GENERAL SYSTEM PRACTICES
ENGINEERING-PLANT SERIES
CONTENTS.
1. GENERAL
Positioning
Telephone .
.
Removal .
Radio Frequency Suppression .
GENERAL
1.
1.01
This section provides installation and
field maintenance procedures for the
Type 183 telephone (Figure 1).
1.02
The Type 183 telephones now being manu-
factured have a self-compensating type
transmission unit. Earlier Type 183 telephones
are equipped with a
rheostat for loop compensation.
telephone is electrically equivalent to its cor-
responding Type 80 telephone.
1.03
The Type 183 telephone is designed for
mounting on a vertical surface.
telephone can be adapted to anyone of a variety
of installation locations by changing the position
INSTALLATION AND FIELD MAINTENANCE
A. E. CO .
TYPE 183 TELEPHONE
PAGE
1
2
2
2
3
3
3
4
4
4
.
4
5
5
5
6
6
6
8
manually adjustable
A Type 183
The
Copyright c1965 Automatic Electric Company
of the dial assembly and/or the handset hook.
The dial assembly can be rotated 360° and
can be secured in any position along that rota-
tion.
The handset hook can be moved along a
180° arc around the front of the telephone and
can be secured in any one of seven positions.
1.04
The Type 183 telephone with ABC dial, B
SATT dial, or less dial is available
in black, beige, green, ivory, turquoise, yellow,
pink, and white.
1.05
If a ringer is required, a Type 33 ringer
unit should be installed as outlined in the
related publication in the 473 series.
HANDSET
HOOK
HANDSET
Figure 1. Type 183 Telephone.
1 of 8
SECTION 473-301-200
ISSUE 1, JUNE, 1965
GT&E STANDARD
DIAL
ASSEMBLY
FRONT COVER
FRONT COVER
SCREWS
