- Page 1 Owner’s Manual S u p e r B l u e PB559X PB779X...
- Page 2 Congratulations on your purchase of a new Pyramid Super Blue amplifier. Super Blue amps are some of the most advanced car amplification products available. These quality audio products are designed and engineered to afford you years of uncompromised musical service. Pyramid has utilized the latest electronic technologies in order to deliver a superb listening experience.
- Page 3 2 ch amp PB559X• PB779X s p e c i f i c a t i o n s output power @14.4 V.D.C 1 Khz Maximum Power Output RMS Power Output @ 4 ohms bass/treble control subwoofer crossover bridged mode...
-
Page 4: Features And Controls
2 ch amp PB559X high level inputs power LED low level inputs input gain control treble control bass control bridged mode switch speaker connections power terminals protection indicator power fuse owner’s manual PB779X •... - Page 5 high level inputs if your car stereo does not have RCA output jacks, you can connect the speaker output from the stereo system to the amplifier. power LED this indicator is illuminated when power is applied. low level inputs this amp features gold-plated RCA input jacks for high impedance input.
-
Page 6: Mounting And Installation
2 ch amp PB559X • PB779X mounting and installation Please read the Installation Precautions section below before installing your Pyramid Super Blue amplifier, and then refer to the diagrams provided to connect power, audio input and speaker connections according to your own system configuration requirements. -
Page 7: Electrical Connections
2 ch amp PB559X• PB779X electrical connections PB559X • PB779X to remote turn-on 12V battery +12V head unit... -
Page 8: Stereo Input Connections
L/R audio outputs high level inputs using wiring harness 2 ch amp PB559X • PB779X head unit head unit from speaker terminals owner’s manual PLEASE NOTE! If using high level inputs, do not... -
Page 9: Mono Input Connections
Y adaptors high level inputs using wiring harness 2 ch amp PB559X •PB779X head unit head unit from speaker terminals PLEASE NOTE! If using high level inputs, do not use the low level RCA inputs at the same time! -
Page 10: Speaker Connections
2 ch amp PB559X • PB779X LEFT speaker owner’s manual mode switch in STEREO position RIGHT speaker mode switch in BRIDGED position MINIMUM SPEAKER IMPEDANCE 4 OHMS! speaker... -
Page 11: Troubleshooting
2 ch amp PB559X • PB779X troubleshooting Before removing your amplifier, refer to the list below and follow the suggested procedures. Always test the speakers and their wires first. Amplifier will not power up. • Check for good ground connection. -
Page 12: For Your Protection
MANUFACTURER’S LIMITED TWO YEAR WARRANTY PYRAMID SOUND CORP. warrants this unit to be free from defective material or workmanship and will repair or replace this unit or any part thereof if it proves defective in normal use or service within two (2) years from the date of original purchase.
