OWNER'S MANUAL
SUNSHINE COAST
MODULAR OUTDOOR FURNITURE SYSTEM
COMPONENT: CORNER UNIT
Model: OLSC-123
FMI BRANDS INC.
107 – 19052 26 Avenue, Surrey, BC Canada V3Z 3V7 • www.outlandliving.com
USA, Canada Toll Free: 1-888-514-1663 • Tel: (+1) 778-294-0988 • Email: info@outlandliving.com
Hours of Operation: 8:30AM - 4:00PM (Pacific Time) • Customer Service in English only
® Registered trademark of FMI Brands Inc.
D.123.000.V0

Advertisement

loading
Need help?

Need help?

Do you have a question about the SUNSHINE COAST OLSC-123 and is the answer not in the manual?

Questions and answers

Summary of Contents for Outland Living SUNSHINE COAST OLSC-123

  • Page 1 ® OWNER’S MANUAL SUNSHINE COAST MODULAR OUTDOOR FURNITURE SYSTEM COMPONENT: CORNER UNIT Model: OLSC-123 FMI BRANDS INC. 107 – 19052 26 Avenue, Surrey, BC Canada V3Z 3V7 • www.outlandliving.com USA, Canada Toll Free: 1-888-514-1663 • Tel: (+1) 778-294-0988 • Email: info@outlandliving.com Hours of Operation: 8:30AM - 4:00PM (Pacific Time) •...
  • Page 2 ¼ - 20 thread 1” Length Screws, 8 +1 ¼ - 20 threade Seat Panel 1-½” Length Screws, 18 +1 ¼ - 20 Thread En-2 OUTLAND LIVING • SUNSHINE COAST • MODULAR OUTDOOR FURNITURE SYSTEM • CORNER UNIT • OLSC-123 ® D.123.000.V0...
  • Page 3 PART # DESCRIPTION QUANTITY PICTURE ¼ - 20 Flange Nut 8 +1 5/32” Hex Key Tool (Long) 5/32” Hex Key Tool (Short) Required Tools (Not Supplied): WARNING: Scissors Improper assembly, adjustment, alteration, service or maintenance can cause injury or property damage. Read the Owner &...
  • Page 4 Do not fully tighten the screws yet. USE (2x) 1-½” LENGTH SCREWS HERE (2x) CORNER BACK *Do not fully tighten the screws yet! En-4 OUTLAND LIVING • SUNSHINE COAST • MODULAR OUTDOOR FURNITURE SYSTEM • CORNER UNIT • OLSC-123 ® D.123.000.V0...
  • Page 5 SECTION 1: ASSEMBLY (continued) STEP 3A SIDE PANEL Fasten (2x) Brackets to the (1x) Side Panel using (4x) ¾” Length Screws. (SHORTER PANEL) **Fasten the long sides of the brackets. IMPORTANT! Leave loose. Do not fully tighten the screws yet. (2x) BRACKETS (4x) ¾”...
  • Page 6 Note the screw holes for mounting the feet on the (1x) Corner Front Panel and (1x) Side Panel. IMPORTANT: During assembly, ensure these holes are facing down! En-6 OUTLAND LIVING • SUNSHINE COAST • MODULAR OUTDOOR FURNITURE SYSTEM • CORNER UNIT • OLSC-123 ® D.123.000.V0...
  • Page 7 SECTION 1: ASSEMBLY (continued) STEP 4 Flip over the panel assembly so the feet mounting holes are facing up. FLIP OVER! a) Install (1x) Short Seat Support using (2x) ¾” Length Screws. b) Fasten (1x) Bracket to the (1x) Corner Front Panel using (2x) ¾” Length Screws. **Fasten the long sides of the bracket.
  • Page 8 Firmly tighten the (2x) crossbar connections inside the component cavity. Use the SHORT Hex Key Tool to firmly fasten the screws. (2x) CROSSBAR CONNECTIONS En-8 OUTLAND LIVING • SUNSHINE COAST • MODULAR OUTDOOR FURNITURE SYSTEM • CORNER UNIT • OLSC-123 ® D.123.000.V0...
  • Page 9 SECTION 1: ASSEMBLY (continued) STEP 8 Install the (1x) Long Seat Support using (2x) ¾” Length Screws. Confirm the (2x) Corner Back components are square and aligned at 90 degrees. Firmly tighten the (2x) seat support screws. LONG SEAT SUPPORT (2x) ¾”...
  • Page 10 Reference the installation instruction diagrams below. (16x) 1-½” LENGTH SCREWS INSTALL (3x) STANDARD FEET HERE INSTALL (1x) FOOT WITH 45 DEGREE CORNER HERE En-10 OUTLAND LIVING • SUNSHINE COAST • MODULAR OUTDOOR FURNITURE SYSTEM • CORNER UNIT • OLSC-123 ® D.123.000.V0...
  • Page 11 SECTION 1: ASSEMBLY (continued) STEP 10 Confirm all wicker panels are squarely aligned. Double-check the tightness of all screws. Ensure all screws are firmly tightened. Flip the assembly over so that the feet are contacting the ground. Use two people to lift. Take care not to scratch the wicker. LEFT HAND SIDE CORNER UNIT RIGHT HAND SIDE CORNER UNIT FLIP...
  • Page 12 Note: For cushion support, the flat seat strap surface should be placed on the top side, so to be in contact with the cushion bottom. (1x) SEAT PANEL En-12 OUTLAND LIVING • SUNSHINE COAST • MODULAR OUTDOOR FURNITURE SYSTEM • CORNER UNIT • OLSC-123 ® D.123.000.V0...
  • Page 13 SECTION 1: ASSEMBLY (continued) STEP 12 Place the Seat Cushion and (2x) Back Cushions. 1. Seat Cushion: a. The mesh seat cushion bottom should be facing down for water drainage; b. The seat cushion zipper should face the back of the chair to remain hidden. 2.
  • Page 14 TIP: USE THE HEX KEY TOOL AS A GUIDE FOR PUSHING THE SCREW THROUGH THE HOLES. **See diagrams on next page. (4x) 1” LENGTH SCREW En-14 OUTLAND LIVING • SUNSHINE COAST • MODULAR OUTDOOR FURNITURE SYSTEM • CORNER UNIT • OLSC-123 ® D.123.000.V0...
  • Page 15 SECTION 2: SECTIONAL FASTENING (continued) TIP: THE HEX KEY TOOL CAN BE USED AS A GUIDE TO PUSH THE SCREW THROUGH THE HOLES IN THE WICKER PANELS. a) Wiggle the Hex Key Tool through the gaps in the wicker between both panels; b) Align the tip of the screw with the end of the Hex Key Tool;...
  • Page 16 SECTION 2: SECTIONAL FASTENING (continued) STEP 1B Lock together using (4x) Flange Nuts. Tighten with the Hex Key Tool. (4x) FLANGE NUT En-16 OUTLAND LIVING • SUNSHINE COAST • MODULAR OUTDOOR FURNITURE SYSTEM • CORNER UNIT • OLSC-123 ® D.123.000.V0...
  • Page 17 SECTION 2: SECTIONAL FASTENING (continued) Arrange the different sections together in your preferred layout. One such layout option is shown here. There is no limit to what you can build! Additional modular components can be ordered from www.outlandliving.com. En-17 1-888-514-1663 • WWW.OUTLANDLIVING.COM...

  • Page 18: Maintenance

    Owner & Safety Manual ® SECTION 3: MAINTENANCE OUTLAND LIVING Outdoor Furniture is meant for outdoor use ATTENTION: and requires periodic maintenance to keep it in good condition. The cushions will be wrinkled when freshly released from The all-weather resin wicker weave is made from 100% new the vacuum pack bags.

  • Page 19: Warning Notes

    At FMI Brands Inc.’s sole discretion, products under warranty will be repaired and/or replaced at no charge to the customer. Any returns sent back to FMI Brands Inc. must be sent via prepaid freight and in the original retail packaging. Please register your OUTLAND Living product for proof of purchase and warranty at: https://outlandliving.com/register-products/.
  • Page 20 Simply call us or send an email to info@outlandliving.com and we will answer all DO NOT questions and/or concerns that you may have. RETURN We take pride in our products at FMI Brands Inc. (Outland Living) and will strive to TO STORE provide excellent customer support. FMI BRANDS INC.
