- Page 1 TracSafe MAX User Manual Multi-use Data Logger...
- Page 2 Bluetooth Low Energy technology, that allows touchless temperature checks of in-transit shipments using a smart phone or tablet via the CSafe TracSafe app (iOS or Android). It enables direct monitoring of the temperature-sensitive products during the shipment or storage phases and can easily identify if the tempera- tures hava been maintained at the end destination.
-
Page 3: Specification
5.Logging interval: 3min~60min 6.Start mode: Button push, immediate start, or start delay, useTracSafe APP or CSafe pc software 7.Stop mode: Button push, stop when inserted into pc, stop when memory is full,use TracSafe APP or CSafe pc software 8.Alarm Limits: 1 high and 1 low limit for temperature/ 1 high and 1 low limit for humidity Alarm type: Single, cumulative 9.Alarm type: Single, cumulative... - Page 4 •User can re-configure and start logging after stop device or export the complete data. Notice: The history data will be cleared about saving parameter. User can click “History” in CSafe to review the history data if user forget to save/download data.
- Page 5 •Press START and STOP buttons simultaneously for 3 seconds until the two LED lights blink at the same time shows on the LCD screen. 2.Download CSafe APP •The user can download the CSafe TracSafe APP in iOS APP store or Google Play for Android •User needs to register according to the prompts. 3.Configuration and logging •Click “Loggers”...
- Page 6 4.Read & download data •Click in Loggers page to refresh the device list and click “Read data”. •After the data has been read completely user can click “stop” to stopping logging; Click “Data” tab to review the history data; user can download PDF and CSV reports via clicking “Download data” tab. 5.Quick operations via scanning the bar code on the device •...
-
Page 7: Status Indication
Status indication 1.Button functions Function Operation Start logging Press START button for 3s blink 5 times Stop logging Press STOP button simultaneously for 3s blink 5 times Press START and STOP button for 3s red and green LED blink 5 times at the same time Switching the LCD pages Press START button (or )blink once(or twice) -
Page 8: Lcd Interface
LCD interface 1. Not started 2. Start delay 3. Started 4. Stopped 5. MAX 6. MIN 7. Generating reports 8. USB connected 9. Internal sensor error 10. External sensor error 11. Re-save parameters... -
Page 9: Lcd Symbols
LCD symbols Function ▶ Started Stopped ■ No alarm Alarm External probe is connected. External probe error Bluetooth is turned on. Note: 1. Please store the device in a room temperature environment. 2. When using the device for the first time, be sure to connect the computer for parameter configuration to synchro- nize time. -
Page 10: Factory Default Parameters
Factory default parameters Items Default parameter Note Logging interval 5 min Start mode Press button to start Start delay No start delay Press button to stop Enabled Temporary PDF Enabled Temperature units °C LCD display time LCD main page display time LCD other pages display time LED blink No blinking... -
Page 11: Fcc Statement
FCC Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
