- Page 1 Network Video Recorders Quick Guide Version: V1.01 BOM: 3101C0FC...
- Page 2 Thank you for purchasing our product. Contact your local dealer if you have any questions or feedback. No part of this manual may be copied, reproduced, translated, or distributed in any form or by any means without prior consent in writing from our company.
- Page 3 instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. This product complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: This device may not cause harmful interference.
- Page 4 Disk Installation Choose an option. Use a 1# or 2# screwdriver as needed. All photos are only for illustration. Option 1 (for 1 or 2 disks) 1. Remove the cover, connect data 2. Connect data and power cables to the and power cables to disk(s), and motherboard and then install the then secure disk(s) with screws.
- Page 5 Option 3 (for more than 2 disks) You will open the front panel and install hard disks on mounting brackets. 1. Secure the disk to a pair of 2. Press the latches on both sides (1) and 用双手分别按住前面板两侧卡扣， mounting brackets (L means then detach the front panel (2).
- Page 6 Audio output Grounding PoE ports Power on/off HDMI output DC power VGA output Network Audio input RS232 (for maintenance) eSATA interface Alarm input/output CVBS output AC power Network Power on/off Grounding 12V DC output RS485 Audio out/input HDMI output VGA output HDMI output...
- Page 7 Description PWR(Power) Steady on: Connected to power. Steady on: Normal. RUN(Operation) Blinks: Starting up. NET(Network) Steady on: Connected to network. GUARD(Arming) Steady on: Arming is enabled. Steady on: Activated for remote control. Blinks: Authenticating device code. ALM(Alarm) Steady on: Device alarm occurred.
- Page 8 Live View Click Menu > Camera > Camera. The discovered cameras are listed. Click to add a camera. To search a network segment, click Search. If a camera is added but live video is not available, check network connection and make sure the correct camera username and password are set in the system.
