Qlogic SANbox 5200 Specifications

S A N b o x 5 2 0 0 / 5 2 0 2
t h e
F I B R E C H A N N E L
S T A C K A B L E S W I T C H
F I B R E C H A N N E L S W I T C H E S
8, 12 or 16 auto detecting
•
2Gb /1Gb device ports
4 10Gb ports for high speed
•
stacking links
4-port 2Gb/1Gb and/or 10Gb
•
field upgrade licenses
available
Stacking of up to 6 units
•
for 96 available user ports
Non-Disruptive Code Load
•
and Activation (NDCLA)
Single and dual hot-swap
•
power supply configurations
available
BREAKTHROUGH EASE OF USE. The first Fibre Channel stackable
switches to be configured and zoned with simple wizards. Point-and-
click installation and configuration wizards get your QLogic HBAs and
switches up and running quickly.
INCREDIBLY LOW COST. Starting at 8 ports, SANbox 5200/5202 stack-
able switches offer an entry point affordable to the smallest business.
And with an easy-to-use graphical user interface (GUI), you won't have to
hire a SAN expert to manage your stack.
MODULAR SCALABILITY. Start with 8 ports and then grow your SAN in 4
port increments up to 96 ports in a single stack. A key benefit is the ability
to add, change or delete switches without disrupting your storage network.
SANbox
10
G b
The benefits of stackable IP switches are now available for SANs. The SANbox
5200/5202 stackable switch delivers the seamless scalability and performance of a
chassis switch, in an easy-to-manage, pay-as-you-grow solution. With sixteen 2Gb
ports plus a four-pack of high-speed 10Gb ISL ports, and entry as low as 8 ports with
4-port software-keyed increments and included graphical user interface (GUI) wizards,
each SANbox 5200/5202 stackable switch provides maximum flexibility for configuring
and scaling SANs. Available in two power supply configurations: single integrated
(SB5200) and dual hot-swappable (SB5202).
• Configuration, Zoning and Extended
Distance wizards to simplify switch
installation and fabric scaling
• Interoperable with all FC-SW-2
compliant Fibre Channel switches
• Full-fabric, public-loop or switch-to-
switch connectivity on 2Gb/1Gb ports
• Full-fabric or switch-to-switch
connectivity on 10Gb ports
• Auto-sensing, self-configuring ports
• Fabric Tracker tool for fabric-wide
snapshots and detection of
configuration changes
5200/5202
®
•
The Industry's First
•
•
•
Fibre Channel
•
•
Stackable Switch
•
•
• Non-blocking full-bandwidth
architecture
• I/O StreamGuard for RSCN
suppression
• "No-Wait" routing – guaranteed
maximum performance
independent of data traffic
• Industry's lowest latency for
maximum performance
SFP (small form-factor pluggable)
•
connectivity – 16 front ports in a
1U full-width rack form-factor
PERVASIVE INTEROPERABILITY. Interoperable with popular servers,
storage and networking products from major manufacturers, including
ADIC, Brocade, Cisco, Computer Associates, Dell, EMC, Emulex, HDS, HP,
IBM, LSI, McDATA, Microsoft, Quantum, StorageTek, Sun, VERITAS, and
many others.
BLAZING 10Gb PERFORMANCE. The first SAN product to support traffic
between switches, servers and storage at up to 10Gb per second — six
times faster than 2Gb networks being deployed today. A single, 10Gb
inter-switch link (ISL) ensures low latency between switches and
eliminates the cost and complexity of trunking up to six 2Gb ports.
•
•
•
•
•
•
Stackable
Switch
•
•
•
•
•
•
•
•
• Designed for seamless operation
with higher-level third-party
management applications
• In-band, out-of-band, Telnet and
SNMP management access
• ASIC-embedded memory – faster,
more scalable and more reliable
than shared memory architecture
