8' x 6' x 6'6" Professional Growers Greenhouse
Assembly Instructions
C
B
A
DESCRIPTION
MODEL #
A
B
C
PGG68
Professional
2.4 x 1.8 x 2 M - Green
3503514
Growers Greenhouse
8' x 6' x 6'6"
Please read instructions COMPLETELY before assembly. This shelter MUST be securely anchored.
Before you start: 2 or more individuals recommended for assembly, approximate time 1
1
/
hours.
2
PARTS & SERVICE: 0208 988 7400
E-mail: Parts@clarkeinternational.com or
Clarke International
Service@clarkeinternational.com
Hemnall Street
Epping
SALES: UK 01992 565333 or
Essex CM16 4LG
ENGLAND
EXPORT: 00 44 (0)1992 565335
www.clarkeinternational.com
05_70650_0A
3/1912
Page 1

Advertisement

loading
Need help?

Need help?

Do you have a question about the PGG68 and is the answer not in the manual?

Questions and answers

Summary of Contents for Clarke PGG68

  • Page 1 8' x 6' x 6'6" Professional Growers Greenhouse Assembly Instructions DESCRIPTION MODEL # PGG68 Professional 2.4 x 1.8 x 2 M - Green 3503514 Growers Greenhouse 8' x 6' x 6'6" Please read instructions COMPLETELY before assembly. This shelter MUST be securely anchored.
  • Page 2: Care And Cleaning

    AncHorinG AnD instAllAtion oF FrAMe: PRoPER ANCHoRING oF THE FRAME IS THE RESPoNSIBILITY oF THE CoNSUMER. Clarke International is not responsible for damage to the unit or the contents from acts of nature. Any greenhouse that is not ®...
  • Page 3 8' x 6' x 6'6" Organic Growers Greenhouse - Parts List - Model # PGG68 3503514 Description of Parts: Quantity Part # 3-Way Frame Connectors 802860 4-Way Frame Connectors 802861 34.4 in. Poles 802864 22.2 in. Upright Poles 802862 802868 45.7 in.
  • Page 4 1. lAY oUt rooF FrAMe 802860 802861 802860 802868 802868 802860 802861 802860 802868 802868 802860 802861 802860 802868 802868 2. AsseMBle rooF FrAMe Use 03032 bolts and 07000 wingnuts as shown. 4-Way Connections 3-Way Connections 802868 03032 802864 802861 802860 03032 03032...
  • Page 5 3. AsseMBle leGs & AttAcH to rooF FrAMe Use bolts as shown in illustrations. A. Assemble each of the 6 legs. B. Attach legs with 1-7/8 inch bolts (#03032) on one side of roof frame, letting the other side of roof frame rest on the ground.
  • Page 6 4. AsseMBle coVer rAils A. Place a cover rail between each leg and secure them with cover clamps as shown below. (802695) Loosely HAND-TIGHTEN note: these connections. B. Slide the cover rails so they are approximately 8 inches up from the ground. Middle Rib Cross Rail Clamps 802864 13201...
  • Page 7 6. instAllinG coVer AnD coVer rAils A. Your greenhouse cover comes in one complete piece. You may find it easier to fit the cover over the frame by partially opening the door zippers. B. Pull cover over the frame, making sure to center cover on frame. There should be an equal amount of over- hang at all four corners.
  • Page 8 7. properlY AncHor FrAMe Your unit comes with 4 Anchors. A. Anchors must be placed inside shelter at the corners of the shelter. Insert a ¾-inch pipe or steel rod, through the eyelet of the auger and screw the anchor into the ground until the eyelet is sticking out of the ground by 1 to 2 inches so it can be anchored to the legs.
  • Page 9 8. instAllinG AnD UsinG siDe Vent rAils A. Assemble rails for the side vents as shown below. Bolts are not used for these connections. B. Insert assembled vent rails into pockets at the bottom of the vent covers on each side. C.
  • Page 10 9. UsinG tHe enD pAnel Vents A. To open vents, completely unzip the semicircular zipper. B. Roll the vent cover upward. C. Use the hook-and-loop strap to secure the vent cover in a rolled position. 05_70650_0A Page 10...
