Page 1 FiberSystem 8000 User’s Guide B-Version...
Page 2 Notices © The Protectowire Warranty Assistance Company, Inc. This The Protectowire Company, Inc. Product maintenance agreements No part of this manual may be repro- instrument product warranted and other customer assistance agree- duced in any form or by any means...
Page 3: Table Of Contents
......... . 16 Front, Rear and Connection Panels of the FIBERSYSTEM 8000 Instrument .
Page 4 Ordering Information Index The Protectowire Company, Inc. FIBERSYSTEM 8000 - Linear Heat Series...
Page 5: Getting Started
Front, Rear and Connection Panels of the FIBERSYSTEM 8000 Instrument ....Terminating the Sensor Cable ....
Page 6: Introduction & Measurement Principle
Introduction & Measurement Principle Protectowire Company, Inc. FIBERSYSTEM 8000 PTS (Protectowire Temperature Sensing) Series is optimized and certified for fire detection applications. The instrument can be configured for various alarm criteria and can be connected to a fire control panel using the relay inputs and outputs. It is categorized as a DTS (Distributed Temperature Sensing) System which are optical fibers functioning as linear sensors.
Page 7 Getting Started The temperature resolution is dependent on several factors: Measurement time, spatial resolution, the length of the fiber, the loss of the fiber, splices or connectors. The Protectowire Company, Inc. FIBERSYSTEM 8000 - Linear Heat Series...
Page 8: General Safety Considerations
Do not proceed beyond a warning sign until the indicated conditions are fully understood and met. The Protectowire Company, Inc. FIBERSYSTEM 8000 - Linear Heat Series...
Page 9 Operator access to the inside of the instrument is WA RNING limited to the procedures described in “Setting up the FIBERSYSTEM 8000 System” in chapter 1. Other areas and parts inside the instrument are not for service by the operator. Refer servicing to qualified service personnel.
Page 10 For operation of the instrument use a power supply certified CAUT ION in compliance with EN54-22 and certified to UL/ULC for UL/ULC compliance. Please note, the The Protectowire Company, Inc. AC/DC adapter A1011A (18V DC, 3.5 A) is not suitable for certified fire detection application. The Protectowire Company, Inc.
Page 11 Laser class 1M label The instrument has built-in safety circuitry, which will disable the optical output in the case of a fault condition. The Protectowire Company, Inc. FIBERSYSTEM 8000 - Linear Heat Series...
Page 12 Please pay attention to the following laser safety WA RNING warnings: • Even the laser power of the FIBERSYSTEM 8000 instrument does not generate direct danger for your eyesight we suggest not to look into the end of an optical cable attached to the optical output when the device is operational.
Page 13 WEEE Directive Annex I, this product is classed as a "Monitoring and Control instrumentation" product. Do not dispose in domestic household waste. For product disposal you can return it to The Protectowire Company, Inc. after arrangement. Please contact your local Protectowire distributor for details.
Page 14: Setting Up The Fibersystem 8000 System
• Defective, damaged, or malfunctioning instruments must be returned to The Protectowire Company, Inc. Do not operate the instrument in the presence of flammable gases or fumes. Operation of any electrical instrument in such an environment constitutes a safety hazard.
Page 15: Installing The Software
CAUT ION range, you should first wait for the device to acclimatize before turning it on. 2. Attach the FIBERSYSTEM 8000 to a fire safety certified power supply which provides the required safety extra-low voltage as specified. Reference controller Internal Wiring Diagram (IWD drawing) for precise connection points.
Page 16: Connecting To The Controlling Pc
LAN, you will need to first connect to the distributed temperature system via USB and set the IP address with the FIBERSYSTEM 8000 Configurator (see FIBERSYSTEM 8000 Configurator Guide), if DHCP is not activated or supported by the network.
Page 17 Interactive IO’s default timeout; you can modify the timeou t in the Interactive IO window by selecting Interact > Options... 2. Continue with “Starting the FIBERSYSTEM 8000 Instrument” on page 32. The Protectowire Company, Inc.
Page 18: Front, Rear And Connection Panels Of The Fibersystem 8000 Instrument
FAULT ALARM Fault LED Alarm LED Indicates On when a temperature value FIBERSYSTEM 8000 measured exceeds alarm has an error condition limits on one or more (e.g. fiber break). channels. The Protectowire Company, Inc. FIBERSYSTEM 8000 - Linear Heat Series...
Page 19 E2000- Connection APC) (depending on Memory card slot On/Off Relays channel options) Disabled; for To switch Connectors to input and output further use FIBERSYSTEM relays 8000 instrument on or off. The Protectowire Company, Inc. FIBERSYSTEM 8000 - Linear Heat Series...
Page 20: Terminating The Sensor Cable
(clean) end of the cable in index matching fluid • any combination of winding, polishing and immersing according to this discribtion here. Note: To terminate the sensor cable by polishing or immersing, a clean cable end is necassary. The Protectowire Company, Inc. FIBERSYSTEM 8000 - Linear Heat Series...
Page 21: Connecting To The Output Relays And Input Lines
Getting Started Connecting to the Output Relays and Input Lines The FIBERSYSTEM 8000 provides one fault relay and 43 alarm relay outputs (dry contacts) that are capable of notifying the user of alarm conditions. • The fault relay is normally closed and in the event of an instrument failure or power outage open.
Page 22 1 x Connection Box with 9 contacts You can mount the connection boxes on a standard c-rail. The outputs contacts are numbered consecutively (1 to 44), with relay outputs on each connector. The Protectowire Company, Inc. FIBERSYSTEM 8000 - Linear Heat Series...
Page 23 Output 28 Pin 6, 21 Output 29 Pin 7, 22 Output 30 Pin 8, 23 Output 31 Pin 9, 24 Output 32 Pin 10, 25 Output 33 Pin 11, 26 The Protectowire Company, Inc. FIBERSYSTEM 8000 - Linear Heat Series...
Page 24 Pin 41, 42 Output 44 Pin 43, 44 Input to reset alarms The FIBERSYSTEM 8000 also provides 4 opto-coupled inputs. The inputs are edge-sensitive and their polarity (rising or falling edge) is be configured to reset selectable by the user. The inputs can alarms that have already been detected.
Page 25: Making Measurements
2 Making Measurements Starting the FIBERSYSTEM ....26 8000 Instrument The Protectowire Company, Inc. FIBERSYSTEM 8000 - Linear Heat Series...
Page 26: Starting The Fibersystem 8000 Instrument
To get familiar with the instrument and measurement concept we NOTE recommend to use the FIBERSYSTEM 8000 Configurator. A Quick and Easy Course is provided on the support CD. It is a step by step course, which takes you through the basic operation.
Page 27 3 Troubleshooting and Maintenance This FIBERSYSTEM 8000 system should be serviced only by authorized personnel. Cleaning ....... .
Page 28: Cleaning
Troubleshooting and Maintenance Cleaning Safety Precautions The Protectowire Company, Inc. assumes no liability for the customer’s failure to comply with these requirements. Do not remove instrument covers when operating. WA RNING Ensure that the instrument is switched off throughout the cleaning procedures.
Page 29: Cleaning Fibersystem 8000 Instrument Housings
Cleaning the Optical Connectors and Adapters To clean the connector Unplug the power supply. The E2000 connector(s) on the FIBERSYSTEM 8000 are inside the enclosure. The Protectowire Company, Inc. FIBERSYSTEM 8000 - Linear Heat...
Page 30 Isopropanol. Spill some drops Isopropanol on a small area of the cleaning paper. Gently rub the connector end over this location, then before the connector dries, rub it against a dry area. The Protectowire Company, Inc. FIBERSYSTEM 8000 - Linear Heat Series...
Page 31 Rotate the stick cleaner 3 or 4 turns. Remove the stick cleaner and dispose of it. you are using a Diamond Ferrule Cleaner, follow the instructions that came with the device. The Protectowire Company, Inc. FIBERSYSTEM 8000 - Linear Heat Series...
Page 32: Replacing The Fuse
Pull the fuse holder and fuse clear of the back panel. Take the fuse out of the fuse cap and note the fuse rating. Make sure the replacement fuse (4A, 250V, The Protectowire Company, Inc. part no. 312004) has the same rating.
Page 33: Checking The Operation Of The Fibersystem 8000 System
FIBERSYSTEM 8000 system Set the measurement system Power down the distributed temperature system. Setup the hardware and connect the FIBERSYSTEM 8000 to the controlling PC (“Setting up the Hardware” on page 14) Connect a fiber to the unit. Switch-on the FIBERSYSTEM 8000 Observe boot process: Observe the LED’s on the FIBERSYSTEM 8000 front panel while...
Page 34: Troubleshooting And Maintenance
Troubleshooting and Maintenance If there is a measurement problem, check if the sensing fiber is correctly connected. If you still have a problem, contact The Protectowire Company, Inc. for support. Check the sensing fiber The sensor cable is verified in the “loss-trace” provided with a FIBERSYSTEM 8000 instrument.
Page 35: Returning The Instrument For Service
Your Advantage The Protectowire Company, Inc. offers a wide range of additional expert services, which you can purchase according to your unique technical business needs. Solve problems efficiently and...
Page 36: Specifications And Regulatory Information
Angled Connector Specifications....Specifications ......The Protectowire Company, Inc. FIBERSYSTEM 8000 - Linear Heat Series...
Page 37: Introduction
Specifications and Regulatory Information Introduction This chapter contains specifications and characteristics for the Protectowire FIBERSYSTEM 8000 Fiber Optic Linear Heat Detector The Protectowire Company, Inc. FIBERSYSTEM 8000 - Linear Heat Series...
Page 38: Definition Of Terms
Dynamic range The maximum two-way loss within the sensing fiber to and from the measured point for which the FIBERSYSTEM 8000 unit is designed. Note: The two-way loss in dB is twice the (one-way) loss of the sensing fiber from the FIBERSYSTEM 8000 unit system to the measured point.
Page 39 Fiber distance The distance along the sensor fiber from the FIBERSYSTEM 8000 connector to a measurement point. A FIBERSYSTEM 8000 trace shows temperature or loss over fiber distance. Intermediate update time - itut Selectable parameter for the time until an intermediate temperature trace is available from the FIBERSYSTEM 8000.
Page 40 +− 20°C per hour. Note: For a FIBERSYSTEM 8000 unit mounted in a rack the environmental conditions within the rack apply. Note: For the temperature range of the sensing fiber see Sensing fiber temperature range.
Page 41 Other parameters as specified. Measurement: An ideal step change in temperature of ΔT 10°C (rising or falling) is measured with the FIBERSYSTEM 8000 instrument. The points of the measured slope are connected using a cubic spline interpolation.
Page 42 The statistics (standard deviation) is based on an operating ambient temperature evenly distributed over the temperature range over repetitions i. Conditions: same as for “Temperature repeatability (standard deviation)”. The Protectowire Company, Inc. FIBERSYSTEM 8000 - Linear Heat Series...
Page 43 Measurement: Smoothing window size s = 50 m (±25 m around each point). Sampling resolution set to minimum (0.5 m). Typical value Typical value is a characteristic describing the product performance that is usually met, but not guaranteed. The Protectowire Company, Inc. FIBERSYSTEM 8000 - Linear Heat Series...
Page 44: References
Specifications and Regulatory Information References (1) according to the “Guide to the Expression of Uncertainty in Measurement”, BIPM, IEC, ISO et al. (1993) The Protectowire Company, Inc. FIBERSYSTEM 8000 - Linear Heat Series...
Page 45: Angled Connector Specifications
The contact connector on your distributed temperature system is an E2000 APC angled, you can only use a cable with angled connectors. Never connect a straight connector directly to an angled connector. The Protectowire Company, Inc. FIBERSYSTEM 8000 - Linear Heat Series...
Page 46: Specifications
Specifications and Regulatory Information Specifications Each FIBERSYSTEM 8000 instrument is individually tested and must pass defined test limits. The test and specification process follows strict guidelines. Offering a thorough data sheet backed by stringent quality control measures guarantees best performance application fit over time.
Page 47 Specifications and Regulatory Information The Protectowire Company, Inc. FIBERSYSTEM 8000 - Linear Heat Series...
Page 48 5 Ordering Information The Protectowire Company, Inc. offers a wide range of FIBERSYSTEM 8000 instruments, sensor cables, as well as other Accessories from The Protectowire Company, Inc. and it’s Solution partners. Detailed information available at: www.protectowire.com . The Protectowire Company, Inc.
Page 49 I/O configuration testing sensor fiber terminating input connector see also relay service returning instrument marking Spatial resolution Internal data storage capability specifications ISO 9001 angled connector The Protectowire Company, Inc. FIBERSYSTEM 8000 - Linear Heat Series...
Page 50 © 2011 The Protectowire Company Inc. Man-2004 August 2013 The Protectowire Company, Inc 60 Washington Street Pembroke, MA 02359 Tel: (781) 826-3878 Fax: (781) 826-2045 www.protectowire.com...
