ROBOT TROLLEY (EN)
Model RT4500, 2500 & 1500
Congratulations on the purchase of your new Robot Trolley, and thank you for choosing a product from
#HeroCamper™
.
It is important that you read this manual thoroughly before using your Robot Trolley. Unauthorized use or maintenance
may result in voidance of the guarantee.
Charge the battery completely before first use!
The Lithium battery installed in this machine has only been charged to part of its capacity (as freight
regulations prescribe). It is vital that you charge the battery to its full capacity before operating the machine
to ensure high performance and long life. Charging for the first time may take 6-8 hours (see recharging
instructions).
Always recharge fully after use until the LED light turns green!
Recharge Periodically!
If the Robot Trolley goes unused for more than two months, it is highly recommended to inspect and charge
the battery until the LED on the charger changes from red to green, in order to maintain maximum battery
life and performance.
Do not store the Robot Trolley in direct sunlight or at high temperatures. High temperatures may drain the
battery quickly.
Failure to follow these instructions will damage the battery and void the battery's warranty!
Batteries: Charging and changing
Battery for Robot Trolley
1. To charge the Robot Trolley battery, connect the charger to the Robot Trolley by placing the charging
plug in the outlet on the back end cover.
2. The battery charger displays a constant red light while charging is in progress. Completion of battery
charging is indicated by a constant green light.
WARNING NOTICE FOR BATTERY
Advertisement
Summary of Contents for HeroCamper ROBOT TROLLEY RT4500
- Page 1 Model RT4500, 2500 & 1500 Congratulations on the purchase of your new Robot Trolley, and thank you for choosing a product from #HeroCamper™ It is important that you read this manual thoroughly before using your Robot Trolley. Unauthorized use or maintenance may result in voidance of the guarantee.
-
Page 2: Technical Data
Battery Charger Battery Charger Charging Fully Charged Charging Outlet Changing the remote control battery Loosen the 4 screws on the back of the remote control and remove the panel. Replace the old battery with a new one of the same type. Remember to protect the environment when disposing of batteries –... - Page 3 Support plate for female mounting bracket Clamp + Screws and nuts for suspension fitting.
-
Page 4: Eu Declaration Of Conformity
EU DECLARATION OF CONFORMITY No.: 1 The manufacturer, and/or any authorized representative of the manufacturer within the European Community, hereinafter referred to as #HeroCamper™ Lammefjordsvej 5, DK-6715 Esbjerg N declares that the products Robot Trolley RT1500, Robot Trolley RT2500 and RT4500 have been manufactured in conformity with the provisions of the following EU directives ·... - Page 5 EN 13850:2006 Safety of Machinery – Emergency stop – Principles for design EN 13857:2008 Safety distances to prevent hazard zones being reached by upper and lower limbs EN 60204-1:2006 Safety of Machinery - Electrical equipment of machines - Part 1: General requirements #HeroCamper™ Lammefjordsvej 5, DK-6715 Esbjerg...
- Page 6 Before Use: Preparing the Robot Trolley Checking the status Unpack the Robot Trolley and check that the Robot Trolley is clean and not broken Make sure the Robot Trolley battery is charged according to instructions Mounting the suspension fitting – standard bracket REGIONAL VARIANTS Some countries and makes of caravan may require a special bracket version.
- Page 7 The suspension fitting mounted on the Robot Trolley fits into a slit on the underside of the mounting fitting on the left side (seen from the ball catch) and can be pushed into place in this slot. After pushing the Robot Trolley into the slot in the mounting fitting, attach the factory-provided cotter ring, which locks the Robot Trolley in place.
- Page 8 Activating and Pairing the Robot Trolley with the remote control The Robot Trolley comes pre-paired with the remote control. Turn on the Robot Trolley by simply pressing the Start/Stop button for maximum 1-2 seconds. Turn on the remote control by pushing the forward button () once. The Robot Trolley is now ready to use.
- Page 9 Note that children under age 3 should not play with any plastic bags or small parts from the Robot Trolley, as there is a risk of suffocation. Children should not tow the caravan with the remote control. #HeroCamper™ Lammefjordsvej 5, DK-6715 Esbjerg N...
