Welotec TK600 Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
TK600
Version:
v1.0.0
Date:
16.05.2023

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TK600 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Welotec TK600

Summary of Contents for Welotec TK600

  • Page 1 TK600 Version: v1.0.0 Date: 16.05.2023...

  • Page 2: Table Of Contents

    4 FAQ How Do I Restore Factory Settings Through Hardware? ......Welotec GmbH www.welotec.com Zum Hagenbach 7 info@welotec.com...

  • Page 3: Preface

    1 Preface This document describes how to install and operate the TK600 series router. Before using these products, confirm the product model and the number of accessories inside the package, and purchase a SIM card from the local network operator.

  • Page 4: Structure And Dimensions

    1.2 Structure and Dimensions Welotec GmbH www.welotec.com Zum Hagenbach 7 info@welotec.com Page 3 48366 Laer +49 2554 9130 00...

  • Page 5: Installation

    2 with gentle force, to insert the DIN rail seat onto the DIN rail. Check that the device is installed reliably on the DIN rail, as shown in following figure on the right. Welotec GmbH www.welotec.com Zum Hagenbach 7 info@welotec.com...

  • Page 6: Installing A Sim Card

    Lift the device when its lower end isolates from the DIN rail. Then, take off the device from the DIN rail. 2.3 Installing a SIM Card TK600 supports Dual SIM card. 2.4 Installing an Antenna Revolve the movable part of the metal SMA interface with gentle force until it cannot be revolved, in which state the outer thread of the antenna connection cable is invisible.

  • Page 7: Installing The Power Supply

    2.5.1 Procedure: Step 1: Remove the terminal from the router. Step 2: Unfasten the locking screw on the terminal. Step 3: Connect the power cable to the terminal and fasten the locking screw. Welotec GmbH www.welotec.com Zum Hagenbach 7 info@welotec.com...

  • Page 8: Installing The Ground Protection

    Ground the router to improve its interference resistance. Connect the ground cable to the ground post of the router based on the operation environment. 2.7 Connecting the Network Cable Connect the router to a PC directly by using the Ethernet cable. Welotec GmbH www.welotec.com Zum Hagenbach 7 info@welotec.com...

  • Page 9: Connecting Terminals

    Terminals provide the RS232 and RS485 interface modes. Connect cables to the corresponding terminals before using the interfaces. During installation, remove the terminals from the device, unfasten the locking screws on the terminals, connect cables to the corresponding terminals, and fasten the screws. Sort the cables in order. Welotec GmbH www.welotec.com Zum Hagenbach 7 info@welotec.com...

  • Page 10: Configuring Network Connection

    Step 1: By default, the IP address of WAN/LAN on TK600 is 192.168.1.1; the IP address of LAN on TK600 is 192.168.2.1. This document uses the LAN port to access the TK600 as an example. Set the PCs IP address to be on the same subnet with LAN.

  • Page 11: Logging In To The Router

    (default: 123456), and click OK or press Enter to access the web configuration page. 3.3 Navigation Bar Operations 3.3.1 Returning to the Homepage You can click the Welotec logo in the upper left corner of any web page of the TK600 to return to the Overview page quickly. Welotec GmbH www.welotec.com...

  • Page 12: Overview

    The Overview page displays information about the TK600, such as its network connection status, system informa‑ tion, and data usage. You can quickly obtain the TK600 running status on this page after you log in to the TK600 web page, the Overview page appears by default. You can also click Overview to display this page. This page displays the following information: Network Connection Status: shows the TK600s network connection status and network configuration.
  • Page 13 • On‑demand Dial – Data Trigger: indicates that the router is offline by default and will dial up automatically when data is sent to the Internet. Welotec GmbH www.welotec.com Zum Hagenbach 7 info@welotec.com Page 12 48366 Laer...
  • Page 14 Infinitely Dial Retry: enables the router to retry unlimited times upon a dial‑up failure. • Debug: enables display of more detailed system logs. • Expert Options: allows you to set command parameters. Welotec GmbH www.welotec.com Zum Hagenbach 7 info@welotec.com Page 13...
  • Page 15 – Description: specifies the descriptive information that identifies the Ethernet interface. – Secondary IP Setting: allows you to set up to 10 secondary IP addresses in addition to the primary IP ad‑ dress. Welotec GmbH www.welotec.com Zum Hagenbach 7 info@welotec.com...
  • Page 16 Loopback The loopback interface is a logical, virtual interface on the TK600. After you create and configure the loopback interface, you can ping its IP address or set up a Telnet connection to it to test the network connectivity. You can set or view loopback interface parameters on the Loopback page.
  • Page 17 Windows Name Server (WINS): specifies the IP address of the WINS server. • Static IP Setting: allows you to bind a fixed IP address to a MAC address, as shown in the following figure. Welotec GmbH www.welotec.com Zum Hagenbach 7 info@welotec.com...
  • Page 18 4. Enter the domain name or IP address of a host and specify the matching IP address. 5. Click OK to save the configuration, and then click Submit to apply the configuration. The following figure shows the configuration of the DNS relay service. Welotec GmbH www.welotec.com Zum Hagenbach 7 info@welotec.com...
  • Page 19 Host List You can view information about hosts connected to the TK600 on the Host List page. Choose Network > Network Services > Host List to display the Host List page, as shown in the following figure. 3.5.3 Routing Routing Status Choose Network >...
  • Page 20 Gateway: specifies the IP address of the next router that data packets pass through before reaching the desti‑ nation IP address. • Distance: specifies the priority of the route. A smaller value indicates a higher priority. • Track ID: specifies the track index or ID. Welotec GmbH www.welotec.com Zum Hagenbach 7 info@welotec.com Page 19 48366 Laer...
  • Page 21 6. Click OK to save the configuration, and then click Submit to apply the configuration. The following figure shows the configuration of a standard access control policy. The following figure shows the configuration of an extended access control policy. Welotec GmbH www.welotec.com Zum Hagenbach 7 info@welotec.com...
  • Page 22 – Source IP: specifies the source IP address of packets in the ACL rule. If this field is kept blank, the rule matches packets from all networks. – Source Wildcard: specifies the wildcard mask of the source IP address in the ACL rule. Welotec GmbH www.welotec.com Zum Hagenbach 7 info@welotec.com...
  • Page 23 3. Click the Add icon under Network Address Translation (NAT) Rules to add an NAT rule and set parameters for the rule. 4. Click OK to save the configuration, and then click Submit to apply the configuration. 5. Welotec GmbH www.welotec.com Zum Hagenbach 7 info@welotec.com...
  • Page 24 As shown in the following figure, the NAT rule allows hosts connected to the TK600 to connect to the Internet by using the IP address of interface WAN. Parameters of the NAT rule are described as follows: • Action – SNAT: uses the source network address translation feature that translates source IP addresses of data pack‑...

  • Page 25: Edge Computing

    Install and run Python App To install and run Python App in TK600, please refer to the following process, this document takes the Device Su‑ pervisor as an example (if you want own functionality please get in contact with your Welotec Sales): •...
  • Page 26 Once enabled, the App automatically runs and will run every time the TK600 is started. Welotec GmbH www.welotec.com Zum Hagenbach 7 info@welotec.com Page 25 48366 Laer +49 2554 9130 00...
  • Page 27 Generally, if you need to update the Python App version, you only need to import the new version of the App on the Edge Computing > Python Edge Computing page. After the update is completed, as shown below Welotec GmbH www.welotec.com Zum Hagenbach 7 info@welotec.com...

  • Page 28: System

    Python Edge Computing, select Enable Debug Mode. After the debugging mode is enabled, TK600 will start an SSH server to listen on port 222 of LAN (default IP ad‑ dress being 192.168.2.1). The username and password of the SSH server are displayed on the previous web page.
  • Page 29 TK600, such as its running status and changes of configuration. On the Configure page, you can set a remote log server. Then, the TK600 will synchronize all system logs to the remote log server. The host used as the remote log server must run a remote log program.
  • Page 30 4. Wait until the upgrade succeeds, and then click Reboot to restart the TK600. 3.7.5 Access Tools To facilitate TK600 management and configuration, you can configure the TK600 management and access methods on the Access Tools page. Follow these steps to complete the configuration: •...
  • Page 31 4. Remote Control: enables or disables remote access to the TK600 through HTTPS. If no remote control network is specified, the TK600 can be remotely controlled through any network. The following figure shows the configuration of Telnet‑based management. The Telnet parameters are described as follows: 1.
  • Page 32 TK600 on this page. You can enter some extension options in the Expert Options area. For example, expert option ‑t for the ping tool enables the TK600 to ping a specified host continuously until you stop the ping. The ping tool can be used to check whether a network is reachable.

  • Page 33: Advanced

    Choose System > 3rd Party Notification to display the 3rd Party Notification page. You can view the statement about the third‑party software used for the TK600. 3.8 Advanced Some functions are not fully migrated yet from TK800 series to TK600 series. For advanced functions you can still use the TK800 webinterface. 3.8.1 Administration On this page, you can view the system status and network status (including the firmware version, MAC address, system time, and up time of the router).
  • Page 34 Tun: mostly used for IP‑based communication. Tap: allows complete Ethernet frames to pass through the OpenVPN tunnel and provides support for non‑IP protocols. – Network Type: Options are net30, p2p, and subnet. Welotec GmbH www.welotec.com Zum Hagenbach 7 info@welotec.com Page 33...
  • Page 35 – Local IP Address: specifies the virtual IP address of the OpenVPN server interface. – Remote IP Address: specifies the virtual IP address of the OpenVPN client. – Description: specifies the description of the OpenVPN tunnel. • Welotec GmbH www.welotec.com Zum Hagenbach 7 info@welotec.com...
  • Page 36 Strict CA: sets the ID of a trusted CA. The certificate of a device is enrolled and issued by a trusted CA. Therefore, you must specify the ID of a trusted CA to bind the device to the CA. Then, the device completes certificate application, acquisition, revocation, and query through this CA. Welotec GmbH www.welotec.com Zum Hagenbach 7 info@welotec.com...
  • Page 37 – OCSP URL: specifies the URL of the Online Certificate Status Protocol (OCSP) server. Generally, it is the same as the URL of the CA server. Note: When using a certificate, ensure that the system time is consistent with the actual time. Welotec GmbH www.welotec.com Zum Hagenbach 7 info@welotec.com...

  • Page 38: Faq

    Hardware? Follow these steps: 1. Press the RESET button while turning the TK600 on. 2. As soon as the ERROR LED lights up (approx. 10 seconds after switching on), release the RESET button. 3. After a few seconds, the ERROR LED will no longer light up. Now press the RESET button again until the Error light flashes and then release the button.
