Metasphere Point Orange User Manual

Remote telemetry unit
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
`
Point Orange
Point Orange
Remote Telemetry Unit
User Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Point Orange and is the answer not in the manual?

Questions and answers

Related Manuals for Metasphere Point Orange

Summary of Contents for Metasphere Point Orange

  • Page 1 Point Orange Point Orange Remote Telemetry Unit User Guide...
  • Page 2 Permission is, however, not required to copy sections on conditions that a full reference to the source is shown. Published by Metasphere Ltd, Millfield, Dorking Road, Tadworth, Surrey KT20 7TD. Point Orange User Guide, Issue 4.0 ©...

  • Page 3: Table Of Contents

    Text conventions .....................5 Numerical conventions ...................5 Terms and Abbreviations ................6 Storage and Handling ................7 Storage ........................7 Handling ........................7 Point Orange Overview ................8 Basic functionality ....................8 External connections ....................8 Configuration ......................9 External IO .......................9 Modbus Slave......................9 Internal Points ......................9 Modem ........................9...
  • Page 4 Alarm connection ....................36 Terminating a connection ................... 36 Retry regime ......................37 External Antenna ....................38 Powering the Point Orange ..............39 Internal Battery ..................... 39 External Battery ....................39 External DC source ....................39 Power source switching ..................39 Configuring Point Orange ...............

  • Page 5: About This Manual

    Point Orange User Guide About this manual This manual describes the functionality of the Point Orange Remote Telemetry Unit (RTU) and explains how to configure, program and install the Point Orange RTU. It is assumed that the reader has a basic understanding of telemetry, RTU’s and configuration of central telemetry systems.

  • Page 6: Terms And Abbreviations

    Point Orange User Guide Terms and Abbreviations Abbreviation Description Carrier Signal Quality Database Editor Direct Current Data Gatherer Electromagnetic Compatibility FMEA Failure Mode and Effects Analysis GPRS General Packet Radio Service Global System for Mobiles The Institute of Engineering and Technology...

  • Page 7: Storage And Handling

    Point Orange User Guide Storage and Handling The Point Orange has an internal lithium thionyl chloride (LTC) battery pack. This is a mature proven primary lithium battery technology that has been deployed globally to power millions of devices. The manufacturer of the cells used in Point Orange have an exemplary track record and excellent design and quality assurance.

  • Page 8: Point Orange Overview

    GSM/GPRS modem or a tri-band 3G modem. External connections The Point Orange has 2 external connectors; the first is the main connector at the front, which is used for connecting external sensors and/or the USB cable for configuring or monitoring the RTU.

  • Page 9: Configuration

    Point Orange should operate. For more information on Poco please see the relevant user guides. The Point Orange should be connected to the PC running Poco using the Point Orange configuration cable which connects to the main connector on the Point Orange and a spare USB port on the PC. External IO The Point Orange has 5 IO channels;...

  • Page 10: Points

    ■ When the USB is connected to the Point Orange, the RTU will not go to sleep, as the assumption is that the user is configuring the RTU or wishes to monitor the point values as they are updated. In this instance, all non-loop powered points are updated continuously on a 2 second cycle.
  • Page 11 The second exception is for non-loop powered analogue points that are configured with an alarm. In this instance, the Point Orange will wake up at the frequency specified by the ‘Alarm Check’ setting in Poco. This setting is NOT used for any loop powered sensors.

  • Page 12: External Io

    Digital input The Point Orange can be configured to read up to 5 digital inputs (DI). Each of these inputs is defined as volt-free. i.e. no whetting voltage is required for the change in state to be detected. The DI’s will also accept a 0-2V signal as a digital input.

  • Page 13: Counter Input

    Counter input The Point Orange can be configured to read up to 4 counter inputs (CI). Similar to the DI channels, they are defined as volt-free. The counters are able to count at up to 100Hz and include a debounce filter for use with mechanical switches.
  • Page 14 Point Orange User Guide Active loop The Point Orange can be configured to read up to 2 active loop inputs. An active loop channel provides a 12V DC power supply to power an external sensor and can read a 4-20mA signal from the sensor.

  • Page 15: Serial

    Figure 6: Typical passive loop connections Passive voltage The Point Orange can be configured to read up to 5 passive voltage analogue inputs. A passive voltage channel can read a 0-2V signal from the sensor. Figure 7 shows a typical connection...

  • Page 16: Configuring The Io

    Modbus slave these include 10 digital points, 10 analogues points and 10 counter points. In order to conserve power the Point Orange will only communicate with the slave on a specified trend frequency. This trend frequency is the minimum trend frequency configured on any of the above mentioned Modbus points.
  • Page 17 Point Orange User Guide Figure 11: IO Configuration tab...

  • Page 18: Available Io

    The number of channels of a particular type is displayed in brackets after each IO type i.e. with no IO configured a Point Orange can have up to an additional 5 Digital inputs, 2 Active loops, 2 passive Loops etc. These numbers are also updated as IO channels are added. The left hand side of Figure 12 shows the IO available with no channels added and on the right an active loop and counter have been added, reducing the overall IO options.

  • Page 19: Configured Io Channels

    Figure 16: Active Loop configuration Passive Loop The passive loop inputs have no additional configuration settings, as it is assumed that the sensor is being permanently powered by an external supply, which is beyond the control of Point Orange. Figure 17: Passive Loop Configuration...
  • Page 20 The Response Timeout is the length of time the Point Orange will wait for a response from the slave to single command. i.e. to read each register. Care must be taken to ensure this timeout is not too...
  • Page 21 This allows Point Orange to power the sensor for a given time, which should be matched to the sensor’s “settle” time – i.e. the time the sensor needs to power-up and take a reading. This settle time should be entered into the configuration screen –...

  • Page 22: Connector Pin-Out

    Point Orange User Guide Connector pin-out The pin numbering scheme of the single 12-pin connector on Point Orange are shown in the following table. Note that many of the pins have multiple uses, depending on how they are configured in Poco as discussed above.

  • Page 23: Internal Io

    Point Orange User Guide Internal IO The Point Orange has a number of internal points that can be read by a master station such as battery voltage, or whether the unit is submerged or not. These conditions are mapped to points and are always available.
  • Page 24 This allows for more frequent sampling of the sensor if desired. Once a submerged reading has been detected, the Point Orange will take a further 5 samples at 10 second intervals. If the average of these six samples has a deviation greater than the threshold then...

  • Page 25: Modem Points

    This digital point is updated by interrupt and is set to 1, when a USB cable is connected between the Point Orange and a PC. This can be used as a tamper detection to determine if and when a local connection is made to the RTU.
  • Page 26 IP address, but the socket was unexpectedly Socket closed by remote host closed. The server might not be configured to accept communication from the Point Orange. The remote server unexpectedly closed the Connection closed by remote connection during an established comms host session.
  • Page 27 This point is updated during the connection attempt so can be read as a current value by the master. This point shows the last signal strength read when the internal antenna was in use. Modem Types (AI23) This point shows which modem the Point Orange is currently using. Point Value Modem...
  • Page 28 Point Orange User Guide Network Technology (DI14) This digital point indicates which network technology is being used by the Point Orange. 0 = 2G, 1 = Last Contact Time (CI5) This point is updated at the end of a connection attempt, and displays the last time the RTU made contact with the master station (in Unix time –...

  • Page 29: Rtu Diagnostic Points

    The clock is stopped each time the RTU goes to sleep. Serial Number (ST0) This is the serial number of the Point Orange unit and will match the number located on the top of the enclosure. This can be useful for tracking where units are.
  • Page 30 Point Orange User Guide Bit number Description Abnormal condition exists on Outstation (Trouble) Device restart Function not supported Object not supported Parameter error (Outstation is unable to parse the Application Layer fragment) Event buffer Overflow Operation already executing Configuration Corrupt...

  • Page 31: Events And Alarms

    Passive points are sampled every time the RTU wakes up and every 2s thereafter as long as the RTU stays awake. If there is an alarm configured on any of the passive points the Point Orange will wake up at the frequency specified by the ‘Alarm Check’ setting in Poco. Otherwise if there are no Alarms...

  • Page 32: Counter Inputs

    External Counter points. Deadbands When configuring alarms the concept of deadbands is applicable to AI and DI points. There are two types of deadband that are used by the Point Orange, time deadbands and level deadbands. Time...
  • Page 33 Point Orange User Guide deadbands can be applied to both digital and analogue points. Level deadbands are only applicable to analogue points. Time deadbands A time deadband is the time period after an alarm condition has been detected that the event or alarm is raised.

  • Page 34: Trending

    Maximum events If a Point Orange is configured as a DNP3 slave the maximum number of events that can be stored for each class can be configured in the configuration file. If the Point Orange reaches this maximum number of events it will attempt to dial-in to the Master and continue to collect events.

  • Page 35: Time

    UTC time and date. The Point Orange has an integrated RTC that is responsible for maintaining time. When the Point Orange is first powered up or is reset, the time is initialised to the start of Unix time, i.e. 01/01/1970: 00:00:00.

  • Page 36: Communications

    If for any reason the RTU does not get it’s time set, the Point Orange will consider this to be a failed connection and will enter the retry regime.

  • Page 37: Retry Regime

    At the next connection attempt, the Point Orange will use the second IP address in the list. If after trying all IP addresses, the Point Orange cannot contact the master, or if the attempt fails for another reason, such as GSM registration failure, or APN logon failure, then the Point Orange will enter the Retry Regime.

  • Page 38: External Antenna

    RTU will dial-in immediately and the retry regime will reset. External Antenna The Point Orange has 2 antenna options internal or external. The selection of which to use is controlled by software and the user has 3 options, Internal only, External only, or Automatic. The first two options obviously fix the antenna selection to either the internal or external antenna.

  • Page 39: Powering The Point Orange

    Replacement packs are available from Metasphere Ltd. External Battery The Point Orange external battery pack is based on the internal battery pack and can be used to extend the operational life of the unit. For example, high frequency of reading multiple externally powered sensors or to allow lots of calls per day.

  • Page 40: Configuring Point Orange

    If Point Orange does not have a valid configuration it will go into a sleep mode when unplugged from the PC. The Point Orange can only be woken from this mode when connected to the PC via a USB programming cable.
  • Page 41 Point Orange User Guide point displaying the current configuration code. Each time the Point Orange is reset the process illustrated in the following diagram is run. Start New file Existing AI22 = 0 on RTU? valid file? AI22 = 4...

  • Page 42: Installing/ Upgrading Firmware

    Figure 35: Firmware version DNP3 File Transfer The firmware on Point Orange can be updated remotely from a DNP3 master using DNP3 file download and activation functions. The Firmware file must have an extension “*.rfu”.

  • Page 43: Accessories

    For applications with multiple IO and potentially an external battery pack, the off-the-shelf cabling comes in multiple parts: A splitter cable to split out the single connector on the Point Orange to multiple connectors ■ for the sensors and potentially the external battery pack Individual cables which connect the individual sensors to the splitter cable ■...
  • Page 44 Point Orange User Guide Part Part Description Picture Common application number usage 5-110 Point Orange Impress 10 bar 4-20mA Impress sensor + pressure transducer AI1 cable terminated with Point Orange connector. 5-114 Point Orange Splitter for Connect a loop-powered Splitter – AI0 & Ext...
  • Page 45 Point Orange unterminated cables In addition to the full terminated cables listed above a number of unterminated cables are available allowing users to connect any sensor to the Point Orange. The sections below describe these cables including pin outs and core colours.

  • Page 46: Test Box

    The test box also has the option for a DC input (7.5V). If connected to a DC source, the test box will power the Point Orange. If the DC input is not present, Point Orange will use its internal battery to...
  • Page 47 For example, high frequency of reading multiple externally powered sensors or to allow lots of calls per day. It uses the same enclosure as the Point Orange but both parts are orange to allow easy identification. For more information on the Point Orange external battery, see the relevant...

  • Page 48: Installation

    The Point Orange has been designed to minimise the time required to install the unit enabling rapid deployment of the unit in the field. The Point Orange can be installed to a wide variety of sites thanks to its unique design offering 3 different methods: Pipe; Bracket; and Wall. The following sections describe each installation method and when you should consider employing the method.

  • Page 49: Pipe

    (i.e. water, gas etc.) should be determined before installation proceeds. It is the responsibility of the user to ensure that the pipe is suitable for installation. Metasphere accept no responsibility for damage to pipes or other damage as a direct or indirect result of the Point being secured to a pipe.

  • Page 50: Configure And Connect

    Figure 40: Integrated mounting bracket with screw slots Configure and Connect To preserve the internal battery of the Point Orange, all units are manufactured with a default deep sleep configuration. In this mode, the unit is in permanent sleep with all peripherals turned off. The unit can be woken from this sleep connecting it to a PC using the configuration cable.

  • Page 51: Points List

    Point Orange User Guide Points List This section provides a summary of all points available on the Point Orange, including scaling information. Analogue Inputs Point Name Notes Index Analogue input 0 (if configured) If configured as passive voltage or active voltage: Offset = 0, multiplier = 0.0000625...
  • Page 52 Point Orange User Guide Point Name Notes Index 13.22V = 4095 Min = 0, Max = 32767 Submersion Submersion indication Signal quality from the modem (CSQ). In the range 0-31. Offset = -113dBm, multiplier = 2 Modem CSQ -113 dBm = 0...
  • Page 53 Configuration Error Configured Code No new Configuration found Configured New configuration invalid Configured New configuration valid Current modem used by the Point Orange None Unknown Modem Type Wismo 2G Telit 2G Telit 3G Flow0 Number of pulses on counter 0 during the counter 0 trend period...

  • Page 54: Counters

    The number of GSM / GPRS registration failures since the unit was last reset Reserved Reserved Awake seconds The number of seconds the Point Orange has been awake since it was last reset DNP3 Events The number of unreported DNP3 events currently stored on Point Orange...

  • Page 55: Digital Inputs

    1 = Reed switch activated (closed) Indicates antenna currently being used; Antenna 0 = External antenna 1 = Internal antenna Indicates if the Point Orange has been submerged; Submersion 0 = Unsubmerged 1 = submerged Indicates if local USB is connected to a PC;...
  • Page 56 Point Orange User Guide Strings Points Point Name Notes Index Serial Number Serial number of Point Orange Network Name of the network to which the modem is registered. IMEI IMEI number of modem Modem Firmware Firmware version string SIM (ICCID)

  • Page 57: Technical Details

    Point Orange User Guide Technical details Analogue Inputs Up to 4 channels Type: Active Current, passive current, active voltage, passive voltage Current range: 0-20mA Voltage range: 0-2V Input impedance: 10.2kΩ Accuracy: ±0.5% (Max ±2%) Absolute maximum ratings: ±5VDC Resolution: 16-bits...

  • Page 58: Standards And Approvals

    Point Orange User Guide Standards and Approvals Directives Council Directive 1999/5/EC Radio equipment and Telecommunications Terminal Equipment Council Directive 2004/108/EC Electromagnetic compatibility Council Directive 2006/95/EC Low Voltage Standards EN60950-1:2006 - Information technology equipment - Safety - Part 1: General requirements...

  • Page 59: Further Information

    Point Orange User Guide Further information For further information on the Point Orange or any of the other Metasphere products, contact Metasphere using one of the methods below: Post Metasphere Ltd Millfield Dorking Road Tadworth Surrey KT20 7TD Telephone +44 (0) 1737 846100...

  • Page 60: Index

    Point Orange User Guide Index Alarms Internal .............. 23 Passive Loop ............19 Alarm Check ............11 Passive Voltage ..........20 Analogue inputs ..........31 Pin Table ............18 Counter inputs ..........32 Sensor validation..........10 Deadbands ............32 Digital inputs ............. 31...
