Summary of Contents for HOKUYO AUTOMATIC Photo Master PNX Series
- Page 2 ■ Connection ■ Adjusting optical axias ● Through beam type (1)Circuit of input and output. (1) Install the projector and receiver opposite to each other DC power type ● so that the optical axis lines up. Brown DC10〜30V PNX series (2) Swing the projector and the receiver vertically and from Load White side to side, and fix each at the mid-point in the range Changeover of where the indicating lamp at the receiver lights up.
