Summary of Contents for Novitek EXCLUSIVE
- Page 1 SISÄLLYSLUETTELO SISÄLLYSLUETTELO OUTDOOR HOT TUB INSTALLATION- AND OPERATION MANUAL ST2T, TP700, TP500 EXCLUSIVE SELECT BASIC / PREMIUM STANDARD EXCLUSIVE SELECT PREMIUM STANDARD � KIILO SELECT BASIC � LUOSTO � MALLA � RUKA � HALTI � YLLÄS � HELMI � OLOS �...
-
Page 2: Table Of Contents
The supplier or vendor do not cover for any potential loss of use. OY NORDIC SPA LTD | Tehdaskatu 7, 24100 Salo | www.novitek.fi... -
Page 3: Dear Customer
We recommend that a continuous bathing session be no longer than 30 minutes in length, after which you should cool down for 5–10 minutes. • Ensure adequate hydration during the bathing experience. • Water over 40°C warm may be harmful for your health. OY NORDIC SPA LTD | Tehdaskatu 7, 24100 Salo | www.novitek.fi... -
Page 4: Installation Site
2 000 – 3 000 kg, depending on the model of the pool. The manufacturer does not account for potential damage caused by incorrect installation of the pool. OY NORDIC SPA LTD | Tehdaskatu 7, 24100 Salo | www.novitek.fi... -
Page 5: Startup
The pump will pump for a moment, after which the water will start to fl ow properly. Dry any spilled water and close the service hatch. Your outdoor spa pool is ready for use. OY NORDIC SPA LTD | Tehdaskatu 7, 24100 Salo | www .novitek .fi... -
Page 6: General
Clean the inner surface thoroughly with a mild disinfectant. Use a soft and lint-free cloth or sponge. After cleaning the pool, we recommend waxing the coating. The wax effectively protects the naturally shiny surface of the pool. OY NORDIC SPA LTD | Tehdaskatu 7, 24100 Salo | www .novitek .fi... -
Page 7: Cleaning The Pool
If you do not intend to use the pool during winter, we recommend setting the pool into the REST state and using a pool protection hood. PLEASE NOTE! The warranty does not cover damage caused by freezing. OY NORDIC SPA LTD | Tehdaskatu 7, 24100 Salo | www.novitek.fi... -
Page 8: Fiber Filter
The use of the pool, chlorine use and rainwater that potentially winds up in the pool lower the pH value of the water. The chemical expenditure varies depending on the municipality, since the water pH value, as well as chalice and iron concentrations fluctuate greatly. OY NORDIC SPA LTD | Tehdaskatu 7, 24100 Salo | www.novitek.fi... -
Page 9: Water Care Troubleshooting Guide
• Adjust the water pH level to the • Total alkalinity of water too low recommended range Calcification • Water pH level too low • Empty, clean and refill the pool OY NORDIC SPA LTD | Tehdaskatu 7, 24100 Salo | www.novitek.fi... -
Page 10: Main View
-symbol. Depending on the view, you can change settings or move to the next view of the menu with the arrow brackets. PLEASE NOTE! The look of the screen interface may differ from the instructions. OY NORDIC SPA LTD | Tehdaskatu 7, 24100 Salo | www .novitek .fi... -
Page 11: Setting The Time
The display language can be changed by choosing Language in the Settings menu. Choose your LANGUAGE SETTINGS desired language and save the choice by pressing the Select symbol. OY NORDIC SPA LTD | Tehdaskatu 7, 24100 Salo | www .novitek .fi... -
Page 12: Modes
The pool has an automatic preset cleaning cycle. The cleaning cycle starts when the pump has been turned off for at least 30 minutes. You can fi nd the cleaning cycle settings in the Settings menu, by SETTINGS pressing the Cleanup symbol. CLEANUP OY NORDIC SPA LTD | Tehdaskatu 7, 24100 Salo | www .novitek .fi... -
Page 13: M8 Efficient Smartness
In the technical settings you UTILITIES SETTINGS can modify the screen time-out settings Panel as well as see the log information of the last 24 error PANEL codes Faults FAULTS OY NORDIC SPA LTD | Tehdaskatu 7, 24100 Salo | www.novitek.fi... -
Page 14: Screen Error Messages
DO NOT ENTER THE WATER! The water A pump may be stuck on The pump will not turn off. may have overheated. Turn off power to the pool and contact your service agent. OY NORDIC SPA LTD | Tehdaskatu 7, 24100 Salo | www .novitek .fi... -
Page 15: Select Basic (Tp700)
. The active function is selected by pressing selection key . You go back to the main view, by navigating on the Back symbol and pressing the selection key OY NORDIC SPA LTD | Tehdaskatu 7, 24100 Salo | www .novitek .fi... -
Page 16: Setting The Time
By only locking the settings, the lights and jets of the pool can be used normally. You can lock and unlock the panel in the menu by pressing the right arrow key on the wanted locking option. OY NORDIC SPA LTD | Tehdaskatu 7, 24100 Salo | www.novitek.fi... -
Page 17: Modes
12 hours. For example, the filtration cycles can be set the factory set periods 8:00–10:00 pm and 8:00–10:00 am. PLEASE NOTE! If you use the pool more frequently than three times per week, the length of the filtration cycles must be increased. OY NORDIC SPA LTD | Tehdaskatu 7, 24100 Salo | www.novitek.fi... -
Page 18: Cleaning Cycle
• Heater Wattage: Heater power kW (1—3/3 —6). • Heater Type: Heater type. • Dip Switch Settings: Control centre dip switch settings. • Panel Version: Key panel program version. OY NORDIC SPA LTD | Tehdaskatu 7, 24100 Salo | www.novitek.fi... -
Page 19: Spa Menu
Check that the ground fault circuit interrupter is functional. Change the water Replace the water in the outdoor spa pool. Clean the cover Clean the insulation cover. Change the filter Change the filter OY NORDIC SPA LTD | Tehdaskatu 7, 24100 Salo | www.novitek.fi... -
Page 20: Screen Error Messages
DO NOT ENTER THE WATER! The water A pump may be stuck on The pump will not turn off. may have overheated. Turn off power to the pool and contact your service agent. OY NORDIC SPA LTD | Tehdaskatu 7, 24100 Salo | www.novitek.fi... -
Page 21: Standard (Tp500)
PLEASE NOTE! The actual water temperature will not be shown until the pump has run for at least two minutes. OY NORDIC SPA LTD | Tehdaskatu 7, 24100 Salo | www .novitek .fi... -
Page 22: Setting The Time
HOLD on the display. After this, press the WARM button . The display now reads HOLD | ING | FOR | 0:60 (the running timer shows the remaining time for which the pumps will be disabled). OY NORDIC SPA LTD | Tehdaskatu 7, 24100 Salo | www.novitek.fi... -
Page 23: Lower And Upper Temperature Ranges
CLEANING CYCLE The pool has an automatic preset cleaning cycle. The cleaning cycle starts when the pump has been turned off for at least 30 minutes. OY NORDIC SPA LTD | Tehdaskatu 7, 24100 Salo | www.novitek.fi... -
Page 24: Timed Messages
Replace the water in the outdoor spa pool. CLN | COVR Clean the insulation cover. CHNG | FLTR Replace the filter. CHEK | OZ If you have an ozonator, check that it is working correctly. SRVC | CHEK Carry out servicing measures. OY NORDIC SPA LTD | Tehdaskatu 7, 24100 Salo | www.novitek.fi... -
Page 25: Screen Error Messages
DO NOT ENTER THE WATER! The water STUK | PUMP | -- -- -- -- | The pump will not turn off. may have overheated. Turn off power to the pool and contact your service agent. OY NORDIC SPA LTD | Tehdaskatu 7, 24100 Salo | www.novitek.fi... -
Page 26: Sink Paneling
SUPPLEMENTARY HEATER An additional heater is standard for Ylläs pools of the Exclusive collection. The electrical installation of the additional heater can only be carried out by a licensed electrician, and it has to be done simultaneously to the electrical installation of the pool. The electrical connection of the additional heater must be protected with a ground circuit interrupter. -
Page 27: Controlmyspa™ Remote Control
FACTORY INSTALLED ACCESSORIES CONTROLMYSPA™ REMOTE CONTROL In the Exclusive hot tubs, CMS ™ remote control is always standard. You can use remote control to adjust the pool’s settings from anywhere and check the status and functions of the pool. The new generation of CMS™ remote control also sends notifications to your mobile phone about any issues with the pool. -
Page 28: Conditions For The Warranty's Validity
COMMERCIAL USE The Novitek pool is designed to withstand normal use. For pools installed for commercial or rental use, the warranty is limited and specified on a case-by-case basis. If the commercial use is not mentioned when the order is placed and the warranty is not separately agreed upon in the order, the warranty for the products is three (3) months from delivery. -
Page 29: Warranty Measure
Oy Nordic SPA Ltd. The service representative must have free access to each side of the pool. Expenses due to demolition of a terrace or other built foundation, removing or reinstalling of the pool are invoiced to the buyer. - Page 30 OY NORDIC SPA LTD | Tehdaskatu 7, 24100 Salo | www.novitek.fi...
- Page 31 OY NORDIC SPA LTD | Tehdaskatu 7, 24100 Salo | www.novitek.fi...
- Page 32 OY NORDIC SPA LTD Tehdaskatu 7, FI-24100 Salo, Finland +358 2 737 270 www .novitek .fi...
