Summary of Contents for MCS edito KSM Series
- Page 1 KSM User Manual Version: 1.1 24.4.2019 Release date: MCS Micronic Computer Systeme GmbH Geneststraße 5, Aufgang D, 10829 Berlin – Germany...
- Page 2 Adjust tension unit to paper roll position Copyright: This manual is the property of MCS. All rights are reserved. Without the expressed permission of MCS, no part of this manual may be reproduced, processed, copied or distributed. Contact: Technical support: Seiko Instruments Siemensstraße 9...
-
Page 3: Table Of Contents
Contents: INTRODUCTION ....................5 SAFETY PRECAUTIONS ..................5 Handling precautions ...................... 6 Procedures to take when in trouble .................. 7 OPERATING PRECAUTIONS ................. 8 PREPARATION ....................11 Optional accessories ...................... 12 Overview Part Description ....................13 Start-up ......................14 Install paper roll core to paper arm ................. 14 Adjust roll core on paper width .................. - Page 4 Presenter & Retract Module ................... 25 8.4.1 Retract Function ..........................26 8.4.2 Function internal print ........................27 8.4.3 Function Ejection ..........................27 Paper Holder with flex paper channel ................28 Paper arm ........................29 Black mark- und Paper end sensor (LS14&LS5) ..............30 Paper near end Sensor (LS7) ..................
-
Page 5: Introduction
INTRODUCTION This manual describes how to handle edito KSM thermal printers (hereinafter referred to as printer), specified AC adapters, specified AC cables, and other accessories. Read through the "2. SAFETY PRECAUTIONS" and "3. OPERATING PRECAUTIONS" carefully before using the printer, and handle it safely and properly. Keep this manual in a place where it can be accessed quickly. -
Page 6: Handling Precautions
Handling precautions DANGEROUS If following instructions are not followed, this leads to fire, electric shock or to an accident. Do not insert any foreign objects such as a piece of metal or any liquid into the products. Do not touch the metal parts of the terminal, AC plug, and DC plug. To avoid short circuits, prevent terminals of the products, AC plug, and DC plug from touching any conductor such as metal. -
Page 7: Procedures To Take When In Trouble
Procedures to take when in trouble Follow the instructions in the cases below. Failure to follow the instructions may lead to fire, electric shock, or accident. In the following cases you switch off the electricity supply and you pull the power supply unit from the outlet: ◆... -
Page 8: Operating Precautions
OPERATING PRECAUTIONS Follow the precautions below to use the printer properly in order to deliver and maintain the full perfor- mance of the printer. Using the Printer ◆ Be careful not to drop or bump the printer on a hard surface. ◆... - Page 9 ◆ DO NOT drop or insert any foreign objects such as a clip, a pin, or a screw in the internal parts or slot of the printer. ◆ DO NOT drop any liquid or spray a solvent to the printer. ◆...
- Page 10 Cleaning the thermal head The thermal head should be cleaned from time to time, to keep the surface of the thermal-head-line free from paper dust and other particles (e.g. small paper snippets) to get a good heat transfer from heat elements to the paper.
-
Page 11: Preparation
PREPARATION When you open the carton, make sure it contains the printer and its accessories. hex-wrench Quick Start guide (one sheet) edito printer KSM Depending on the model mounted with: Modul flex paper channel Paper arm & holder ... -
Page 12: Optional Accessories
Optional accessories edito cable MED W1 edito cable MED W3 RS232 USB cable (0,5m) power supply (1m) Power Supply Mounting plate (horizontal) inclusive power cable The models that include accessories, see ”7 Determination of the model type". BED0194 Edito printer KSM347 (english) Reference:... -
Page 13: Overview Part Description
Overview Part Description Paper width adjustment Sensor PAPER NEAR END roll core unlock button Roll core paper Printhead flap Paper input guide flap Paper arm adjustment Bezel LED green illuminated roll core positions from paper Paper output Button test ticket Button paper feed Status LED red Paper width... -
Page 14: Start-Up
Start-up ! Thermo-sensitive layer outside! Install paper roll core to paper arm Mount the axis according to your paper roll outer diameter. Diameter of the Paper roll Axis of paper roll core Diameter of the paper roll >130mm Diameter of the Paper roll ≤130mm Adjust roll core on paper width Slide the paper core in the paper roll. -
Page 15: Attach Paper Arm
Attach paper arm The paper arm is separately in the package and must be attached to the paper guide on the two screws. The paper arm can be mounted on the paper guide left or right. This makes it possible to insert the paper roll from the left or right. -
Page 16: Maximum Paper Roll Radius Depends Of Paper Arm Position
Maximum paper roll radius depends of paper arm position Additional information about position paper roll on the paper arm. Arm position Paper roll Position B Paper roll Position A Mounting surface also behind printer on paper roll position 40mm 40mm 70mm 90mm 80mm... -
Page 17: Paper Width Setting On The Paper Guide
Paper width setting on the paper guide About a screw in the center the paper guide is adjusted. Loosen the screw only about a half turn. Important: Do not remove this screw completely! Load paper and the slot to the paper width a-judge. The paper should have about 0.5mm play on each side. -
Page 18: Wiring
Wiring For connect power on the printer, first connect the printer with the power supply and after this, turn on the power supply. Power supply ±5% Power PAPER NEAR END connec- 230V AC tion left or right Power supply 230V/24DC 90W ... -
Page 19: Adjust Tension Unit To Paper Roll Position
5.10 Adjust tension unit to paper roll position The tension unit separate by start of printing the first inertia torque of a bigger paper roll from the printing unit (by using a spring). This is important to get a good print quality. Default setting is the paper comes from the top. -
Page 20: Position Of Buttons And Led
(paper from top) (paper from bottom) [11] (check of same position of the spring left and right side) Position of buttons and LED Button Button test ticket paper feed LED1 LED2 Button Status LED red Button Bezel light paper feed test ticket green Button Test ticket &... -
Page 21: Determination Of The Model Type
Determination of the model type Overview modules printing unit modul Paperarm&holder edito modul flex paper channel edito printer KSM-3470 Bezel Electronic standard Connections Buttton (2x) LED (2x) edito USB Modul output control Serial Modul presenter Electronic Ethernet Option (additional) ... -
Page 22: Printer Mounting Variations
printer mounting variations modelname mounting position edito printer KSM347-x horizontal / vertical* edito printer KSM347O- x only horizontal edito printer KSM347P- x only horizontal edito printer KSM347R- x only horizontal x = Interface selection * paper out on top area only, if paper cannot fall back into the printer after cut. vertical * every angle to only horizontal... -
Page 23: Parts Of The Printer
Parts of the Printer Overview Motor & Sensor Systems edito printer KSM without Output control This is the simplest model. The printed document falls into a tray. No additional part for further transport and paper guiding of the paper in front of printing mechanism. Normally this model is also equipped with flex paper channel and paper arm &... -
Page 24: Paper Output Module
Paper Output Module The way of the paper is monitored after printing continuously with sensors up to the bezel. If the paper output is hindered, the paper forms a loop upwards, moves a flap and printing will be stopped. If the paper way is free again, the flap falls back and it is further printed. -
Page 25: Presenter & Retract Module
Presenter & Retract Module This describes two different module: 1 Presenter module KSM347P 2 Retractor module KSM347R (is including presenter) For module KSM347P/R: The ticket is held after printing inside the Presenter module. Two optical sensors detect the exact position of the ticket. Is the first edge of the ticket before or after the counter rolls? Function: If a ticket is printed and the first edge is short before the counter rolls (LS1), the drive roller begins to turn so long as LS2 detect the ticket edge. -
Page 26: Retract Function
8.4.1 Retract Function Only for Retract Version KSM347R: For the present function, it is the same functionality as for the Presenter module. The Retract module has the same size as the Presenter module, so you can install easily one type or the other type in the same application. -
Page 27: Function Internal Print
8.4.2 Function internal print Only for Retract Version KSM347R. For internal printing, the mechanical switch plate (called switch) is driven by motor and open the paper channel to print direct in the collection basket under the printer. After printing, the switch comes back under it’s own weight. -
Page 28: Paper Holder With Flex Paper Channel
Paper Holder with flex paper channel The paper holder with flex paper channel is inserted into a horizontal slot at the back of the printer. From the bottom of the printer, the bracket is firmly fixed through a spacer bolt. This will also be used to securely fix the complete printer on the base plate. -
Page 29: Paper Arm
Paper arm The whole paper arm can be mounted on the right as well as on the left side to the flex paper channel. For change, remove 2 screws (A) (see also 5.3 Attach paper arm) and mount the arm at the opposite side with the same screws. -
Page 30: Black Mark- Und Paper End Sensor (Ls14&Ls5)
Black mark- und Paper end sensor (LS14&LS5) Inside the holder is a black mark sensor (LS14) and a paper end sensor (LS5) integrated. The Black mark must be on the ticket backside. Sensitive wavelength 700 to 1200nm The reflectivity should be <4%. Here Print direction Thermal sensitive layer... -
Page 31: Paper Near End Sensor (Ls7)
Paper near end Sensor (LS7) The paper near end sensor can be adjusted infinitely in the paper arm for setting when the paper near end status signal will be generated. Put the sensor not too near to the role end, so that swing of the role cannot release the signal uninten- tionally. -
Page 32: Connectors
Connectors Plug Position Pin1 24V Pin2 GND Power supply (X1) Pin assignment 2 pole Molex 4.2MM (MoNr. 39-01-3022) Name Remark (Printerside) +24V Power supply Interface USB (X2) Pin assignment USB Type B (MoNr. 0670688010) Name Remark (Printerside) 5Volt USB-on shield BED0194 Edito printer KSM347 (english) Reference:... -
Page 33: Interface Rs232 (X3)
Interface RS232 (X3) With the Pin5 the printer can be switched off completely. If the input is ON / OFF is set to GND potential, the printer is off and used <mA at 24V. The inputs and outputs are standard RS232 level. Pin Assignment Modular Connector RJ-12 Name Remark (Printerside) -
Page 34: Interface Black Mark Sensor On Paper Holder (X16)
Interface Black mark sensor on paper holder (X16) Interface 5 pole SH JST SHR-05V-S-B) Name Remark (Printerside) LS14 Power supply Signal from the edito printer (Output) Black mark sensor LS14 black mark Signal to the edito printer (Input) LS5 Power supply Signal from the edito printer (Output) Paper end LS5 paper end... -
Page 35: Sideview
10.2 Sideview Thermal sensitive layer outside BED0194 Edito printer KSM347 (english) Reference:... -
Page 36: Paper Eject Position Edito Printer Ksm347-S/U
10.3 Paper eject position edito printer KSM347-S/U Paper eject position BED0194 Edito printer KSM347 (english) Reference:... -
Page 37: View Up And Down
10.4 View up and down screw depth 4mm (2x) BED0194 Edito printer KSM347 (english) Reference:... -
Page 38: Mounting Plate
10.5 Mounting plate BED0194 Edito printer KSM347 (english) Reference:... -
Page 39: Technical Specifications
Technical specifications 11.1 General Printer driver Windows7 (32/64Bit) Windows8 (32/64Bit) Windows10 (32/64Bit) Emulation ESC Sequenzen 11.2 Interface RS232 115200 Baud (optional other) Ethernet 10Base-T/100Base-TX autonegotiation (optional) 11.3 Memory Reserved for users: User memory 512 KB (reserved in FLASH) BED0194 Edito printer KSM347 (english) Reference:... -
Page 40: Printer Unit
11.4 Printer unit Parameter KSM347 KSM347O KSM347P KSM347R Print engine Seiko CAPM347 series thermal mechanism Print methode Thermal dot line printing Printer main function print and cut push /pull detect cut presenter presenter and retractor Internal print not possible possible (without show ticket outside) Dots / line (max,) Resolution (dots/mm) - Page 41 Mark detection level test Integrated in flex paper channel and adjust Printout Emulation Software for development, maintenance and ticket emulation included Interfaces Standard model Serial / USB Inerfaces Ethernet model Serial / USB / Ethernet RS232 Specification fix115.200 Bd, 8 databits, no parity,1 stop bit (Xon/Xoff) (RTS/CTS) Connector RJ-12 USB Specification USB 2.0 Connector Type B Ethernet Specification...
-
Page 42: Thermal Paper
11.5 Thermal paper Specified paper variety: 76 g / m² KLS 48 / T8047 Execution: the outside layer Sleeve diameter: 25 mm Roll diameter: max. 180 mm Roll length: 280 m (Supplier: Diagramm Halbach A.No.A0111959) The function test were carried out with the KLS 48 and T8047 papers. The Print engine itself but has been tested with the following papers. -
Page 43: 11.5.1 Setting The Print Density
11.5.1 Setting the print density Print density regarding default paper in range 70-120 (%), default 100 (%), determine this setting at 25° Celsius. This settings can done with the ePOSConfig program or by driver setup. Refer edito pro- gramming or driver manual. Print density negative temperatures factor regarding default paper in range 40-90 (%), default 60 (%). -
Page 44: Power Consumption
11.6 Power consumption Power supply: 24V ±5% Current: 3,7A @ 128 Dot 1,0A @ 10% Dot Standby: typ. 82mA in standby at 24V (LED on) typ. 70mA in standby at 24V (LED off) 11.7 General environment Operating temperature range: -20°C to 70°C non condensing (Depending on the used thermal paper) Storage temperature range: -25°...
