MAYTONI TRX005-311 Operation Manual

Three-phase track system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
THREE-PHASE TRACK SYSTEM
TRINITY

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TRX005-311 and is the answer not in the manual?

Questions and answers

Summary of Contents for MAYTONI TRX005-311

  • Page 1 THREE-PHASE TRACK SYSTEM TRINITY...
  • Page 2 OPERATION MANUAL The track lighting systems are based on the track. It is designed for mounting and DESCRIPTION AND supplying power to track lamps in AC networks with a rated voltage of 230V and a...
  • Page 3 PRECAUTIONS All installation and mounting works must be carried out by persons with appropriate permits and qualifications. Contact a qualified electrician if necessary. All installation and dismantling works must be carried out with a de-energized network only.
  • Page 4 ASSEMBLY DIAGRAM AND COMPLETE SET power input straight connector angle-connector* 4 flexible connector 6 T-shaped plug connector** TRA005CF-31B TRA005C-31B TRA005CL-31B-R TRA005EC-31B TRA005B-31B-R TRA005C-31W TRA005CL-31B-L TRA005CF-31W TRA005EC-31W TRA005CT-31B-R TRA005B-31B-L TRA005CL-31W-R TRA005CT-31B-L TRA005B-31W-R TRA005CL-31W-L TRA005CT-31W-R TRA005B-31W-L TRA005CT-31W-L...
  • Page 5 ASSEMBLY DIAGRAM AND COMPLETE SET The following components and accessories are used to form complex configuration systems: Power input - a structural element that is used to supply power to the system. Depending on the location of the ground contact, it can be right or left.
  • Page 6 ASSEMBLY DIAGRAM AND COMPLETE SET X-shaped connector - a system element used to form configurations of complex shape for branches in 3 directions with power input. Swivel connector - an accessory that is used to connect track segments at an arbitrary angle, while maintaining rigidity.
  • Page 7 TRACK CONNECTION METHODS SINGLE LINE CONNECTION: There are two examples of connection in a straight line. The top version uses a power input, while the bottom version uses a direct connector with input option, which allows supplying power to the system from any convenient point.
  • Page 8 TRACK CONNECTION METHODS RECTANGULAR JOINT: Rectangular track system configurations can be manufactured in both open and closed versions. It should be taken into account that the angle connectors can be either external or internal. T-JOINT AND X-JOINT:...

  • Page 9: Mounting Procedures

    MOUNTING PROCEDURES MOUNTING ON A RIGID The maximum allowable load per track segment is 20 kg. Distance SURFACE BY OVERLAP between fasteners - no more than 80 cm. METHOD 80cm MOUNTING ON CABLE The maximum allowable load per track segment is 20 kg. Distance PENDANT between fasteners - no more than 1 m.

  • Page 10: Track Installation

    TRACK INSTALLATION MOUNTING THE TRACK For suspended installation of the track, it is necessary to use special pendant WITH THE PENDANT kits, TRA005WS-31B / TRA005WS-31W, consisting of a cable with collet clamps that allow you to adjust its length, mounting and clamping plates and a decorative cap.
  • Page 11 TRACK INSTALLATION INSTALLATION OF A In addition to surface and suspended mounting, it is possible to install the track in THREE-PHASE TRACK USING A a profile for a stretch ceiling(Not included in the product range, sold separately.).
  • Page 12 TRACK INSTALLATION INSTALLATION OF A 7. Fill the harpoons into the grooves of the profile and glue the ends. THREE-PHASE TRACK USING A 8. Install the track and fasten it to theprofile. PROFILE FOR A STRETCH CEILING...

  • Page 13: Connector Connection

    LOCATION OF TERMINALS AND CONNECTOR CONNECTION For the correct connection and selection of components, the location of the RECOMMENDATIONS neutral conductor in the track should be taken into account. To facilitate the correct assembly of the track system, a special ledge is provided in the track design - it will serve as a reference point for the location of the neutral.
  • Page 14 CONNECTING THE TRACK TO THE NETWORK 1. Remove the power input from the track, unscrew the fixing screws. 2. Make a hole for the power cable by removing the special insert on the back side of the power input, remove the cover.
  • Page 15 SELECTING THE CONNECTION DIAGRAM The connection diagram determines how the lighting fixtures located on the track will be controlled, below are the options for the applied diagrams. Max. 10A One line, in which the control is divided by means of single-gang switches.

  • Page 16: Troubleshooting

    TROUBLESHOOTING Malfunction Cause Troubleshooting The lamp does not work No contact in joints Install the lamp on the track until the adapter is in full contact with the current-carrying cores Check the input cable connection terminals, the connection of the power input terminals to the track, and other connections.

  • Page 17: Warranty

    MANUFACTURER Maytoni GmbH, Feldstiege 98, Münster, Germany, 48161 Maytoni GmbH, Feldstiege 98, Münster, Germany, 48161 IMPORTER www.maytoni.de Developed in Germany.
  • Page 18 +49 (0) 2533 64 295200 info@maytoni.com...

This manual is also suitable for:

Trx005-312
