- Page 1 Technical Guide Glass Replacement : M – Series BK 774 Rev 01 Issue Date : 18/04/2023...
- Page 2 Please refer to the main instruction booklet, relevant to your stove, for guidance on the installation and operation of the appliance. • Arada Ltd will not be responsible for any consequential or incidental loss or injury however caused. • Please consult Health & Safety guidelines for advice on handling heavy and / or large items.
- Page 3 TECHNICAL GUIDE—Replacement Glass M-Series CONTENTS : STAGE 1: Identification Of M-Series Door Version & Door Removal STAGE 2: Specific Instructions : Cast Door STAGE 3: Specific Instructions : Steel Door STAGE 4: Specific Instructions : Glass Door BK774 Rev01 PAGE 3...
-
Page 4: Fitting Instructions
TECHNICAL GUIDE—Replacement Glass M-Series Fitting Instructions : It is recommended to remove the door assembly and to position onto a suitable protective flat surface to prevent damage to the front face of the door. STAGE 1: Identification Of M-Series Door Version & Removal Fully open the fire door. - Page 5 TECHNICAL GUIDE—Replacement Glass M-Series STAGE 2: Specific Instructions—Cast Door With the fire door removed from the appliance, carefully place the assembly onto a work bench or similar level surface, with the FRONT face down onto a soft surface, to prevent damage. Cast Iron Door Version ONLY : Glass retaining...
- Page 6 / latching operation. • If any adjustment is required for the door latching please consult BK 773 (Door catch and pin adjustment for M Series stove), available online at www.aradastoves.com. PAGE 6 BK774 Rev01...
- Page 7 TECHNICAL GUIDE—Replacement Glass M-Series STAGE 3: Specific Instructions—Steel Door With the fire door removed from the appliance, carefully place the assembly onto a work bench or similar level surface, with the FRONT face down onto a soft surface, to prevent damage. Steel Door Version ONLY : Glass retaining...
- Page 8 TECHNICAL GUIDE—Replacement Glass M-Series STAGE 3, Continued : • Re-seat a new piece of glass, ensuring the glass sits flat against the rope gasket. • Replace the 4x spacers, 4x glass retain clips and 4x M5 nuts, that were removed earlier. •...
- Page 9 TECHNICAL GUIDE—Replacement Glass M-Series STAGE 4: Specific Instructions—Glass Door With the fire door removed from the appliance, carefully place the assembly onto a work bench or similar level surface, with the REAR face down onto a soft surface, to prevent damage. Glass Door Version ONLY : Silicone seal between outer glass and metal door...
- Page 10 TECHNICAL GUIDE—Replacement Glass M-Series STAGE 4, Continued : • With the inner door metal work placed as shown on right, take the tube of RTV silicone and cut the nozzle at a 45 degree angle, so that you can produce a bead of silicone approx.
- Page 11 TECHNICAL GUIDE—Replacement Glass M-Series STAGE 4, Continued : • Carefully place the replacement glass panel, onto the adhesive NOTE: ensure the emblem is placed in the lower left hand corner (As shown on right). Emblem lower LH corner • Ensure the overhang gap is even on all four sides and apply a gentle pressure to the glass panel, to ensure a good bond with the adhesive.
- Page 12 Fully tighten screws and check the latching operation of the door catch. • If any adjustment is required for the door latching please consult BK 773 (Door catch and pin adjustment for M Series stove), available online www.aradastoves.com. Arada Ltd The Fireworks, Weycroft Avenue - Axminster - Devon, EX13 5HU, UK www.aradastoves.com...
