Page 4: Introduction
www.ACURA.com INTRODUCTION Technology Solutions’ BTL-1010 2D UHF Reader provides Ultra High Frequency (UHF) Radio Frequency Identification (RFID), with optional barcode scanning functionality. The unit can be used stand alone or paired with a Bluetooth ® wireless technology enabled host device. It can be used with UHF transponders including the EPC Global Class 1 Generation 2 transponders. -
Page 5: Using The Btl-1010 2D Uhf Reader
‘Unlocked’ warning label Battery cover release slider in unlocked position FIGURE 3: BTL-1010 2D UHF Reader User Guide © Technology Solutions (UK) Ltd 2014 V1.24... - Page 6 BTL-1010 2D body: Removeable battery cover FIGURE 4: Remove battery cover in this direction FIGURE 5: BTL-1010 2D UHF Reader User Guide © Technology Solutions (UK) Ltd 2014 V1.24...
- Page 7 Battery placement FIGURE 6: Battery in position FIGURE 7: © Technology Solutions (UK) Ltd 2014 BTL-1010 2D UHF Reader User Guide V1.24...
- Page 8 Move battery cover release slider to locked position FIGURE 9: BTL-1010 2D UHF Reader User Guide © Technology Solutions (UK) Ltd 2014 V1.24...
-
Page 9: Locking The Battery Cover (Optional)
Battery cover locking screw location FIGURE 10: Battery cover fully locked FIGURE 11: BTL-1010 2D UHF Reader User Guide © Technology Solutions (UK) Ltd 2014 V1.24... -
Page 10: Charging And Micro Usb Connection
Location of Micro USB socket FIGURE 12: Attaching the Micro USB cable FIGURE 13: BTL-1010 2D UHF Reader User Guide V1.24 © Technology Solutions (UK) Ltd 2014... -
Page 11: Button Operation
In the default configuration, the secondary button action (Barcode scanning) can also be initiated by a rapid double-click-and-hold on the primary button. BTL-1010 2D UHF Reader User Guide V1.24 © Technology Solutions (UK) Ltd 2014... -
Page 12: Reading Transponders
© Technology Solutions (UK) Ltd 2014 BTL-1010 2D UHF Reader User Guide V1.24... -
Page 13: Status Led
Location of status LEDs FIGURE 16: BTL-1010 2D UHF Reader User Guide V1.24 © Technology Solutions (UK) Ltd 2014... -
Page 14: Connections
Awaken the BTL-1010 2D UHF Reader by squeezing the trigger, which is confirmed by the flashing of the blue LED. To pair with your iOS device, navigate to the Bluetooth ® option within the Settings menu on your iOS device. © Technology Solutions (UK) Ltd 2014 BTL-1010 2D UHF Reader User Guide V1.24... -
Page 15: View List Of Bluetooth ® Devices (Ios 7)
List of devices in Bluetooth settings ® FIGURE 20: © Technology Solutions (UK) Ltd 2014 BTL-1010 2D UHF Reader User Guide V1.24... -
Page 16: Pair With Acura Bluetooth ® Device
/ iPhone ® Allow connection FIGURE 23: Open ACURA’s RFID Explorer App. The RFID Explorer App can be downloaded from the App Store. © Technology Solutions (UK) Ltd 2014 BTL-1010 2D UHF Reader User Guide V1.24... - Page 17 iPad ® ® ® iPod / iPhone No devices are available FIGURE 25: © Technology Solutions (UK) Ltd 2014 BTL-1010 2D UHF Reader User Guide V1.24...
- Page 18 iPad ® iPod ® / iPhone ® List of paired Bluetooth devices ® FIGURE 27: BTL-1010 2D UHF Reader User Guide V1.24 © Technology Solutions (UK) Ltd 2014...
- Page 19 © Technology Solutions (UK) Ltd 2014 BTL-1010 2D UHF Reader User Guide V1.24...
-
Page 20: Micro Sd Card
MicroSD inserted correctly FIGURE 13: FIGURE 13: Rotate card slot downwards Slide card slot into locked position FIGURE 13: FIGURE 13: © Technology Solutions (UK) Ltd 2014 BTL-1010 2D UHF Reader User Guide V1.24... -
Page 21: Auto Run File (Auto.txt)
DT: 2013-11-18T10:07:42 EV: Wake up DT: 2013-11-18T10:07:42 EV: Connected USB CS: .al –dlon CS: .iv LCMD 000000 -qss0 –qta EP: 330DE29525C0210005F5F8F2 EP: 221001500000000000000027 BTL-1010 2D UHF Reader User Guide V1.24 © Technology Solutions (UK) Ltd 2014... -
Page 22: Software Development
BTL-1010 2D UHF Reader User Guide V1.24 © Technology Solutions (UK) Ltd 2014... -
Page 23: Troubleshooting And Maintenance
Set the Bluetooth ® PIN to a known Reader has been changed value BTL-1010 2D UHF Reader User Guide V1.24 © Technology Solutions (UK) Ltd 2014... -
Page 24: Regulatory Information
Caution: Viewing the illumination from the barcode reader with optical instruments may result in increased hazard. BTL-1010 2D UHF Reader User Guide V1.24 © Technology Solutions (UK) Ltd 2014... -
Page 25: Health And Safety Recommendations
Replace battery only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer’s instructions and local disposal requirements. BTL-1010 2D UHF Reader User Guide V1.24 © Technology Solutions (UK) Ltd 2014... -
Page 26: Waste Electrical And Electronic Equipment (Weee)
ACURA during manufacture of the Product. BTL-1010 2D UHF Reader User Guide V1.24 © Technology Solutions (UK) Ltd 2014... - Page 27 © Technology Solutions (UK) Ltd 2014 BTL-1010 2D UHF Reader User Guide V1.24...
-
Page 28: About Tsl
ISO 9001: 2008 © Technology Solutions (UK) Ltd 2014. All rights reserved. Technology Solutions (UK) Limited reserves the right to change its products, specifications and services at any time without notice. BTL-1010 2D UHF Reader User Guide V1.24...
