Pilot Communications ANR7000BT Operating Instructions

ANR7000BT
BLUETOOTH and ANR
Operating Instructions
Bluetooth Status
Aux Input
Volume Control Power Status

BT-Link Controls

Volume Controls:
You can independently adjust the volume for each ear
from your BT-Link.
Power Status/Button:
Press and hold for one second to turn ON or OFF BT-
Link. LED indicates the power source and its status.
Bluetooth Status/Button:
OFF the Bluetooth. LED indicates the Bluetooth status. Additional phone
functions are available.
Aux Input:
Use the provided 3.5 mm cable to connect to your audio source
without Bluetooth. When put the 3.5mm plug into the jack, there is a voice "line
in mode", when set to line in mode, the bluetooth volume control also can
control the line in device volume
Audio Priority Switch:
Controls how Aux audio and transmissions are
prioritized. Bluetooth Volume or next/previous song: Adjust your Bluetooth
device volume, or switch to next/previous songs
USB type C Input:
Power your BT-Link via USB instead of through batteries.

Getting Started

Install batteries
Press on the battery box lid where indicated and slide the lid off. Insert two
AA batteries ensuring that the polarity is as shown. Slide the battery box lid
back on and you are ready to go.
Bluetooth Volume
USB Input
Audio Priority Switch
Press and hold for one second to turn ON or

Powering On

To turn on, press the Power On button for more than
1 second and then let go.You will hear a voice say
"Power On". If Power Button is pressed for more
than 3 seconds BT-Link will turn on and then off.

Bluetooth

To turn on Bluetooth press the Power Button for
more than 1 second and then let go. You will hear a
voice say "Power On". If Power Button is pressed for
more than 3 seconds BT-Link will turn on and then off.
To turn off Bluetooth press the Power Button for
1 second and you will hear a voice say "Power OFF".

Pairing

When you turn on Bluetooth the BT-Link will begin searching for a device
to pair with. Look for the Bluetooth name "BT-Link". If prompted for a
code, enter 0000.

Pairing with 2nd device

To pair with a second device you must first disable the bluetooth function
of the first device. Now pair your second device and enable bluetooth
function of your first device. You should now have two devices paired.

Bluetooth Volume or next/previous song Control

On the side of BT-Link
Long press +/>| or -/|< to increase or decrease Bluetooth
volume. When you reach the Max or Min volume there is
a "DiDi" sound.
Short press +/>| or -/<| to switch to next/previous song.

Bluetooth Phone Functions

Press once to pick up a call
Press once to hang up a call
Press for more than 1 second to decline a call
Press twice quickly to redial the last call

Headset Volume

To adjust headset volume use the slide switches on front of
your BT-Link.

Audio Priority Modes

Use the Audio Priority switch to mute your auxiliary audio
input when you are sending or receiving radio transmissions.
AUTO: With incoming transmissions, Bluetooth and Aux are
muted and resume when transmission ends.
MIX: Aux and Bluetooth continue to play with transmissions.
OFF: Only transmissions are heard, Bluetooth and Aux are muted.
When set to Off Mode, in order to save battery power, the bluetooth is
POWERED OFF. When next switched to AUTO or MIX the bluetooth is
powered on again and will connect to your bluetooth devices in seconds.
