MS-250 Powered Subwoofer Wiring Diagram
RT +
RT -
L +
L-
MS-51 Amplifier may be mounted on speaker or on a flat surface
See ME-51 Amplifier Instructions for detailed diagrams
Speaker wire polarity is critical to proper performance
520 McCormick Drive, Suite F, Glen Burnie, MD 21061 Phone: 410 761-4000 Fax: 410 761-6274
Gray
Gray/ Black
White
White /Black
Or
IMR-4
Audio Out
Receiver
Receiver
Switched 12v
or
"Power Antenna"
Connection
12 v Positive
12v Negative
www.polyplanar.com
