Summary of Contents for Spin Twin-Spin 17
- Page 1 OPERATOR MANUAL/PARTS LIST - MODELS 201400, 201300 THIS MANUAL IS FOR MACHINES STARTING WITH SERIAL NUMBER 1126070 MANUFACTURING Box 47174 Minneapolis, MN 55447 612/475-9896 - Phone 612/475-9721 - Fax 18 - FORM NO. 041332 / TWIN SPIN 17/20...
- Page 2 Shipping Weight (w/pad holder) 90 lbs (41 kg) 94 lbs (43 kg) Construction: Handle Tube Extruded Steel Extruded Steel Upper Handle Injection Molded Nylon Injection Molded Nylon Base Roto Molded Polyethylene Roto Molded Polyethylene 20 - FORM NO. 041332 / TWIN SPIN 17/20...
-
Page 3: Table Of Contents
PREPARING THE MACHINE FOR USE........7 OPERATING CONTROLS ............8 OPERATION................9 AFTER USE ................10 TROUBLESHOOTING ............11 HANDLE SYSTEM ............12-13 BASE SYSTEM ..............14-15 WIRING DIAGRAM ..............15 SOLUTION TANK KIT (OPTIONAL)......... 16-17 FORM NO. 041332 / TWIN SPIN 17/20 - 1... -
Page 4: Introduction
INTRODUCTION This manual will help you get the most from your Twin Spin Floor Machine. Read it thoroughly before operating the machine. This product is intended for commercial use; polishing, spray buffing, scrubbing, stripping and rotary carpet shampooing. PARTS AND SERVICE Call the DEALER named below for repair parts or service. -
Page 5: Important Safety Instructions
Do not use near flammable or combustible liquids such as gasoline or use in areas where they may be present. Connect to a properly grounded outlet only. See Grounding Instructions. SAVE THESE INSTRUCTIONS FORM NO. 041332 / TWIN SPIN 17/20 - 3... -
Page 6: Importantes Mesures De Sécurité
Ne brancher qu’à une prise de courant avec mise à la terre. Voir les instructions visant la mise à la terre. CONSERVER CES INSTRUCTIONS 4 - FORM NO. 041332 / TWIN SPIN 17/20... -
Page 7: Grounding Instructions
Extension cords connected to this machine should be 12 gauge, three-wire cords with three-prong plugs and outlets. DO NOT use extension cords more than 50 feet (15 m) long. FORM NO. 041332 / TWIN SPIN 17/20 - 5... -
Page 8: Machine Assembly
"C" is facing up as shown. down and released by pulling up. NOTE: To eliminate any slippage, tighten nut “G”. This part "H" comes assembled with the base housing. Plug these (2) power cords together. 6 - FORM NO. 041332 / TWIN SPIN 17/20... -
Page 9: Preparing The Machine For Use
To remove brush/pad holder, give it a quick, hard turn clockwise. Lugs Slots CAUTION! Using the wrong brush or pad on this machine can damage the floor or overload the motor. FORM NO. 041332 / TWIN SPIN 17/20 - 7... -
Page 10: Operating Controls
Operator Handle Grips Switch Lever Safety Lock Button Switch Levers - Squeeze - ON / Release - OFF “Kwik Lok” Handle Adjustment Lever Power Cord Operator Handle LO/HI Speed Selector Switch 8 - FORM NO. 041332 / TWIN SPIN 17/20... -
Page 11: Operation
NOTE: When spray buffing, check the pad every 15 minutes for dirt and wax build-up. If the pad is dirty, turn it over to expose the clean side or install a clean pad. FORM NO. 041332 / TWIN SPIN 17/20 - 9... -
Page 12: After Use
Inspect the entire machine and all accessories for damage. Perform any required maintenance or repairs before storage. Store the machine in a clean, dry place with the Handle locked in the upright position. 10 - FORM NO. 041332 / TWIN SPIN 17/20... -
Page 13: Troubleshooting
• Warped block on brush or padholder - replace. MACHINE DOES NOT RUN • Check plug for proper connection - on machine and at wall outlet. • Check building circuit breaker. • Call for service. FORM NO. 041332 / TWIN SPIN 17/20 - 11... - Page 14 FRONT 12 - FORM NO. 041332 / TWIN SPIN 17/20...
-
Page 15: Handle System
Latch Arm 201029 201031 Button, Lock 201032 Cord Set 14/3 x 50' 201033 Cord Assembly 14/3 201034 Switch, N.O. SPST Snap 015852 Decal, Spin 002292 Scr, Pan Phil 1/4-20 x 1.00 FORM NO. 041332 / TWIN SPIN 17/20 - 13... - Page 16 FRONT 14 - FORM NO. 041332 / TWIN SPIN 17/20 revised 11/98...
-
Page 17: Base System
NOTE: Pad Holders and Brushes come complete with Industry Standard NP-92 Clutch Plate. 120Vac WIRING DIAGRAM Item Part No. Qty Description 201034 Switch, N.O. SPST Snap 377003 Switch, Rocker 201330 Motor Assembly, 2 Speed FORM NO. 041332 / TWIN SPIN 17/20 - 15 revised 11/98... -
Page 18: Solution Tank Kit (Optional)
FRONT 16 - FORM NO. 041332 / TWIN SPIN 17/20... - Page 19 Tank, Solution 201035 Barb, Adapter 3/8 x 3/4 NPT 201036 Hose, PVC 201047 Wsh, Sealing SS 5/16 352829 Clamp, Hose SAE #52 370711 Nut, Thumb 379170 Spring, Compression 745550 O-Ring 201061 Washer FORM NO. 041332 / TWIN SPIN 17/20 - 17...
- Page 20 © Printed in U.S.A. 03/96 Form Number 041332 FORM NO. 041332 / TWIN SPIN 17/20 - 19...
