- Page 1 User Manual GH602...
-
Page 2: Table Of Contents
Contents Safety information Troubleshooting Safety instructions Installation Product description Technical data Daily use Energy efficiency Hints and tips GREAT BRITAIN – Customer Care and Service Care and cleaning Subject to change without notice. Safety information Before the installation and use of the appliance, carefully read the supplied instructions. -
Page 3: Safety Instructions
WARNING: Unattended cooking on a hob with fat or oil can be dangerous • and may result in fire. NEVER try to extinguish a fire with water, but switch off the appliance and • then cover flame e.g. with a lid or a fire blanket. CAUTION: The cooking process has to be supervised. - Page 4 hob and underside of the appliance is accessible the mains at all poles. The isolation device must and could allow a user or items stored beneath the have a contact opening width of minimum 3 mm. hob to come in direct contact with the underside of Gas connection the hob, an intermediate protection panel must be fitted.
- Page 5 Care and cleaning Warning! Risk of damage to the appliance. Warning! Do not remove the buttons, knobs or gaskets from the control panel. • Do not keep hot cookware on the control panel. Water may get inside the appliance and •...
-
Page 6: Product Description
Product description Cooking surface layout Auxiliary burner Rapid burner Semi-rapid burner Control knobs Button for the spark generator Control knob Symbol Description Symbol Description minimum gas supply no gas supply / off position ignition maximum gas supply Daily use Burner overview Warning! Refer to Safety chapters. -
Page 7: Hints And Tips
C. Ignition candle Caution! In the absence of electricity D. Thermocouple you can ignite the burner without electrical device; in this case approach Ignition of the burner the burner with a flame, turn the control knob counter-clockwise to maximum gas Always light the burner before you put on supply position and push it down. -
Page 8: Care And Cleaning
Burner Diameter of cook- Burner Diameter of cook- ware (mm) ware (mm) Rapid 180 - 260 Auxiliary 80 - 180 Semi-rapid 120 - 220 Care and cleaning 2. The enamel coating occasionally can have rough Warning! Refer to Safety chapters. edges, so be careful when you wash the pan supports by hand and dry them. - Page 9 What to do if... Problem Possible cause Remedy There is no spark when you try to The hob is not connected to an Check if the hob is correctly connec- activate the spark generator. electrical supply or it is connected ted to the electrical supply.
-
Page 10: Installation
Labels supplied with the accessories bag Stick the adhesive labels as indicated below: MOD. MOD. MOD. TYPE PROD.NO. IP20 PROD.NO. PROD.NO. SER.NO. 0049 SER.NO SER.NO 03 IT DATA DATA MADE IN ITALY A. Stick it on Guarantee Card and send this part (if C. - Page 11 Location If you use flexible metal pipes make sure that they The hob may be located in a kitchen, a kitchen/diner or agree to ISO 10380 and ISO 10807 standards. Be bed sitting room (with a volume greater than 20 m³), but careful they do not come in touch with mobile parts or not in a bathroom or shower room.
- Page 12 Before carrying out the connection, make sure: 1. The limiter valve and the electrical system can take the appliance load (see the rating plate) 2. The supply system is equipped with an efficient earth connection in compliance with the current standards and regulations 3.
- Page 13 Replacement of the connection cable Assembly The replacement of electric cable must be carried out exclusively by the service force centre or by personnel with similar competencies, in accordance with the current regulations. To replace the connection cable use only H03V2V2-F T90 or equivalent type.
- Page 14 B) supplied brackets If a furniture unit is installed at a distance of 400 mm above the hob, there must be a minimum safety distance of 50 mm to the left or right from the edge of the hob. Caution! Install the appliance only on a worktop with flat surface.
-
Page 15: Technical Data
Kitchen unit with oven The electrical connection of the hob and the oven must be installed separately for safety reasons and to let easy remove oven from the unit. Technical data Hob dimensions Width 580 mm Depth 500 mm Bypass diameters BURNER Ø... -
Page 16: Energy Efficiency
Gas burners for LPG G30/G31 28-30/37 mbar BURNER NORMAL MINIMUM INJECTOR NOMINAL GAS FLOW g/h POWER kW POWER kW MARK G30 28-30 mbar G31 37 mbar Rapid 0,75 Semi-rapid 0,45 Auxiliary 0,33 Energy efficiency Product information according to EU 66/2014 Model identification GH602SS Type of hob... - Page 17 Model No......Serial No......... Product No......Date of Purchase......Customer Care: Please contact Electrolux Major Contact No: 08445 613613 Appliances, Addington Way, Luton, Bedfordshire, LU4 ENVIRONMENTAL CONCERNS not dispose appliances marked with the symbol with Recycle the materials with the symbol .
- Page 20 867329016-C-082017...
