User manUal
VILLEGGIO NG-TRX sERIEs
Multi-functional hybrid control units
for intrusion detection systems
ULTRABUS
advanced serial bus
1
GENERALs
VIDOMO2K, VICOMPACT2K are multi-functional hybrid con-
trol units supporting both wired and wireless devices.
Control units are compatible with
• wireless devices of NG-TRX series;
• wireless devices of the first Villeggio series.
VIDOMO2K is also compatible with all EL.MO. devices (key-
pads, readers, power groups, security fog systems, concen-
trators and single detectors) thanks to ULTRABUS interface.
Optional modules can be installed to improve unit operating
mode.
It is also possible to connect to e-Connect with the installa-
tion of suitable modules.
VIDOMO2K, VICOMPACT2K are supplied in a plastic housing.
All control units are protected against the cover opening
and removal from wall.
Icons used in this manual
▼ Example of messages on keypad display
21,4°
+21,7°
▼ Keys typing
®
01/06/18
09:00
Area 1
▼ Usage example
Manual contents
▼ Keypads usage → chap. 2 p. 2
Operating mode from keypad → par. 2.4 p. 6
Operation with proximity keys → par. 3.2 p. 14
Operation with remote controls → par. 4.2 p. 15
▼ Chronothermostat usage → chap. 7 p. 18
▼ GPs control → chap. 8 p. 20
▼ Use of e-Connect → chap. 9 p. 21
▼ Maximum security property → chap. 10 p. 22
▼ Remote interrogation and remote
control → chap. 11 p. 23
▼ system test → chap. 12 p. 27
▼ Anomalies diagnostics → chap. 13 p. 27
1 1 1
Advertisement
Chapters
Table of Contents
Summary of Contents for El.Mo VILLEGGIO NG-TRX Series
-
Page 1: Table Of Contents
• wireless devices of the first Villeggio series. ▼ Keypads usage → chap. 2 p. 2 VIDOMO2K is also compatible with all EL.MO. devices (key- Operating mode from keypad → par. 2.4 p. 6 pads, readers, power groups, security fog systems, concen- ▼... -
Page 2: Keypads Usage
KEYPADs UsAGE Key status Indication All sectors associated to the key VILLEGGIO NG-TRX control units are multi-area devices ca- are disarmed pable of managing up to 16 sectors. All sectors associated to the key During unit setup, sectors can be divided into: are armed •... -
Page 3: Fri
Acoustic signalling for tampered zones The unit can be configured to emit a single or continued acoustic signal ("Din Don") when one or more zones are in anomaly condition. 2.2 Displayed information The built-in keypad can control one (or more) pertaining area(s) and can display its status. -
Page 4: Area 1
Backlight e-Connect connection status Status of e-Connect service connection. The display backlight will change according to operating i = e-Connect connection active mode. but unregistered unit. To save energy, the display will be switched off automatical- = unit connected via Ethernet ly after 1 minute inactivity or in case of power cut. -
Page 5: User Menu
01/06/18 01/06/18 21,4° 09:00 21,4° 09:00 +21,7° +21,7° Area 1 Area 1 Disarmed Disarmed SELECT AREA Area 1 (0-4 Ok Stop) System Status ZONES STATUS (↑↓ Ok Stop) – Press arrow keys ↑ or ↓ while the interface is in idle 01/06/18 mode. -
Page 6: Sim Balance Status
– Go to ALM/TAMP. MEMORY. exit path. After system arming, users can leave the premis- – Press OK to enter the menu item. es within a set time (exit time) through the exit path without – Use arrow keys ↑ or ↓ to browse the reports. triggering an alarm event. -
Page 7: System Arming With Sectors Selection - 4 Areas
2.4.3 system arming with sectors selection - 4 areas / 4 sectors mode The unit features an advanced arming procedure that allows the manual selection of sectors to be armed among the sec- tors proposed to the user. With 4 areas / 4 sectors mode, each sector key is associated to a sector distinctively. -
Page 8: Fast Arming - 4 Areas / 4 Sectors Mode
16 sectors mode At the end of exit time, sectors proposed will be armed (sector keys remains lighted unless the option Hide arming state is Arm: 123--67-9AB----G enabled). During key blinking (pre-arming time, around 5s), it is possi- Armed status will be displayed. ble to change sectors proposed either per single sector, or per sectors group. -
Page 9: Fast Arming - 8/16 Sectors Per Area Mode
– If an exit time has been set, leave the protected areas within the set time. The procedure will be cancelled if you press the key of a sector that cannot be armed. 2.4.6 Fast arming - 8/16 sectors per area mode –... -
Page 10: Enter User Menu On Keypad
the installer code will be required to force system arming: 01/06/18 21,4° 09:00 INSTALLER CODE: +21,7° Area 1 -------- Disarmed The installer authorisation is required also when arming the system with a remote control or a M4 key that is not associ- ated to the keypad. -
Page 11: Zones Bypass
→ PHONE NUMBERS - § 2.5.11 p. 13 – Press 2 (=Img.) repeatedly to change authorisation to → CHANGE CODE - § 2.5.12 p. 13 visualise user images in BrowserOne: → SYSTEM TEST - § 2.5.13 p. 13 ▼ NONE → MANAGE CHIME - § 2.5.14 p. 13 The installer cannot view the images. -
Page 12: Clock Calibration
2.5.6 Clock calibration Monday Prog. Use this menu to manually adjust the difference in time oc- curred over a month between the control unit clock and the standard one. – Use arrow keys ↑ or ↓ to go to CLOCK CALIBR. option. (↑↓... -
Page 13: Proximity Keys Usage → Chap. 3 P
access denied). The suspension can be set through ready to test the following zone. weekly programmer too. However, setup from keypad – Repeat the previous step for all zones displayed. has priority over other settings. – Once the test is completed, press STOP to exit test step. –... -
Page 14: Readers Type
IZENITH The keys shall be registered to the control unit. The following paragraph shows some examples of readers that can be installed in the system. Readers installable on ULTRABUS serial line are only com- patible with VIDOMO2K unit. Verify the compatibility of the reader with the unit model purchased. -
Page 15: Remote Controls Usage → Chap. 4 P
pertaining areas. If the time interval elapses without the confirmation of the system disarming, a duress alarm related to the user that disarmed will be created. 3.2.4 system forced arming If the option Activate Arming Lock in BrowserOne is active, –... -
Page 16: Gsm And Phone Communications → Chap. 5 P
key/remote control/remote access codes) the event Maximum access attempts exceeded will be generat- ed. More consecutive access attempts with the same code will be counted as one. Access attempts with remote controls will be counted only if remote controls antiscramble function is active. –... -
Page 17: Temperature Monitoring → Chap. 6 P
TEMPERATURE MONITORING • from keypad (MANAGE SIM BAL. in user menu) details VILLEGGIO NG-TRX series units are equipped with a tem- at: 2.5.4 p. 11 perature detector measuring the temperature inside the • via SMS (texts C.OFF / C.ON messages) details at: housing. -
Page 18: Temperature Thresholds
It is required the installer has set one output with Control of A-B temperatures function associated to a CHRONOTHERMOsTAT SX sector key. VILLEGGIO NG-TRX series units feature Chronothermostat function for boilers control. Reset from keypad The working mode can be daily or weekly based. -
Page 19: Chronothermostat Status Change
– Press OK TEMPERATURE Programm.:+18,2° 01/06/18 Modify:+18,5° 21,4° 09:00 (↑↓ 1=On/Off Ok) +21,7° • active - automatic: the chronothermostat will control boiler activation according to setup Boiler ON icon (blinking when boiler is blocked) TEMPERATURE Time intervals temporary temperature change (arrow UP: increase; arrow Programm.:+18,2°... -
Page 20: Boiler Control
Intervals changed will blink. TEMPERATURE A triangle will appear above current time interval. The tri- Programm.:+18,2° angle will point upwards if the temperature has been in- Manual:+18,5° creased, downwards if it has been decreased. (↑↓ 1=On/Off Ok) To cancel the temporary change of temperature reset it to setup value. -
Page 21: Periodic Coordinates Communication
2.3 p. 5 . E-CONNECT Periodic coordinates communication e-Connect is a supervision software for EL.MO. intrusion de- The unit can be set to send SMS texts with its position data. tection systems. Data can be sent automatically, upon GPS alarms or with e-Connect allows users to control and manage their systems remote interrogation by the user. -
Page 22: Max Security
01/06/18 21,4° 09:00 +21,7° Area 1 Disarmed (default: 111111) SELECT SECTORS Area 1 For the correct use of the software, units have to be equipped S1 S2 S3 S4 with one of the following modules: • MDLAN – key in user code •... -
Page 23: Remote Interrogation And Remote
disarming is performed via weekly programmer Max Disarming made by user with Max Security Reset function, the sector property will be re- Security set and the sector can be armed in the standard way. Disarming made by weekly programmer The following icons indicate sectors arming status: without Max Security Sector disarmed, no Max Security Disarming made by weekly programmer... -
Page 24: Sms Structure
The command sent will be accepted only if sent by a I.ON Arm areas / sectors authorised number on the unit phone number list. I.P1 Arm sectors proposed I.P2 Arm sectors authorised but not the proposed ones 11.1 sMs structure I.OFF Disarm areas / sectors authorised SMS text shall be in the following form:... -
Page 25: Zones Report
11.2.4 Anomalies report ▼ PANEL FULLY ARMED All sectors authorised for the user are armed. The control unit replies with SMS texts containing anomalies ▼ PANEL PARTIALLY ARMED information, one text per each zone pertaining to the user. Some sectors authorised for the user are armed (but not all). -
Page 26: Gps Position Report
Replying sMs 11.3.1 Arm/disarm commands ▼ +/- XX,X degrees The command affects all sectors authorised for the user. Temperature detected (if single). The control unit will reply with one SMS per each area au- ▼ ext. +/- XX,X degrees, int. +/- XX,X degrees thorised for the user: Temperature values detected (outdoor and indoor). -
Page 27: Bypass/Include Zone
Replying sMs ▼ sIM BALANCE READING ENABLED Reading enabled. ▼ out. [name] ENABLED ▼ C.DENIED The output is active. Reading disabled or the user is not authorised for ▼ out. [name] DIsABLED Small Maintenance. The output is not active. ▼ A.DENIED sYsTEM TEsT Output activation is not allowed or the user is not au- thorised for Small Maintenance. - Page 28 UsE ON VEHICLE/MEAN ANOMALY Mains failure: the unit is powered by the battery OF TRANsPORT Mains Failure only. ANOMALY Phone line not detected or absent. The unit can be used to protect a vehicle/mean of transport Tel. Line Fault or boat ANOMALY SIM card missing or disabled, or PIN code active.
- Page 29 Table of contents GENERALS ......P. 1 GSM AND PHONE COMMUNICATIONS..P. 16 Calls reception .
- Page 30 SYSTEM TEST ......P. 27 DIAGNOSTICS......P. 27 ENERGY SAVING .
- Page 32 The information and product features herein are not binding and may be changed without prior notice. EL.MO. Spa - Via Pontarola, 70 - 35011 Campodarsego (PD) - Italy Ph. +39 049.9203333 - Fax +39 049.9200306 - Help Desk +39 049.9200426 - www.elmospa.com - international@elmospa.com...
