Summary of Contents for Solvera Lynx COMBOX.L CI-B
- Page 1 USER MANUAL COMBOX.L CI-B Long Range Low Power Wireless Logger...
- Page 2 LOGGER User manual Solvera Lynx d.o.o. is entered in the Court at Ljubljana District | Share capital: 53.434,75 EUR | ID number: 1716808000 | VAT ID: SI98578537 | Bank account: SI56 0203 6009 1956 438 at NLB d.d., SWIFT: LJBASI2X...
-
Page 3: Information About The Document
V 2.1 1.2. DISCLAIMER All rights to this manual and the information contained herein are the property of Solvera Lynx. Reproduction, use or disclosure to third parties without expressed permission is prohibited. Solvera Lynx reserves the right to change the technical specifications of its products without notice in writing and urges its customers to make sure that the information they have is valid. -
Page 4: Product Presentation
Uses LoRa modulation under LoRaWAN™ v 1.0.2 protocol • This is not a point to point device and can not be used in this manner 2.2. PACKAGE CONTENT • device ComBox.L CI-B • battery LI-SOCI2 SAFT LS14500 3,6 V • cable for counter (optionally 2 •... -
Page 5: Tehnical Data
3. TEHNICAL DATA RADIO • Frequency: 868 MHz ISB EU • TX Power: 14 dBm (25 mW) 4. TEMPERATURE • • RX Sensitivity: -139 dBm Operation: -20 °C to +60 °C 3,6V) • • Modulation: LoRa Storage: -20 °C to +70 °C •... -
Page 6: Technical Data
4. TECHNICAL DATA 4.1. COMBOX.L CI-B TYPE • Minimal 15 min measuring/sending period • Connector C1 • Connector C2 C1 connector C2 connector (left side) (right side) -
Page 7: Notification For Installation
5. INSTALLATION 5.1. NOTIFICATION FOR INSTALLATION • The ComBox.L device must be vertically mounted with the antenna on the top. • Before device placement, you must observe nearby metal objects (reinforced concrete, steel poles, etc), radio interference devices and other obstacles, which influence the signal strength. Relocate the device as far away as possible from those objects. - Page 8 WARNING • Interference with the device interior is permitted only when replacing batteries. Any other interference with the device is strictly prohibited. • Batteries are standard AA size batteries, but if you insert 1.5 V alkaline batteries, the device will not work. Use ONLY SAFT LS14500 batteries. •...
-
Page 9: Connection To Nms (Network Management Server)
• If you have only one cable connected to the ComBox.L device, then it is very important to seal second connector with the enclosed plug. With this plug we are ensuring IP67 protection. For installation, please see pictures below (Pictures 8, 9 and 10) Pictures 8, 9 and 10: Cable Connection •... -
Page 10: Recommended Fields Of Use
6. RECOMMENDED FIELDS OF USE • Smart Buildings • Smart Industries • Smart Grids • Smart Energy Picture 13: LoRaWAN Network Structure Picture 14: Energy Management System... -
Page 11: Lora Certificate Of Compliance
7.1. LORA CERTIFICATE OF COMPLIANCE CERTIFICATE OF COMPLIANCE LoRaWAN™ Certified Product The LoRa Alliance is pleased to congratulate Solvera Lynx d.d. on the completion of the LoRaWAN™ Certification Program for the following product: MANUFACTURER Solvera Lynx d.d. TYPE OF DEVICE... -
Page 12: Siq Certificate
7.2. SIQ CERTIFICATE... -
Page 13: Eu Declaration Of Conformity
8. EU DECLARATION OF CONFORMITY This declaration of conformity is issued under the sole responsibility of the manufacturer: Solvera Lynx d.o.o. Stegne 23A SI-1000 Ljubljana Slovenia for the product: Product: ComBox. L – Long Range Low Power Wireless Logger Types: ComBox.L CI-B;... - Page 14 9. REGULATIONS WEEE According to the WEEE (Waste electrical and electronic equipment) Directive, do not dispose of this product as household waste or commercial waste. Waste electrical and electronic equipment should be appropriately collected and recycled as required by practices established for your country.
