SImx MANROSE FAN7044 Installation Instructions Manual

Inline Extraction Fan Kits - 150mm Contour
To ensure correct function and safety, please read all instructions before using the product and keep all instructions for future reference.

SPECIFICATIONS

Max.
Duct
Fan Type Fan Watts
(mm)
(W)
150 EC Axial 18
Fascia Selections
(sold separately)
Adapter Plate White
DCT4502
Compliance: AS/NZS60335-2.80:2016

DIMENSIONS

A B C
200 143 170
Note: Grille cut-out size is a nominal diameter for a circular cut-out.

TECHNICAL

Supply
220-240V AC, 50Hz Die cast aluminium

FAN TIMER SELECTION

Please use the FAN2444 fan timer model shown
Installation Instructions
enquiry@manrose.co.nz | www.manrose.co.nz
Thank you for purchasing this quality 150mm inline extraction fan kit.
When using electrical appliances, basic safety precautions should always
be followed to reduce the risk of fi re, electrical shock and personal injury.
Max.
Fan Pressure
(PA)
91
Round
Black LED White
DCT4503 DCT4506
D
185
Motor Housing Impeller & Outer Rotor
PBT plastic
Specifi cations are subject to change without notice

Description

Standard Switching
This Manrose inline extraction fan kit is designed for ventilation within a shower
cubicle. The high performance fan provides high levels of extraction and enables
additional ducting to be added to this system.
Free Air Fan Performance
Fan Power
3
(l/s) (m /hr)
105 380
LED Black White
DCT4507 DCT4504
A
Ducting
5m Flexible PVC
Do not use old model FAN2444 (with resistor) or FAN0372 fan timers
Specific
Interior Grille
(W/l/s)
0.17 Range Selection
Square
Black LED White
DCT4505 DCT4508
C
B
Order Code
FAN7044
Exterior Grille
Fixed Louvre White
LED Black
DCT4509
D
Page 1
Distributed by Simx Limited
