Husqvarna DC 1000S Manual page 6

4
Attach Front Gate (3) to inside of the body and tighten hardware as shown.
34
35
5
Attach Corners (5) to the two front body joints and tighten hardware as shown.
5
34
6
Insert Axle (10) into Undercarriage (6) halfway as shown. Center 3-1/8" Spacer
(30) inside Swivel Clevis and align with Axle (10).
Assembly Instructions
3
35
10
SWIVEL CLEVIS
30
5
