Summary of Contents for TIERRA AM35 Series
- Page 1 AM35 SERIES Installation Manual...
-
Page 2: Table Of Contents
TABLE OF CONTENTS PREFACE ......................2 INTRODUCTION ....................4 SPECIFICATIONS ....................8 INSTALLATION ....................12 BATTERY PACK WARNINGS ................18 TROUBLESHOOTING ..................19 TECHNICAL SUPPORT ..................20 LINK TO USER GUIDE ..................21 CERTIFICATIONS ....................22... -
Page 3: Preface
This manual uses the following conventions: of your receiver. The information and data in this Manual are a valuable asset of Tierra and are developed by the expenditure of considerable work, time and money, and are the result of original selection, coordination and arrangement by Tierra. -
Page 4: Introduction
INTRODUCTION INTRODUCTION AM35 Series is Tierra’s third generation of devices and the result of our long-standing expertise in providing REFERENCE PART NUMBER advanced telematics and bringing meaningful improvements in our HW to keep on meeting our customers’ necessities. Part Numbers... - Page 5 INTRODUCTION INTRODUCTION AM35 LED DISPLAY PANEL AM35 MAIN ENVELOPE DIMENSIONS Power LED (Red): • OFF - No power supply. • Double blink - powered and working. • Rapid blinking - key off. CAN-BUS LED (green): • Off: CAN-BUS signal not available. •...
-
Page 6: Specifications
SPECIFICATIONS SPECIFICATIONS AM35XT AM35XB Wakeup sources Ignition - RTC - CAN - IMU Wakeup sources Ignition - RTC - CAN - IMU Onchip transformable RSP 3.2 compliant Onchip transformable RSP 3.2 compliant WiFi/BLE WiFi 2.4 GHz, 11b/g/n20: 2412 ÷ 2472 MHz - BT/BLE 4.1: 2402 ÷ 2480 MHz WiFi/BLE WiFi 2.4 GHz, 11b/g/n20: 2412 ÷... - Page 7 SPECIFICATIONS SPECIFICATIONS AM35LT Wakeup sources Ignition - RTC - CAN - IMU Onchip transformable RSP 3.2 compliant WiFi/BLE Memory 30 MB - extended memory +8MB Flash NAND 90 MB - extended memory +128 MB Ports & Connectors Serial Port RS232 CAN Bus 2x with configurable 120 Ohm termination Connector...
-
Page 8: Installation
INSTALLATION INSTALLATION The following section describes the installation steps for AM35 devices. Vehicle cables and screws are not included WARNING - NEVER cover the vent hole in the bottom of the AM35 device with tape or Velcro. Covering the vent hole may cause device failure, as the vent hole releases humidity caused by temperature changes. - Page 9 INSTALLATION INSTALLATION Connect the antenna cables (AM35XB only). NOTICE - If the device is not properly installed, any motion detected by the internal accelerometer will have a negative impact. False readings will occur unless the device is firmly in place. WARNING - DO NOT ALLOW the CM1X or the components of the telematic system to BLOCK or LIMIT your view outside the cab.
- Page 10 INSTALLATION INSTALLATION CONNECTOR PINOUT NOTICE - The wiring schematics are noted as recommendations by Tierra, please consult your equipment manufacturers operation manuals for specific information Pin # Signal Color Pin # Signal Color pertaining to wiring or use of the equipment’s battery as a power source.
-
Page 11: Battery Pack Warnings
If power management profiles do not function, make sure that the internal battery has a full charge (this can take up to 10 hours initially to put a full charge into the back up battery contained inside Tierra devices). Try to power cycle the device. -
Page 12: Link To User Guide
TECHNICAL SUPPORT LINK TO USER GUIDE If the troubleshooting hints and tips in this Installation Manual fail to remedy the problem, please contact Tierra Once the device is installed and running, you can access the User Guide at the following link: Support: support-tierra@tierratelematics.com... -
Page 13: Certifications
CERTIFICATIONS CERTIFICATIONS ISED Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device model AM35XT/AM35XB/AM35LT contains IC:28545-AM35 and: IC: 10224A-201611EC21A (Modem version EC21A) Changes or modifications not expressly approved by the party responsible for compliance could void the user’s Responsible party’s contact located in the Canada: authority to operate the equipment. - Page 14 © Copyright Tierra S.p.A. July, 2022 All contents in this manual are copyrighted by Tierra S.p.A. All rights reserved. The information contained herein may not be used, accessed, copied, stored, displayed, sold, modified, published, or distributed, or otherwise reproduced without express written consent from Tierra S.p.A.
- Page 15 TIERRA S.p.A. Corso Ferrucci, 112 - 10138 Torino - Italy www.tierratelematics.com...
