PowerDsine Ltd. reserves the right to make changes to products and to their specifications as described in this document, at any time, without prior notice. No rights to any PowerDsine Ltd.
Page 4
...17 ROWSING 3.5.1 L ...17 OCAL URFING 3.5.2 R LAN W EMOTE ANAGEMENT TFTP S ERVER ONFIGURATION MANAGING WITH POWERDSINE POWERVIEW ...21 GUI D ...21 ESCRIPTION 4.1.1 O ...21 VERVIEW ...21 OGGING IN 4.2.1 L ...21 OGGING IN ...23 PENING...
Page 6
SNMP P ...51 ROTOCOL SNMP UTLINE OF THE PROTOCOL 7.3.1 M ANAGEMENT NFORMATION 7.3.2 S ...52 ECURITY 7.3.3 SNMP A ...52 GENT 7.3.4 T ...52 RAPS 7.3.5 O ...52 PERATIONS Power over LAN Solutions ...51 (MIB)...52 Catalog Number: 06-6910-056 SNMP...
About this Guide 1.1 Objectives This User Guide introduces PowerDsine PowerView (hereafter referred to as PowerView for short), a Web tool for managing PowerDsine’s Power over (PoL) product line of Midspan devices, including: ! ! ! ! PD- 6024 – 24 ports...
Notes 1.5 Related Documentation For additional information, refer to the following documentation: ! ! ! ! Power over LAN PowerDsine PD-60XX (AC and DC version), User Manual (Y1-6800-001). ! ! ! ! IEEE Standard 802.3af, DTE Power via MDI. Power over LAN Solutions DEFINITION Keywords &...
Runs on a PC platform with Windows graphic user interface (GUI). ! ! ! ! 2.3 System Capabilities PowerDsine PowerView can be installed on any PC on the Local Area Network, providing remote management capabilities of Power over LAN devices connected to the LAN.
Parameters at port level include: maximum per port power, port priority level, port status and type of powered device connected. 2.4 Security Security is implemented in PowerDsine PowerView on three levels: SNMP security - handles the entire SNMP communication process by the community field.
SNMP Security Community strings provide a basic form of access control in SNMP v2 (PowerDsine PowerView is based on SNMP v2). Whenever a community string is defined, it must be provided along with any basic SNMP query, if the requested operation is to be permitted by the device. Community strings usually allow read-only or read-write access to the entire device.
3.2 Software Installation 3.2.1 CD Contents PowerDsine PowerView is delivered with a CD that includes a number of programs: SnmpLocalClient folder – files used to surf the PoL unit locally. ! ! ! ! ! ! ! ! javaws-1_0_1_XX-win-int-rt.exe –...
* Do not change the names of the libraries. The program will not function. Warning! * Copy the libraries as folders and not as individual files. The PowerDsine pack n.n provides a software pack for the PoL Step 2 Midspan operating system and for the GUI.
Web Manager User Guide Figure 3-2: HyperTerminal Registration Enter your name or organization name in the Name text field of Step 2 Figure 3-1. Then, click on the OK button. In the Connect To window, select on the Connect using drop- Step 3 down menu, the communication port to be connected to the PoL unit.
3.4.1 Installation using the DHCP Server PowerDsine PowerView unit default configuration is DHCP-enabled client when logging on to the network. When starting up, the PowerView unit configuration is that entered the last time. $ Perform the next 5 steps: Connect the PoL unit to AC power and connect the null-modem...
Web Manager User Guide 3.4.2 Network Interface Parameters The next steps configure the network parameters (on a manual basis), such as assigning an IP address to the PoL Midspan. 1. In case that you enter wrong parameter in one of the following steps, Notes choose (M)odify (press Enter for default), in the following option: “(M)odify any of this or (C)ontinue? [M]”...
Page 18
Figure 3-6: Network Parameters Screen Press any key within five seconds. Step 3: For each of the following questions press Enter to obtain the Step 4: default shown in brackets [ ] or you can type a new value: “Do you want to obtain LAN IP address from DHCP? [Y]”...
1. Local – from the Management Station 2. Remote – from PowerDsine’s Web site, located in the USA. The user may select to perform the steps of either paragraph 3.5.1 or 3.5.2, but not both.
At this time, the null-modem cable between the computer and the Step 1 PoL unit, may be disconnected. Connect the RJ-45 Ethernet cable between the PoL unit and an Step 2 entreprise network, having Internet access (see Figure 3-5). Open your Internet browser, then go to link: http:// [IP number],...
Set-up a computer to act as a server. Make certain that this Step 1 computer is accessible by all PoL Midspan users. If you have not done so, copy the PowerDsine pack n.n to the c:\ Step 2 drive (only) of the computer acting as a server.
Figure 3-11: Opening the TFTP Window In the base directory, shown in Figure 3-12, click on the Browse Step 5 button and select the PowerDsine pack n.n that you copied to your C drive. Click Ok when done. Step 6...
GUI, the installation process, described in Section 3, must have been performed in its entirety. 4.2 Logging in PowerDsine PowerView manages a single unit at a time. More than one unit can be managed using standard management platforms, such as: HP Openview, SNMPc and similar platforms.
Address: the IP address of the SNMP agent of the specific management Note card controlling the PoL unit. User Type: the function performed by the managing user, selecting one of three options offered by the system. Password: alphanumeric string, minimum three characters to be entered by the user, shown on the screen as asterisks (***).
Menu bar - provides for selection of major tasks: System – used for program related functions, such as program updates, refreshing data from the device and exiting the PowerDsine PowerView program. Device – all items under this task, are related to the device shown in the display window.
Command Log – displays all network events. Selected Device – shows a visual representation of the device targeted in the map area. The display is active as it identifies port status and operational parameters. Other tabs come up during operation. These tabs can remain on the screen or can be removed, by exiting the related panel.
Power over LAN Midspan is receiving AC or DC power. The “AC” and “DC” indicators are lit in orange to indicate an internal fault. Refer to Table 4-1 for additional information. Version 2.1 4. Managing with PowerDsine PowerView March 2003...
Page 28
Due to the standard detection process performed on each PoL port, power Note will not be supplied to an Ethernet device, that is not PoL-enabled (indicated in orange or off). In this way, Ethernet devices (not PoL-enabled) will not be affected by this connection. Table 4-1: Main Power Status Indications...
! ! ! ! It is possible to revert to previous data, when displayed in red, by clicking on the Refresh button. Version 2.1 4. Managing with PowerDsine PowerView Port Voltage Power to the port is disconnected.No DC voltage present on spare pairs.
Figure 4-6: Properties Panel 4.5.2 Definitions Label: name of the SNMP device (maximum string length is 15 characters) IP Address: IP address of the SNMP device Agent Software Version: software version of agent GUI Software Version: software version of GUI Description: user-definable text (maximum string length is 50 characters) Poll Interval: time parameter, defines the time (in seconds) between consecutive polling actions done by the network manager.
A line per each device will be available in the properties table, to enable downloading different software files to each device (maximum string length is 10 characters). 4.5.3 Commands Refresh: reverts to previous data, marked in red. Set: saves the new data entered. Version 2.1 4. Managing with PowerDsine PowerView March 2003...
Figure 4-7 displays a number of traps recorded by the application program. The individual trap listings compose a file started the moment PowerDsine PowerView initates the connection between the PoL unit agent and the SNMP manager. File content is limited to 5000 messages.
- indicates PSE threshold usage indication is on and that consumed power is above the threshold. pethMainPowerUsageOffTrap - indicates PSE threshold usage indication off and that consumed power is below the threshold.. Version 2.1 4. Managing with PowerDsine PowerView March 2003...
4.6.4.3 Private PoL traps polDeviceDownloadStartTrap - indicates that a download was started for the device. PolDeviceDownloadCompleteTrap - indicates that a download was completed for the device. polDeviceDownloadFaildTrap - indicates a download failure for the device. polDeviceGeneralTrap - indicates a general message from the device. polWWWDownloadStartTrap - indicates a download start from the WWW site.
When clicking on this entry, a query dialog box is opened, to ascertain that the reset is really required. Communication traps are generated for the boot. Version 2.1 4. Managing with PowerDsine PowerView Figure 4-8: System Menu March 2003...
Page 36
Device_sw Update (for administrator only): starts the software download process for the Power over LAN Midspan. When clicking on this entry, a query dialog box is opened, to ascertain that the download is really required. Communication traps are generated for the start and stop of the download. For details on the Device software download process and methodology, refer to section 6, Software Upgrading, on page 49.
Page 37
Device Hardware Version : number identifying the device hardware version. Part Number : product part number, according to the device type. PD Detection Method : IEEE (resistor), or both IEEE (resistor) and PowerDsine (capacitor). Clicking on this field creates a drop-down menu (see Figure 4-10).
Page 38
Figure 4-11: Power Parameters Panel Power Backup Present: status of the DC backup connection. There are 3 possibilities: On (backup is connected, within range) Fault (backup is connected, not in range) Off (backup is not connected). Backup Activated: shows whether the device is using the backup source. Two states available: Activated, Not activated.
Click on the desired statement (true to obtain a graphical Step 3 representation). The appropriate graphs appear (see Figure 4-13). Figure 4-13: Graphical Representation of Power Parameters Version 2.1 4. Managing with PowerDsine PowerView Figure 4-12: Graph Request March 2003...
Port Menu 4.9.1 About the Port Menu The Port menu (shown in Figure 4-14) allows the user to control individual ports, monitor their status, and set-up parameters. Specifically, via this menu, the user can: ! ! ! ! Activate/shut-down individual ports. ! ! ! ! Allocate power per port ! ! ! !
Guidelines provided in paragraph 4.9.2, above (to edit a field). If the value selected is not within the limits, an error message will appear on the screen and the new entry will not be accepted. Version 2.1 4. Managing with PowerDsine PowerView blue. March 2003...
Page 42
Figure 4-15: Activate/Shut-down Panel 4.9.3.2 Maximum Power This panel (see Figure 4-16) gives the user the capability to define the maximum allowed power, per port: Default: 18 W Minimum: 1 W Maximum: 18 W 4.9.3.3 Priority This table enables to assign priorities to the ports in case the Midspan device is operating with a limited source of power.
Page 43
When opening this table, a special 5-second refresh is activated, unrelated to the general polling parameters. The PowerDsine PowerView application continuously polls each port of the Midspan device. The results are displayed as either a status or as a fault error indication (see Figure 4-17).
Page 44
! ! ! ! Fault error descriptions: VoltTooHigh (port output is above permissible voltage) VoltTooLow (port output is below acceptable voltage) portNotActive hardwareError (unit internal fault) overLoadAndUnderLoad (PD goes to over, then under voltage and is disabled) underLoad (PD was disconnected) overload (PD consumption is over the limit) hardwareCommandError (internal port fault) voltFeed (PD presents over 30 V output to unit;...
Page 45
! ! ! ! Wireless Access Point ! ! ! ! Network Camera ! ! ! ! IP Phone ! ! ! ! Others. Figure 4-18: Powered Devices Connected to the Midspan Version 2.1 4. Managing with PowerDsine PowerView March 2003...
Page 46
4.9.3.7 Power Consumption This panel lists the actual power (in mW) being supplied to each port (see Figure 4-19). Figure 4-19: Actual Power Delivered per Port 4.9.3.8 Port Description In this panel, the operator can enter free text, such as: terminal location, name of user, his telephone, etc…...
CLI Commands 5.1 Built in Capabilities Using PowerDsine PowerView, it is possible to configure the unit via RS-232 or via Telnet protocol. The CLI commands are used to allocate authorizations and set up communication parameters. The commands can be activated by...
Figure 5-1: Initiating Telnet The default Password is: Admin. 5.2.3 PowerDsine PowerView Special Commands There are five basic commands which have been created especially for PowerDsine PowerView. These are: ! ! ! ! user ! ! ! ! ipaccess ! ! ! !
Page 49
Web Manager User Guide command – this command is used to include additional users to the permitted list: Telnet> user set [name] [+++++] [+++++] where: +++++ followed by the same password for verification. The default password for the admin user is admin. Delete command –...
Page 50
Delete command – removes an IP address from the permitted list: Telnet> ipaccess delete IP 172.16.4.21 – use with care Clear command access list: Telnet> ipaccess clear Unauthorized command – provides IP addresses which are trying to access the SNMP agent and are not in the permitted list: Telnet>...
Web Manager User Guide Software Upgrading 6.1 Architecture There are three types of software associated with the Power over LAN (PoL) Midspan): 1. PoL device software - embedded into the PoL Midspan‘s motherboard operates the PoL functionalities. 2. Management software - installed in the SNMP daughter board (agent). This is the management software.
6.2 Upgrade Possibilities There are several ways to download the three types of software mentionned above, depending on the software. 6.2.1 PoL Midspan Software This is the functionality software for the Midspan device. It is downloaded by surfing to the unit and accessing the Device menu on the GUI (Device_sw Update).
The Simple Network Management Protocol (SNMP) is a standard that allows management data on different network devices to be read and monitored, as well as controlled by an application. PowerDsine PowerView monitors and controls SNMP objects on any device implementing an SNMP agent.
7.3.1 Management Information Base (MIB) The MIB contains the essential objects which compose the management data for the unit. The MIB defines the objects to be managed for a TCP/IP network and provides a format for each object. The MIB is defined as an object tree, divided into logically related groups of objects, such as: system, interfaces, ip, tcp, udp, snmp, etc…...
