MicroFogger 4 Pro Manual
Quick start guide
The following guide will show you how to setup your new MicroFogger 4 Pro for the first
time. Follow each step carefully - failure to do so can damage the product and cause
frustration!
Read the "safety" part of this manual to familiarize yourself with the safety
procedures before operating the MicroFogger.
1. Upon unboxing your parcel, locate the MicroFogger and the USB charging cable.
Turn the MicroFogger ON using the black toggle switch on the bottom and plug
it into a charger using the included cable. Only use a wall socket type USB charger
to prevent unintentional activation during charging. The MicroFogger can only be
charged while it is turned ON. We recommend that you allow the MicroFogger to
fully charge before beginning to use it. This will usually take 3 to 4 hours.
2. While the MicroFogger is charging, you can fill up the fog liquid tank. With the new
and improved top-fill design, simply lift up the rubber cover to open the fill port, as
shown in figures A and B. Do not pour any liquid onto the central opening.
3. Locate the bottle of fog liquid and unscrew the top cap. Using the pipette-style tip,
carefully pour fog liquid into the fill port. Take your time and don't fill too quickly as
this can can make the process harder. We recommend getting the tip of the pipette
inside the fill port, and off to one side for easier filling as shown in figure C.
4. Once the fluid tank is nearly full, remove the fog liquid bottle and re-install the rubber
fill port cover. Wipe away any fog liquid drops which may have spilled
Figure A
V1.00 01/01/23
Figure B Figure C
