User manual

Lefant LT1 Mopping Robot

FCC ID:2AZ2R-LT1

FCC ID:2AZ2R-J2

Table of Contents

Need help?

Do you have a question about the LT1 and is the answer not in the manual?

Questions and answers

Summary of Contents for lefant LT1

Page 1 User manual Lefant LT1 Mopping Robot FCC ID:2AZ2R-LT1 FCC ID:2AZ2R-J2...
Page 2 Should you encounter situations that have not been properly addressed in this User Manual, please contact our Customer Service Center, we will solve your speciﬁc problem.For more information, please visit the Lefant ROBOTICS ofﬁcial website: www.lefant.com or send email to support@lefant.com.
Page 3 IMPORTANT SAFETY INSTRUCTIONS WARNING: Read all safety warnings and instructions. Failure to follow the warnings and instructions may result in electric shock, ﬁre or serious injury. READ ALL INSTRUCTIONS BEFORE USING THIS APPLIANCE. For Household use only When using an electrical appliance, basic precautions should always be followed, including the following: 1.
Page 4 21. Do not use the base station if it is damaged. modiﬁed batteries may exhibit unpredictable behavior resulting in ﬁre, 22. Do not use the robot or the base station if it is not working properly, explosion or risk of injury. has been dropped, damaged, left outdoors, or come in contact with water.
Page 5 SAVE THESE INSTRUCTIONS Short-circuit-proof safety isolating transformer To satisfy RF exposure requirements, a separation distance of 20 cm or more Switch mode power supply should be maintained between this device and persons during device operation. To ensure compliance, operations at closer than this distance is not recom- mended.
Page 6 Federal Communications Commission (FCC) Interference Statement This equipment has been tested and found to comply with the limits for a RF exposure warning Class B digital device, pursuant to Part 15 of the FCC Rules. This equipment complies with FCC radiation exposure limits set forth for These limits are designed to provide reasonable protection against harmful an uncontrolled environment.This equipment must be installed and interference in a residential installation.
Page 7: Table Of Contents
Contents · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 1.
Page 8: Product Introduction
1. Product introduction / 1.1 Packing list Robot Power cable Water tank User manual Lefant LT1 Mopping Robot Mop bracket Cleaner User manual Self-cleaning station *The picture of the manual is for reference only. The appearance should be subject to the actual manual.
Page 9: Part Name
1. Product introduction / 1.2 Part Name Front view Side view Power Switch dToF Laser Green at the bottom of the switch is on, Navigation Sensor Red at the bottom of the switch is off. Water tank Start/pause button Bumper Line laser sensors Line laser sensors Bottom view...
Page 10 1. Product introduction / 1.2 Part Name Self-cleaning station Clean water tank Display Screen Tank handle Back to wash button sewage tank Start/pause button Mode switch button Power Socket Charging electrode Water intake Cleaning tray...
Page 11 1. Product introduction / 1.2 Part Name Mopping Module Mop installation interface Handle...
Page 12: Preparation
2. Preparation / 2.1 Assemble and charge Install the mop Position the station/Connect power supply Remove the protective film Aim the mop at the installation interface. Revolve the shaft *Put the station in an open area. until it’s pressed in. A “click” sound indicates it’s in place. *Connect power supply and arrange the power cable.
Page 13: Using Environment Preparation
2. Preparation / 2.2 Using environment preparation Sort out the space to be cleared Tidy the items from the ground If the rug at home has tassels, like cables and slippers to keep put the tassels under the rug in the robot working advance.
Page 14: Using The Product
3. Using the product / 3.1 How to use robot buttons Start/pause button Single press: Start/Pause Double press: Automatic return and charge Press and hold for 3 seconds: Enter Wi-Fi pairing mode Robot status Start/pause button light indicator status Power ON White light on (Red light on when low power) Mopping White light on...
Page 15 3. Using the product / 3.2 How to use station buttons Button Icon Button Name How to use the button Single press: Robot returns to the station to wash the mop. Back to wash Press and hold for 3 seconds: Wash the mop instantly. button Start/pause button Single press: start/pause.
Page 16 Fill the clean water tank with cleaner Check the water tank and the cleaning tray Please use Lefant special cleaner to avoid machine malfunction. The machine can Install the clean water tank and the sewage tank into the station automatically add cleaners. Cleaners can be purchased and used on demand.
Page 17 3. Using the product / 3.3 Start mopping Recall the robot to the station Start mopping Short press to recall the robot to the station. Select the cleaning task. Press on the station. The robot starts to work. (If you put the robot into the station by yourself, please pay attention to (The robot starts to create a home map the ﬁrst time it works.
Page 18 3. Using the product / 3.3 Start mopping Check the clean water tank/ Sewage tank Mopping completed If you run out of water or the tank is full during the mopping process, the After the robot completes mopping and returns to the station, it will base station screen will display "Insufﬁcient clean water"...
Page 19 Method I : Scan the following QR code, and then download and install App as prompted. Lefant_2.4G Lefant_5G Method II : Search "Lefant" in the App store, download and install the Lefant app. Tips: * Follow the guidance in the Lefant app to register, login, and pair the robot.
Page 20: Maintenance Frequency
3. Using the product / 3.5 Maintenance frequency In order to maintain the peak performance of the product, it is recommended to perform accessories maintenance with reference to the following frequency: Accessory Maintenance frequency Replacement frequency Once every 1-2 months dToF laser navigation sensor Universal Wheel Anti-fall sensors...
Page 21 3. Using the product / 3.6 Maintenance * Unplug the station when performing cleaning and maintenance on the robot and its accessories. Bottom of the robot The mop 1. Clean the anti-drop sensor to ensure sensor sensitivity. 1. Tear off the old mop and remove it. 2.
Page 22 3. Using the product / 3.6 Maintenance * Unplug the station when performing cleaning and maintenance on the robot and its accessories. Cleaning tray for the station 1. Hold the cleaning tray handle with both 2. Take out the cleaning tray and rinse 3.
Page 23: Abnormal Symptoms
4. Abnormal symptoms / 4.1 Troubleshooting If the following problems occur during the use of the product, you can cross-reference them and solve them independently. Fault Possible causes Solutions Mop bracket is tangled. Clean up foreign objects. Poor cleaning ability. The mop is worn.
Page 24: Troubleshooting
4. Abnormal symptoms / 4.1 Troubleshooting If the following problems occur during the use of the product, you can cross-reference them and solve them independently. Fault Possible causes Solutions Find the saved map in “Map Management” of the APP, and try to restore it by clicking "Use There may be a risk of losing the map when Map lost.
Page 25: Technical Parameters
5. Technical parameters Product model Rated input of Robots Charging time ≤ 3.5 hours LT1 Self-cleaning station Self-cleaning station models Rated input (state of charge) 100-240V~ 50/60Hz, Max 0.55A Rated output (state of charge) Note: Since the product needs continuous improvement, the actual product shall prevail.
Page 26 Warranty This warranty covers the repair or replacement of the malfunction device at our company’s discretion for a period of 1-year. In addition this certiﬁcate is void if altered. The serial number must be provided as well as all accessories to be eligible for warranty coverage. Please kindly ﬁll in below form accurately and completely.
Page 27 Ofﬁcial website Website: www.lefant.com Email: support@lefant.com Facebook: @LEFANTOFFICIAL Community: facebook.com/groups/Lefantofﬁcalcommunity Shenzhen lohas Technology Co., LTD. Building 2, Fashion Brand Industrial Park, E'Bu Town, Shenzhen-Shanwei Special Cooperation Zone, Shenzhen, Guangdong, China. LT1-LH20221009-V01...
