Summary of Contents for Hyundai IT L17T0D071
- Page 1 NEXT Type No. L17T0D071 Model. G73TR Dual Function Touch Monitor User’s Guide...
- Page 2 U.S.A. U.S.FEDERAL COMMUNICATIONS COMMISSION RADIO FREQUENCY INTERFERENCE STATEMENT INFORMATION TO THE USER NOTE : This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
- Page 3 DECLARATION OF CONFORMITY HYUNDAI IT CORP. Ami-ri Bubal-Eub Ichon-Si Kyungki-Do 467-860 KOREA declare under our sole responsibility that the product: Dual Function Touch Monitor Kind of equipment L17T0D071 Type-Designation to which this declaration relates is in conformity with the following standard(s) or other normative document(s)
-
Page 4: Table Of Contents
Contents 1. Introduction ...........1/24 2. Safety Information .........1/24 3. Installing the monitor ......4/24 3-1. Packing List ..........4/24 3-2. Selecting a suitable location ....5/24 3-3. Rear View & Signal Input Jacks ..6/24 3-4. Connecting the monitor .......6/24 3-5. Setting the refresh rate ......9/24 Preset Timing Table ......10/24 3-6. -
Page 5: Introduction
1. Introduction This manual contains instructions for installing and operating HYUNDAI IT G73TR. HYUNDAI IT G73TR. is a highly ergonomic color display unit. reen r reen-Display controls rface 2. Safety Information red and manufactured to assure your safety. You can pr... - Page 6 Avoid operating the monitor in extreme heat, humidity or areas affected by dust. Temperature : 5~35°C Humidity : 30~80RH Be sure to turn the monitor off before plugging the power cord into the socket. Make sure that the power cord and the other cords are securely and rightly connected.
- Page 7 Cleaning and Maintenance To avoid risk of electric shock, do not disassemble the display unit cabinet. The unit is not user-serviceable. Remember to unplug the display unit from the power outlet before cleaning. ropyl) or any str use thinner or benzene, abrasive cleaners or compressed air. reen with a cloth or sponge that could scratch the surface.
-
Page 8: Installing The Monitor
3. Installing the The following items should be found in the packaging. monitor 3-1. Packing List Power Cord Japan Signal Cable America/Canada Europe DVI-D Cable Audio Cable Australia South Africa USB Cable Korea AC/DC Power Manual CD & Touch Adapter Install CD Above power cord can be changed upon different voltage areas. -
Page 9: Selecting A Suitable Location
3-2. Selecting a suitable location rectly onto or is r reen. To r 3-3 Rear View & Signal input Jacks 5/24... -
Page 10: Connecting The Monitor
3-4. Connecting the Before you start cabling your monitor, check that the power is off on all units. To avoid any possibility of monitor electric shock, always connect your equipment to properly earthed outlets. 6/24... - Page 11 1. Connect AC/DC Power Cable to Adaptor and then connect Adaptor Cable to Monitor through the jack "12V DC" . 2. One end of "Audio Cable" to PC through the jack, "Audio Out". And the other end to Monitor " Audio In". 3.
- Page 12 8/24...
-
Page 13: Setting The Refresh Rate
3-5. Setting the refresh Follow the instructions below to set your refresh rate in Windows rate 98/ME/XP/2000/VISTA/7. Go to the configuration window(Start-Settings-Configuration window). Double click on the ‘Display’ icon. Click on the ‘Settings’ tab. Click on the ‘Advanced’ button. Click on ‘Adapter’ and select 60Hz from the list. Click on ‘Apply’... -
Page 14: Preset Timing Table
Preset Timing Table If the signal from the system doesn't equal to the preset timing mode, adjust the mode with reference to the user’s guide of video card because the screen may not be displayed. Resolution H-Freq V-Freq Mode 31.4 KHz 70 Hz 640 x 350 31.4 KHz... -
Page 15: Way To Install Driver For Touch Monitor
Way to Install driver The driver for touch screen software enables to have mutual communication to 3-6. touch screen-controller through and SUB for touch monitor Supporting organization This utility program enables test for the correction and draw test through the touch screen.Including addition and removal. -
Page 16: User's Environment
3-7. User’s Environment Recommended Ergonomic User’s Environment Kensington Security ice to secure your (Locking) Slot monitor. Kensington lock is not included. * Kensington Technology Group · Address : 2000 Alameda de las Pulgas 2F san mateo, California 94403-1289 · Tel : +1 650 572 2700 · Fax : +1 650 572 9675 · Web-site : www.kensington.com 12/24... - Page 17 VESA MOUNT’G * Ergotron, Inc. · Address : Ergotron Europe Kuiperbergweg 50 1101 AG Amsterdam The Netherlands · Tel : +3 1 20 696 60 65 · Fax : +3 1 20 609 04 59 · E-mail : info.eu@ergotron.com 13/24...
-
Page 18: Adjusting The Picture
4. Adjusting the picture You can adjust the screen display by using the buttons located below the screen. 14/24... -
Page 19: Using The On Screen Display
4-1. Using the On Screen To make adjustments in the On Screen Display, follow these steps: Display Push the MENU button to call the OSD to the screen. Push the " + " or " - " button to choose the item you want to adjust. The selected item is highlighted. -
Page 20: Osd Adjustments
4-3. OSD Adjustments 4-3. OSD Adjustments PICTURE BRIGHTNESS Adjusting the Brightness for all over the Screen. (At factory, they have set the initial Brightness to 50.) CONTRAST Adjusting the Contrast for all over the Screen. (At factory, they have set the initial Contrast to 50.) H.POSITION Moving the position of the screen horizontally. - Page 21 AUTO ADJUST Adjusting the Picture Status to the optimum automatically. Color COLOR TEMPERATURE Adjusting Color Tone for all over the Picture.( At Digital mode, it is it not workable - USER : The user can adjust each color tone to its favorable tone like to the Reddish, Greenish or Bluish.
- Page 22 OSD H.POSITION Move OSD Window horizontally. OSD V.POSITION Move OSD Window vertically OSD TIMER Select the time while OSD Window remains on the screen. (10 Sec, 20 Sec, 30 Sec, 40 Sec) TRANSPARENCY Adjust the Transparency of OSD Window. 18/24...
- Page 23 Miscellaneous LANGUAGE Decide the language for OSD Menu. RECALL If you select "Recall", the Picture will be out of the range and then come back to the range at almost same time. And all adjusted data will be back to the factory set. INPUT SELECT Decide the Input Signal between ANALOG and DIGITAL .
-
Page 24: Display Power Management
5. Display power If the power management function of your computer is enabled, your monitor management turns on and off automatically. You can control power management features from your computer. Reducing power consumption Your computer may have power management features which enable the computer or monitor to enter a power saving mode when the system is idle. -
Page 25: Troubleshooting
6. Troubleshooting If your monitor is not functioning properly, you may be able to solve the problem by following suggestions below : Problem Possible solution Blank screen If the power LED is not lit, push the Soft power switch or check the AC cor d to turn the monitor on. - Page 26 Problem Possible solution Color defects Check that the signal cable connector is properly connected and that the connection pins ar e not bent or damaged. Try another color temperature. Size, position, Adjust the picture characteristics as described in the section OSD shape or quality Adjustment (4-3).
- Page 27 Problem Possible solution The power LED is LED Indicator can be appear orange on changing of video mode or a orange color Input Signal. Check the Resolution and the frequency on the video part of your computer. Compare these values with the data in the Preset Timing Table.
-
Page 28: Specifications
7. Specifications 17"viewable, Diagonal, Pixel pitch 0.264mm, A-Si TFT 337.92(H) x 270.336(V) mm Display area Number of color 16.7 million colors Input signals R.G.B Analog, 15 pin D-sub / Digital TMDS(DVI-D) Frequency rate Horizontal : 31.0 to 80.0KHz, Vertical : 56 to 76Hz Maximum bandwidth 135 MHz Maximum resolution...
