CG800H-SKY S

ERIES

SKYNET 2000 CONTROL PANEL

SER

ANUAL

CG800H1-SKY

CG100H2-SKY

CG800HHB-SKY

CG800H4-SKY

1 button mood

2 button mood

Doorbell switch

4 button mood

control panel

1.1

ERSION

17 J

, 2014

ANUARY

Disclaimers and Copyright

Nothing contained in this publication is to be construed as granting any right, by implication or otherwise, for the

manufacture, sale, or use in connection with any method, apparatus, or product covered by letters patent, or as insuring

anyone against liability for infringement of letters patent.

Efforts have been made to ensure the accuracy and reliability of the data contained in this publication; however, Citygrow

Energy Systems Limited. makes no representation, warranty, or guarantee in connection with this publication and hereby

expressly disclaims any liability or responsibility for loss or damage resulting from its use or from the use of any product

or methodology described herein; for any violation of any federal, state, or municipal regulation with which this

publication may conflict; or for the infringement of any patent from the use of this publication. Nothing contained in this

publication should be viewed as an endorsement by Citygrow Energy Systems Limited. of any particular manufacturer's

products.

Table of Contents

Need help?

Do you have a question about the CG800H-SKY Series and is the answer not in the manual?

Questions and answers

Summary of Contents for CityGrow Systems CG800H-SKY Series

Page 1 CG800H-SKY S ERIES SKYNET 2000 CONTROL PANEL ANUAL CG800H1-SKY CG100H2-SKY CG800HHB-SKY CG800H4-SKY 1 button mood 2 button mood Doorbell switch 4 button mood control panel control panel control panel ERSION 17 J , 2014 ANUARY Disclaimers and Copyright Nothing contained in this publication is to be construed as granting any right, by implication or otherwise, for the manufacture, sale, or use in connection with any method, apparatus, or product covered by letters patent, or as insuring anyone against liability for infringement of letters patent.
Page 2 CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK) NO USER-SERVICEABLE PARTS INSIDE REFER SERVICING TO QUALIFIED SERVICE PERSONNEL The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated “dangerous voltage”...
Page 3: Table Of Contents
Table of Content Introduction ...................... 1 Understanding of the product-CG800H4-SKY ............2 Understanding of the product-CG100HHB-SKY ............. 3 Dimensions ....................... 4 Wiring ......................5 Installation ....................... 7 Operation instruction ..................10 7.1 CG100H4-SKY, 4 Button Mood Control Panel ............10 7.2 CG800HHB-SKY, Doorbell switch ...............
Page 4: Introduction
1. Introduction Thank you for buying Citygrow’s product. CG800H-SKY Series is both powerful and easy to use and install. Description 1. Wall mount control panel for SkyNET2000 2. Data communicates through RS485 bus and running on Citygrow’s SmartBus protocols. 3. LED indicator for on/off status.
Page 5: Understanding Of The Product-Cg800H4-Sky
2. Understanding of the product-CG800H4-SKY Frame Button panel (front view) Button panel (bottom view) Control button Reset button Dip Switch (for address setting) Connector to Programming Bracket port Bracket Bracket (bottom view) Mounting hole Model number plate Metal clip to fix the button panel Connector to...
Page 6: Understanding Of The Product-Cg100Hhb-Sky
3. Understanding of the product-CG100HHB-SKY Frame Button panel (front view) Button panel (bottom view) Control button Reset button Dip Switch (for address setting) Connector to Programming Bracket port Bracket Bracket(front view) (bottom view) Mounting hole Model number plate Metal clip to fix the button panel...
Page 7: Dimensions
4. Dimensions 85mm 25.5mm...
Page 8: Wiring
5. Wiring Before getting started WARNING! It must be installed by a qualified electrician in accordance with all applicable regulations and building codes. Improper wiring can result in personal injury or damage to control units or other equipment. Always turn off circuit breaker or remove main fuse from power line before doing any work. To avoid overheating and possible damage to equipment.
Page 9 Wiring Diagram CG801SKN-M SkyNET 2000 Main Unit Daisy chain RS485 Wall mount control panels DC 12V Power AC 220V supply Distribution board Neutral Live Power supply Neutral (System) For CG800HHB-SKY only AC Live Door Dry contact Neutral Bell control...
Page 10: Installation
6. Installation In order to install the product correctly, please follow the below steps: STEP 1: IMPORTANT! Turn off main power at the main switch board. STEP 2: Loosen the screws of the original wall switch. Remove the switch and the wiring.
Page 11 STEP 4: Connect the Belden 8723 cable wires and the power wires, and then fix the product on the wall box according to the following diagram. Important! Before plugging the Button panel onto the Bracket, double check the Dip Switch located at the back of the Button panel to see whether the address is equal to the label located at the front of the button panel.
Page 12 STEP 7: Double check if all wiring is correct, then power up the main switch board, the LED indicators on CG800H-SKY series will be lighted up for one second if you push the button once. Since the CG800H-SKY is not programmed and setup by SkyNET Planner Software at this moment, the product buttons will not function at this stage.
Page 13: Operation Instruction
7. Operation instruction 7.1 CG100H4-SKY, 4 Button Mood Control Panel 1. 1, 2, 3, 4 are buttons location. 2. 4 pcs Locks to fix the main unit onto the wall bracket. 3. Reset button 4. Program port Button 1, 2, 3, 4 can be programmed to be ON/OFF function, or Dim up/ Dim Down or Scene function.
Page 14: Cg800Hhb-Sky, Doorbell Switch
7.2 CG800HHB-SKY, Doorbell switch 1. Doorbell button. 2. Clean Room Indicator ( For Hotel Only) 3. Do Not Disturb ( For Hotel Only) MAIN UNIT 4. 4 pcs Locks to fix the main unit onto the wall bracket. 5. Reset button 6.
Page 15: Programming The Skynet System
8. Programming the SkyNET system Remove one of the button panel from the wall, then you will see the wall bracket is still fixed on the wall box. Then prepare a PC with SkyNET Planner Software installed and run it, connect the CG101UT5 and CG100UTC cable from PC to the CG101TP- SKY Tools Panel.
Page 16: Specification
9. Specification CG800H1-SKY CG800HHB-SKY CG800H2-SKY CG800H4-SKY Description 1/2/4 button mood control panel for SkyNET Doorbell switch for SkyNET 2000 2000 Function 1 preset lighting scene for CG800H1- Build-in contactor to drive AC door bell. LED backlight 2 preset lighting scene for CG800H2- Support two way function, ie.
