MKC Series
Metal Pan & Tilt Bracket Instructions
Original Instructions
These instructions are for defining acceptable MKC Metal Pan & Tilt Bracket installations to a
mounting surface and for installing an MKC Series or MKD526 Loudspeaker to an MKC Series
Metal Pan & Tilt Bracket.
IMPORTANT SAFETY INSTRUCTIONS – READ THIS FIRST
Safety Instructions
Read and heed all warnings and safety instructions in this manual before using this product.
Failure to follow these precautions may result in damage, injury, or death.
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Clean only with a dry cloth.
6) Install loudspeaker in accordance with the manufacturer's instructions.
7) Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus that produce heat.
8) Only use attachments/accessories specified by the manufacturer.
9) Refer all servicing to qualified service personnel. Servicing is required when the apparatus
has been damaged in any way, does not operate normally, or has been dropped.
10) Use personal protective equipment not limited to gloves, safety goggles, ear protection,
and lifting supports.
Suspension Warnings
WARNING: Suspending anything, especially overhead of people, should be done with extreme
caution. Always engage the services of a certified professional who is qualified to determine
the requirements for and to implement overhead rigging. Only persons with the knowledge
of proper hardware and safe rigging techniques should attempt to suspend loudspeakers
overhead. Failure to follow these precautions may result in damage, injury, or death.
|
1
Tel 800 992 5013 / +1 508 234 6158
www.eaw.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the MKC Series and is the answer not in the manual?

Questions and answers

Summary of Contents for EAW MKC Series

  • Page 1 Original Instructions These instructions are for defining acceptable MKC Metal Pan & Tilt Bracket installations to a mounting surface and for installing an MKC Series or MKD526 Loudspeaker to an MKC Series Metal Pan & Tilt Bracket. IMPORTANT SAFETY INSTRUCTIONS – READ THIS FIRST Safety Instructions Read and heed all warnings and safety instructions in this manual before using this product.
  • Page 2 MKC Series Metal Pan & Tilt Bracket Instructions Avertissements de suspension AVERTISSEMENT: Suspendre quoi que ce soit, en particulier les frais généraux de personnes, doit être fait avec une extrême prudence. Toujours engager les services d'un professionnel certifié qui est qualifié pour déterminer les conditions requises et à mettre en œuvre le gréement en tête.
  • Page 3 Metal Pan & Tilt Bracket Instructions 1. Inventory your kit Item Description Quantity EAW MKC Metal Wall Mount Speaker Bracket EAW MKC Metal Wall Mount Wall Bracket Button Head Hex Drive Screw 18-8 Stainless Steel Split Lock Washer 18-8 Stainless Steel Oversized Washer **Tools Needed: (2)13mm wrench, 2.5mm &...
  • Page 4 EAW-approved will void the warranty and may result in damage, injury, or death. d. WARNING: Take care when lifting larger MKC Series products to avoid harm or damage to product. 3. Installation of the MKC Series Metal Pan & Tilt Bracket to a mounting surface a.
  • Page 5 Each MKC Series Metal Pan & Tilt wall bracket (A) hole will need to mount to permanent structure i. All four mounting holes will need to mount to permanent structure utilizing approved mounting hardware.
  • Page 6 MKC Series Metal Pan & Tilt Bracket Instructions b. Connecting Speaker Bracket (B) to Wall Bracket (A) i. Line up the two exposed speaker bracket holes with opening in pivot block ii. Slide Button Head Hex Drive Screw (C) connect brackets together iii.
  • Page 7 As with any professional loudspeaker system, routine maintenance must be conducted in order to ensure the longevity and safe, consistent performance. d. Inspect the MKC Series Metal Pan & Tilt Bracket for damage. Brackets with visible damage should be replaced and discarded.
