- Page 1 Introducing BrilliantColor™ Technology David C. Hutchison Texas Instruments DLP® Products...
- Page 2 (reference Figure 1). available colors that can be displayed, Figure 1 -- Color Gamut of a Typical Television or Projector making it difficult to display brilliant yellows and cyans that are commonly found in natural scenes.
- Page 3 Items such as lumens collected out of the p, optical system efficiency, color wheel efficiency, and screen efficiency impact the brightness of the display. brightness is simply the efficiency of the optical system multiplied by the collected lumens and the screen gain. Improving any of the efficiencies in the optical path will result in an improvement of the screen brightness.
- Page 4 By using a multi-primary color wheel and BrilliantColor™ technology, we are able to expand the color gamut to that defined by the outer polygon (dotted line). Figure 4 – BrilliantColor™ Color Gamut This new color gamut represents colors in nature better than the three color gamut typically used in today’s display systems.
- Page 5 Additional Benefits of BrilliantColor™ Technology addition gaining efficiencies in the illumination optics and providing wider color BrilliantColor™ technology additional improvements to the rendering of images on DLP® displays. The BrilliantColor™ algorithms are implemented using floating point arithmetic. Unlike traditional color algorithms which are implemented using a fixed number of bits, the BrilliantColor™...
