Master Operating Instructions
secuENTRY
ENTRY 7711 Keypad PIN
BURG-WÄCHTER KG
Altenhofer Weg 15
58300 Wetter
Germany
www.burg.biz
Contents index
en
English
en
Further languages at:
www.burg.biz
Foreword
Dear Customer,
Thank you very much for deciding on the ENTRY 7711 Keypad PIN.
The system was developed in Germany according to the most
modern technical capabilities and fulfils the latest high safety
requirements.
Using the ENTRY 7711 Keypad PIN, you can unlock and lock the
door with a 6-digit user code
fitted to house and interior doors. The keypad can be installed
up to approx. four metres from the locking unit, depending on
preference and conditions.
The ENTRY 7711 Keypad PIN is setup and operated using the
free smartphone app secuENTRY KeyApp
wireless, the keypad uses the modern Bluetooth 5.2 standard.
We hope you enjoy your new keypad!
!
Please note:
As this keypad is an optional accessory for a secuENTRY
profile cylinder, it is recommended to install the cylinder
first. You will find the relevant instructions included in
the profile cylinder set. These instructions assume that
a secuENTRY cylinder has already been installed and do
not cover the installation steps.
!
Important:
Please read the entire operating instructions before you
start the installation.
*
The keypad can only be used together with a secuENTRY profile cylinder
(available separately). The BURG-WÄCHTER KeyApp is required for the setup.
2
. The ENTRY 7711 Keypad PIN can be
*
*
. The transmission is
Advertisement
Related Manuals for Burg Wächter secuENTRY Entry 7711
Summary of Contents for Burg Wächter secuENTRY Entry 7711
- Page 1 Contents index English Further languages at: Master Operating Instructions www.burg.biz secuENTRY ENTRY 7711 Keypad PIN Foreword Dear Customer, Thank you very much for deciding on the ENTRY 7711 Keypad PIN. The system was developed in Germany according to the most modern technical capabilities and fulfils the latest high safety requirements.
- Page 2 Set contents ENTRY 7711 Keypad PIN The ENTRY 7711 Keypad PIN can be used to operate electronic secuENTRY cylinders from ENTRY 7711 Keypad PIN BURG-WÄCHTER. Communication between the keypad and the profile cylinder is 128-bit AES Screwdriver Tx8 encrypted. Dowels (3x) Operation on the illuminated keypad is carried out via push-buttons.
- Page 3 A prompt will appear asking you to ENTRY 7711 Keypad PIN commissioning scan the QR code provided using your smartphone camera. The QR code is on To setup the ENTRY 7711 Keypad PIN, secuENTRY the sticker enclosed in the packaging you must first download the secuENTRY KeyApp (see small fig.).
- Page 4 This takes you to the menu illustrated Connecting ENTRY 7711 Keypad PIN and secuENTRY profile cylinder (Fig. 21). Briefly lay the smartphone aside and set the keypad to program- Once you have successfully registered ming mode using the following steps. the ENTRY 7711 Keypad PIN in the First, remove the battery protection KeyApp, you can start connecting strip from the keypad (Fig. 22).
- Page 5 Opening the secuENTRY cylinder using the keypad ENTRY 7711 Keypad PIN installation Activate the keypad by pressing either The installation of the ENTRY 7711 Keypad PIN is explained below. the ON key or the CLOSE key (I) (Fig. 28). There are two options to choose from for installation. The ENTRY 7711 Keypad PIN wall bracket Provided that the connected can either be screwed or adhered directly to the wall.
- Page 6 ENTRY 7711 Keypad PIN installation - screw mounting ENTRY 7711 Keypad PIN installation - adhesive mounting Drill three holes according to the Clean the surface to which the keypad dimensions shown in the illustration. is to be attached (Fig. 39). Use a 6 mm diameter drill bit (Fig. 34). Insert the dowels supplied into the holes and screw in the screws provided (Fig. 35).
- Page 7 Battery status display and replacing the batteries Compatibility with other secuENTRY products Whether for one front door, several doors or a complete locking system: Simply configure your The system monitors the keypad and individual unit with the secuENTRY modular system . cylinder battery voltage.
-
Page 8: Warranty
secuENTRY Add-on Article number: Warranty 4003482571804 ENTRY Home 7071 RELAY In order to deliver a flawless and high quality product to you and to better assist you in case of Further info available on our website: service or repair, it is necessary that faulty or defective devices along with the valid administrator Fig. 53 www.burg.biz code and the QR code(s) be presented to your dealer together with the original documentation. - Page 9 secuENTRY ENTRY 7711 Keypad PIN BURG-WÄCHTER KG Altenhofer Weg 15 58300 Wetter Germany www.burg.biz www.burg.biz...
