, en représentant différentes lignes et couleurs, tout comme le stylo écrit sur le...
Page 32
PD156 PRO 1.2.2 Stylo numérique Le stylo numérique fonctionne sans pile et offre 8192 niveaux de sensibilité à la pression. Bouton supérieur : Fonction de la touche droite de la souris (par défaut) Bouton inférieur : Fonction de gomme (par défaut)
Page 33
PD156 PRO 1.2.4 Adaptateur Veuillez sélectionner la prise qui convient en fonction de votre pays ou de votre région, et la connecter à l'adaptateur (la prise fournie avec le produit sera différente en fonction des pays et les régions). Norme britannique Norme européenne...
PD156 PRO 1.3 Connexions d'Affichage Configuration de l'écran 1. Ouvrez le support, puis posez l'écran sur le support. 2. Connectez l'écran à votre ordinateur avec le câble 3-en-1. 3. Branchez l'adaptateur à la prise secteur. 4. Appuyez sur le bouton d'alimentation pour allumer l'écran.
PD156 PRO 1.4 Installation du pilote 1.4.1 Support OS Windows 7 ou plus récent et macOS 10.12 ou plus récent. 1.4.2 Installation du pilote Veuillez télécharger le pilote sur notre site web: www.gaomon.net/download Lorsque l'installation sera terminée, vous trouverez l'icône grise du pilote dans la zone d'état...
PD156 PRO 1.5 Remplacement de la pointe 1. La pointe s'use après été utilisée longtemps, il faut alors la remplacer par une nouvelle. 2. Dévissez le porte-stylo et sortez une nouvelle pointe. 3. Insérez l'ancienne pointe dans le trou situé au bas du stylo et inclinez le stylo pour retirer la pointe.
PD156 PRO 2. Réglages OSD ⑤ ④ ③ ② ① Entrez dans le menu OSD: 1. Appuyez pendant trois secondes, le fonction du bouton ci-dessous deviendra une fonction OSD. 2. A cette époque, la fonction de deviendra comme suit: AUTO : Avant enter dans le menu, il est fonction de réglage automatique.
PD156 PRO 3. Réglages des fonctions 3.1 Invite de connexion de l'appareil 1. Aucun appareil détecte : l'ordinateur ne reconnaît pas la tablette graphique avec écran. 2. Dispositif connecté : l'ordinateur a reconnu la tablette graphique avec écran. www.gaomon.net...
Page 39
PD156 PRO 3.2 Réglage de la zone de travail 3.2.1 Utilisation de plusieurs moniteurs La position du curseur dépend du mode d'écran que vous avez défini lorsque vous avez connecté la tablette graphique avec écran à un écran externe (comme à un ordinateur portable ou un PC), par exemple : En mode dupliquer, la tablette graphique avec écran et l'écran externe afficheront la même image, et...
Page 40
PD156 PRO 3.2.2 Réglage de la zone de travail Définir la zone de tablette qui sera considérée comme étant la zone d'écran. 1. Zone pleine : Toute la zone active de la tablette. C'est le réglage par défaut. 2. Zone personnalisée : Faire glisser les coins au premier plan pour sélectionner la zone de l'écran.
Page 41
PD156 PRO 3.2.3 Rotation de la zone de travail En changeant la direction de la tablette graphique avec écran pour offrir plus de choix aux utilisateurs. Quatre directions sont disponibles. 3.2.4 Réglage des fonctions des touches de raccourcis Paramètre par défaut : Placez le curseur sur la touche de raccourci ou cliquez sur la touche sensitive pour définir les valeurs par défaut.
PD156 PRO 3.3 Réglage de la fonction des boutons du stylo Paramètre personnalisé : Sélectionnez la fonction à appliquer en utilisant la boîte de dialogue contextuelle, et elle sera sauvegardée automatiquement. www.gaomon.net...
PD156 PRO 3.4 Réglage de la sensibilité à la pression La sensibilité à la pression sera modifiée en tirant les points de la courbe de pression. Tirez les points vers le haut à gauche pour une sensibilité plus élevée. Tirez les points vers le bas à droite pour une sensibilité plus faible.
PD156 PRO 3.5 Test de pression du stylo Vous pouvez appliquer une pression progressive sur le stylo à l'écran afin de tester le niveau de pression. www.gaomon.net...
PD156 PRO 3.6 Calibration Calibration de l'écran : Cliquez sur la croix rouge à l'écran pour terminer la calibration. Réinitialisation des paramètres usine : Cliquez sur "Réinitialisation usine" pour réinitialiser la tablette graphique avec écran. Annulez la calibration : Cliquez sur "Annuler la calibration" ou appuyez sur "ESC" pour arrêter la calibration.
Page 47
PD156 PRO 3.7 Activer la fonction Windows Ink Cette fonction est pour les logiciels qui prennent en charge Windows Ink, tels que Microsoft Office, Windows Journal, Adobe Photoshop CC, SketchBook 6, etc. www.gaomon.net...
PD156 PRO 3.8 Mode souris Comme indiqué ci-dessous, cochez la case en face du mode souris pour activer le mode souris. En mode souris, lorsque vous déplacez le stylet, le curseur se déplace sen suivant les coordonnées relatives, de la même façon que vous déplacez le curseur en utilisant la souris.
PD156 PRO 3.9 Personnalisation des touches et de la courbe de pression Vous pouvez personnaliser la fonction des touches et la courbe de pression pour différents programmes. Sélectionnez un programme, personnalisez la fonction des touches et ajustez la courbe de pression, les réglages seront automatiquement enregistrés.
PD156 PRO 3.10 Exportation et importation de données Le pilote prend en charge l’exportation et l’importation de vos données de configurations personnalisées du produit, ce qui vous permet d’utiliser différents logiciels et d’éviter ainsi les problèmes liés aux réglages répétés.
Page 51
PD156 PRO 4. Spécifications Modèle PD156 PRO Taille du paneau 15,6 pouces Résolution 1920 × 1080(16 : 9 ) Type LCD Zone active 344 , 16 × 193,59 Ratio de contraste 1,000: 1 Écran Luminosité 220cd / m Temps de réponse 25ms 89°...
3. Si vous décidez d'utiliser le mode étendu. Assurez-vous de choisir la tablette à stylo numérique comme zone de travail dans le pilote GAOMON. Il s'agit généralement de «Display 2». Les images sont floues Veuillez régler la résolution d'affichage en 1920 x 1080.
Il y a un décalage entre la pointe et Essayez de calibrer le curseur Le pilote GAOMON indique « dispositif connecté », mais le stylo ne répond pas sous Mac OS 10.14 ou versions supérieures. Trouvez la réponse ici : https://www.gaomon.net/question/macos_mojave_catalina_solution.html...
Page 56
PD156 PRO Voorzorgsmaatregelen 1. Lees deze handleiding voor gebruik zorgvuldig door en bewaar ze goed voor toekomstig gebruik. 2. Trek de stekker uit het stopcontact voordat u het pen display reinigt en veeg het af met een zachte, vochtige doek, gebruik geen reinigingsmiddelen.
Page 58
1. Productoverzicht 1.1 Product Inleiding Bedankt voor het aankopen van de GAOMON PD156 PRO pen display. Dit is een nieuwe generatie professionele batterijloze pen displays, die uw werkefficiëntie van schilderen en creatie aanzienlijk kan verbeteren, en vol plezier. Je kunt vrij schilderen en schrijven, waarbij u verschillende lijnen en kleuren weergeeft, net zoals de pen op het papier schrijft, wat u een echte schokervaring bezorgt.
Page 59
PD156 PRO 1.2.2 Digitale pen De digitale pen is batterijloos en heeft een drukgevoeligheid van 8192 niveaus. Bovenste knop : functie rechter muistoets (standaard) Onderste knop : Eraser functie (standaard) Penpunt : Functie linker muistoets 1.2.5 Accessiores Vervangende penpunten Digitale Pen...
Page 60
PD156 PRO 1.2.4 Voedingsadapter Selecteer de juiste stekker voor uw land of regio en monteer deze op de voedingsadapter (de stekker die bij het product wordt geleverd, verschilt per land en regio). VK-standaard EU-standaard VS-standaard AU-standaard Monteren Demonteren www.gaomon.net...
Page 61
PD156 PRO 1.3 Het scherm aansluiten Het scherm instellen 1. Open de standaard, en plaats vervolgens het scherm op de standaard. 2. Sluit het scherm aan op uw computer met de 3-in-1 kabel. 3. Sluit de voedingsadapter aan op voedingskabel.
Page 62
PD156 PRO 1.4 Driver Installatie 1.4.1 OS-ondersteuning Windows 7 of hoger,macOS 10.12 of hoge. 1.4.2 Driver installeren Download de driver van onze website: www.gaomon.net/download Nadat de installatie is voltooid, kunt u het grijze pictogram van het stuurprogramma in het systeemvak vinden, wat betekent dat het stuurprogramma met succes is geïnstalleerd; wanneer...
Page 63
PD156 PRO 1.5 Penpunt Vervanging 1. De punt zal na langdurig gebruik verslijten, dan moet u hem door een nieuwe punt vervangen. 2. Schroef de penhouder los en neem er een nieuwe punt uit. 3. Steek de oude penpunt in het gat aan de onderkant van de penhouder en kantel de pen om de penpunt eruit te trekken.
Page 64
PD156 PRO ⑤ ④ ③ ② ① Het OSD Menu openen: 1. Houd de “Functieknop” ongeveer drie seconden ingedrukt totdat het OSD menu verschijnt en ondertussen zal het indicatielampje gaan branden. De functie van de toetsen worden de OSD functie.
Page 65
PD156 PRO 3. Functie-instellings 3.1 Apparaatverbinding Prompt 1. Geen apparaat gevonden : De computer herkent de tablet niet. 2. Apparaat verbonden : De computer heeft het pen display herkent. www.gaomon.net...
Page 66
PD156 PRO 3.2 Werkgebied Instelling 3.2.1 Instelling Werkgebied De locatie van de cursor is afhankelijk van de schermmodus die u hebt gekozen toen u het pen display op een extern display (zoals een laptop of all-in-one pc) hebt verbonden, bijvoorbeeld: In de modus Dupliceren geven het pen display en het externe display dezelfde afbeelding weer en wordt de cursor tegelijkertijd op elke monitor weergegeven.
Page 67
PD156 PRO 3.2.2 Instelling Werkgebied Definieer het tabletgebied dat aan het schermgebied wordt toegewezen. 1. Volledig gebied : het gehele actieve gebied van de tablet. Dit is de standaardinstelling. 2. Aangepast Gebied : Sleep de hoeken van de voorgrondafbeelding om het schermgeb ied te selecteren.
Page 68
PD156 PRO 3.2.3 Werkgebied draaien Door de richting van het pen display te veranderen om gebruikers meer keuzes te bieden. Er zijn vier richtingen beschikbaar. Snelkoppelingen Toetsen Functie-instelling 3.2.4 Standaardinstelling : Plaats de cursor op de sneltoets of klik op de druktoets om de standaardwaarden te zoeken.
Page 70
PD156 PRO 3.3 Pen Knoppen Functie-instelling Aangepaste instelling: Selecteer de functie die moet worden uitgevoerd in het pop-upvenster, dan wordt deze automatisch opgeslagen. www.gaomon.net...
Page 71
PD156 PRO 3.4 Drukgevoeligheid Instelling The pressure sensitivity will be changed by dragging the points of the pressure curve. Drag the points to the upper left for higher sensitivity. Drag the points to the lower right for lower sensitivity. www.gaomon.net...
Page 72
PD156 PRO 3.5 Pen Druk Testen U kunt geleidelijk druk uitoefenen op de stylus op het scherm om de drukniveau te testen. www.gaomon.net...
Page 73
PD156 PRO 3.6 Kalibratie Schermkalibratie : Klik op het rode kruis op het scherm om de kalibratie te voltooien. Resetten naar fabrieksinstellingen : Klik op "Resetten naar fabrieksinstellingen" om het pen display te resetten. Kalibratie annuleren : Klik op "Kalibratie annuleren" of druk op "ESC" om de kalibratie te stoppen.
Page 74
PD156 PRO 3.7 de Windows Ink-functie inschakelen De functie is voor software die Windows Ink ondersteunt, zoals Microsoft Office, Windows Journal, Adobe Photoshop CC, SketchBook 6 enzovoort. www.gaomon.net...
Page 75
PD156 PRO 3.8 Muismodus Zoals hieronder weergegeven, vink het selectievakje voor de muismodus aan om de muismodus te openen. In de muismodus, als u de pen beweegt, beweegt de cursor volgens het relatieve coördinatenprincipe, vergelijkbaar met het verplaatsen van de cursor met de muis.
Page 76
PD156 PRO 3.9 Druktoetsen en drukcurve aanpassen U kunt de functie van druktoetsen en drukcurve voor verschillende programma's aanpassen. Selecteer een programma, pas de functie van druktoetsen en de drukcurve aan, de instellingen worden automatisch opgeslagen. www.gaomon.net...
Page 77
PD156 PRO De driver ondersteunt het exporteren en importeren van uw aangepaste configuratiegegevens van het product, wat handig is om andere software te gebruiken en het probleem van herhaalde instellingen te vermijden. www.gaomon.net...
Page 78
PD156 PRO 4. Specificaties Model PD156 PRO Paneelgrootte 15.6 inch Resolutie 1.920 x 1.080 (16 : 9 ) LCD-type Actief gebied 344.16 × 193.59mm Contrast ratio 1.000 :1 Scherm Helderheid 220 cd / m² Reactietijd 25 msec 89° / 89°(H) / 89° / 89°(V) Kijkhoek (Typ.)(CR >...
Page 79
Weergaven” 3. Als u besluit om de uitgebreide modus te gebruiken, zorg ervoor dat u de pen weergave kiest als werkgebied in de GAOMON Driver. Dit is meestal “Weergave 2”. Afbeeldingen zijn wazig Zet de schermresolutie op 1920 x 1080.
Page 80
10 mm bedraagt. Er is een afwijking tussen de punt Probeer kalibratie. en de cursor GAOMON driver geeft aan ''apparaat aangesloten'', maar de pen regeert niet in Mac OS 10.14 of hogere versies. VInd hier het antwoord: https://www.gaomon.net/question/macos_mojave_catalina_solution.html Opmerking: Neem voor meer informatie contact met ons op via onze e-mail: service@gaomon.net...
Page 81
PD156 PRO 6. Neem contact met ons op voor After-sales Service GUANGZHOU GAOMON ELECTRONIC TECHNOLOGY CO., LTD. www.facebook.com/Gaomonpentablet twitter.com/Gaomonpentablet service@gaomon.net https://www.gaomon.net www.gaomon.net...
