OWNER'S MANUAL
TRINITY BASICS® 3-Tier NSF 60" x 24" x 58" Wire Shelving w/Wheels
Model # TBTZ-0970 / TBFPBK-0970
Important / Important / Importante
FOR 3D ASSEMBLY INSTRUCTIONS
Intelligent Instructions
Directives intelligentes
POUR DES DIRECTIVES D'ASSEMBLAGE 3D
Instrucciones Inteligentes
PARA INSTRUCCIONES DE ENSAMBLAJE EN 3D
DOWNLOAD THE FREE APP | TÉLÉCHARGER L'APPLICATION GRATUITE | DESCARGUE LA APLICACIÓN GRATUITA
Advertisement
Table of Contents
Related Manuals for Trinity Basics TBTZ-0970
Summary of Contents for Trinity Basics TBTZ-0970
- Page 1 OWNER’S MANUAL TRINITY BASICS® 3-Tier NSF 60" x 24" x 58" Wire Shelving w/Wheels Model # TBTZ-0970 / TBFPBK-0970 Important / Important / Importante FOR 3D ASSEMBLY INSTRUCTIONS Intelligent Instructions Directives intelligentes POUR DES DIRECTIVES D’ASSEMBLAGE 3D Instrucciones Inteligentes PARA INSTRUCCIONES DE ENSAMBLAJE EN 3D...
-
Page 3: Parts List
PARTS LIST Your TRINITY BASICS® 3-Tier NSF 60" x 24" x 58" Wire Shelving w/Wheels should include the following parts. Please inspect box contents to ensure you have received all components. If you are missing any parts, need assistance with assembly or have questions, please contact TRINITY Customer Service: 800.985.5506 or customerservice@trinityii.com. - Page 4 ASSEMBLY INSTRUCTIONS STEP 1 Mobile Option B (4) E (2) F (2) G (1) H (4) Screw each CASTER (E & F) into bottom of each BOTTOM POLE (B). Turn clockwise to screw in place. Make sure Locking Casters are on the same side. Warning: Use provided WRENCH (G) to tighten CASTER (E &...
- Page 5 Make sure SHELF (C) corner cylinders are positioned over SLIP SLEEVES (D). Stand the unit upright. Note: • Level side of SHELF (C) is TOP side (TRINITY BASICS logo on corner cylinders should be right-side up.) • Use a rubber mallet, if needed, to secure SHELF (C).
- Page 6 ASSEMBLY INSTRUCTIONS STEP 5 On POLE (A+B), place 1 pair of SLIP SLEEVES (D) at desired height. Make sure C (2) D (16) arrow faces up and word “TOP” is right side up. Do this for each POLE (A+B) and make sure height is identical for each POLE (A+B). Lower SHELF (C) over each POLE (A+B) so corner cylinders of SHELF (C) are positioned over SLIP SLEEVES (D).
-
Page 7: Service Parts List
SERVICE PARTS LIST – TBTZ-0970 (Chrome) TRINITY Customer Service provides the following replacement parts: Part Number Description Part Number Description XBK-01-011-2543 Slip Sleeve ZSV-99-008-4010 Locking Caster ZSV-04-006-2650 Top Pole XBK-98-003-2538 Feet Leveler ZSV-01-013-2523 Pole Connector ZSV-99-007-4010 Non-locking Caster ZSV-04-042-2650 Bottom Pole... - Page 8 SERVICE PARTS LIST – TBFPBK-0970 (Black) TRINITY Customer Service provides the following replacement parts: Part Number Description Part Number Description XBK-01-012-2543 Slip Sleeve ZSV-99-008-4010 Locking Caster PBK-04-006-2650 Top Pole XBK-98-003-2538 Feet Leveler ZSV-01-013-2523 Pole Connector ZSV-99-007-4010 Non-locking Caster PBK-04-042-2650 Bottom Pole XBK-23-004-2517 End Cap XXX-97-002-0001...
-
Page 9: Care And Maintenance
WARNINGS 1. Read and understand all instructions. Failure to follow all instructions may result in injury and / or damage. 2. Tighten all casters completely by using the wrench. Failure to do as instructed could result in the caster stem breaking, thereby causing the product to collapse. 3. -
Page 10: Product Registration
PRODUCT REGISTRATION Thank you for purchasing a TRINITY BASICS® 3-Tier NSF 60" x 24" x 58" Wire Shelving w/Wheels. In order to register your product and receive streamlined customer service, please fill out the following Product Registration Form and (1) fax the form to 310.347.4134 (2) complete the Product Registration Form online at www.trinityii.com or (3) scan and email the form to customerservice@trinityii.com. -
Page 11: Year Limited Warranty
Trinity International Industries (“Trinity”) warrants to the original consumer purchaser (“Purchaser”) of the TRINITY BASICS® 3-Tier NSF 60" x 24" x 58" Wire Shelving w/Wheels (“Product”) that each Product shall be free from defects in workmanship and materials for a period of 1 year from the date of original purchase. - Page 12 CONTACT US QUESTIONS? NEED PARTS? WE ARE HERE TO HELP! Please feel free to contact us. There are no questions too small, or any problems too big. We’re committed to providing our customers with the highest level of service. TRINITY Customer Service TEL: 800.985.5506 FAX: 310.347.4134 EMAIL: customerservice@trinityii.com...
