Timewatch FB2000 Manual

Flap barrier
Hide thumbs

Advertisement

Quick Links

Download this manual
Manual
Flap Barrier FB2000/2200

Advertisement

loading
Need help?

Need help?

Do you have a question about the FB2000 and is the answer not in the manual?

Questions and answers

Summary of Contents for Timewatch FB2000

  • Page 1 Manual Flap Barrier FB2000/2200...

  • Page 2: Table Of Contents

    Content 1.Brief introduction..2.Appearance and size········································································· 3.Product structure and working principle················································ Electric control system and accessories Operating principle of the system 4.Equipment installation······································································· 5.Device function debugging································································· Control board button description Function parameter setting Motherboard wiring instructions 6.Common failure and solution······························································ (+91)-11–41916615 sales@timewatchindia.com D-162, Okhla Phase-I, Okhla Industrial Area,...

  • Page 3: Brief Introduction

    I. equipment introduction 1.1. A brief introduction Pedestrian gate is intelligent channel management equipment after years of R&D. The device integrates mechanical, electronic, microprocessor control and various reading and writing technologies. The appearance of the equipment adopts stainless steel plate laser welding molding, beautiful and generous shape, rust-proof, durable, and external use of standard electrical interface, bar code card, ID card, IC card and other card readers can be easily integrated in the equipment, to provide civilized and orderly...
  • Page 4 3) anti-impact function, when no signal is received, the door will automatically lock or alarm; 4) infrared anti-clamping function; 5) it has the automatic reset function of timeout. After the pedestrian reads the valid card, if the pedestrian fails to pass within the specified time, the system will automatically cancel the pedestrian's permission to pass;...

  • Page 5: Product Structure And Working Principle

    Relay dry Communicati Opening RS232 contact signal on interface signal Traffic speed Application Indoor 30-40 people/min 3. Product structure and working principle 3.1. Mechanical system of pedestrian gate The mechanical system of gate is divided into two parts: frame and drive. As a carrier, the frame is equipped with a direction indicator, a reading and writing device and an infrared sensor.
  • Page 6 3.2. Electronic control system of channel gate The electronic control system consists of card reader, main control board, infrared sensor, direction indicator board, alarm, transformer, etc. Card reader (self-provided) : after reading the information on the card and judging and processing, send the application pass signal (switch signal) to the main control board.
  • Page 7 ◆ direction indicator light: displays the current status of the channel and guides pedestrians to pass through the channel in a safe and orderly manner. ◆ alarm: when the system detects pedestrians entering the passage illegally, it will send out an alarm. (+91)-11–41916615 sales@timewatchindia.com D-162, Okhla Phase-I, Okhla Industrial Area,...

  • Page 8: Operating Principle Of The System

    3.3. Operating principle of the system Name Function ◆ IC/ID card access control, fingerprint device, Entrance face recognition, QR code device, gate guard system opening signal on the control board of gate machine, remote control, button to open the door (optional) The control center of the system, which receives signals from the card reader and infrared sensor, and makes logical judgment...

  • Page 9: Equipment Installation

    and process the information read from the card and send an application signal to the main control board. ◆ the main control board receives the signal from the card reader and infrared sensor, and after comprehensive processing, sends an effective control signal to the direction indicator and the motor, so that the direction indicator sign turns into a green arrow pass sign.
  • Page 10 ◆ after finishing the foundation surface of the installation equipment, arrange the equipment well. ◆ after the hole location is determined, drill the hole and embed the anchor bolt or expansion bolt of M12. (+91)-11–41916615 D-162, Okhla Phase-I, Okhla Industrial Area, sales@timewatchindia.com +91 9609749609 www.TimeWatchindia.com...
  • Page 11 put the strong electric cable and weak electric cable ◆ through 3/4 "PVC pipe and bury them in cement to the corresponding position. ◆ open the case door, select one of the equipment as the reference (it is better to choose the middle one as the reference), D-162, Okhla Phase-I, Okhla Industrial Area, (+91)-11–41916615 sales@timewatchindia.com...
  • Page 12 align the bolt hole of the machine seat with the corresponding anchor bolt, and tighten the nut first. ◆ refer to the wiring diagram, connect the power line and control line well, and connect the system ground wire protection. ◆ After check, if the equipment status is normal, the following function debugging can be carried out! ◆...
  • Page 13 plus value" "down key - minus value", press "menu key" to return and save, and press "ok" to exit the setting option 5.2 Function parameter setting < L-1 >O  PENING TIME OF ENTRANCE AND EXIT DEFAULT SECONDS ETTING THE OPENING TIME OF SWINGING DOOR AFTER SWIPING CARD AUTHORIZATION <...
  • Page 14 < L-3 > Delay closing time Set closing time after pedestrian pass the channel (default: 0.2s ), can be set from 0-50s < L-4 > Left pass voice speaker default：1：welcome Voice speaker number code from 0 to 18 For example：0：welcome ，1：welcome back <...
  • Page 15 0：open to the left 1：open to the right < L-8 > trespassing alarm default：0：trespassing, please swipe the card 0：trespassing, please swipe the card， 1： ticking sound < L-9 > Entrance and exit memory function, continuous swipe card Set up group ticket, continuous swipe mode default：0: without memory function 0: without memory function, 1：with memory function <...
  • Page 16 Default: 15 < L-13 > voice message test After entering the voice test, the gate will automatically broadcast all the voices to make sure all the voice message are normal and convenient for users to quickly understand which voice options are included. For example: exit the voice test mode, please press the "OK"...
  • Page 17 < L-15 > Main motor type selection Select the corresponding value according to different brands of motors, the default value is 1, do not change at will. < L-16 > Main motor type selection Select the corresponding value according to different brands of motors, the default value is 1, do not change at will.
  • Page 18 manually move the pendulum door toward the left direction to the desired position, press ok to save < D-3 > right open position setting When the gate open not in desired position, You can adjust the channel position by enter the parameter setting according to the voice prompt to manually move the pendulum door toward the right direction to the desired position, press ok to save <...
  • Page 19 When a pedestrian pass the channel, and hit by the gate, it will bounce back or keep closing, default setting is 0. 0: Hit the pedestrian then bounce back then keep open1: hit the pedestrian, stop for seconds, then keep open <...
  • Page 20 strength and the greater the vibration. Value : 1-100, default is 40. < D-12 >buffer strength from gate closing ( slave) The buffer strength is adjusted, The larger the value, the faster the closing speed and the greater the vibration. The smaller the value, the slower and more stable the closing speed.
  • Page 21 obstacle, the smaller the value is , the higher sensitivity . Note: this setting only be effective when the Resistance rebound Mode is set. Value: 1-99, default is 75. < D-18 > Physical clamping current time The sensitivity setting when the gate hit pedestrian or in the face of obstacle, the smaller the value is , the higher sensitivity .
  • Page 22 < D-23 > Physical clamping reaction time This adjustment needs to contact the manufacturer's technical staff "value 1-100" default value: 0 do not change at will. < D-26 > counter strength( slave) When the swinging door is in the closed non-working state, the reverse force can be adjusted when the swinging door is forced open by the external force.
  • Page 23 Motor wiring (white, blue and green) motor name color PCB screen print white(thick) Motor phase blue(thick) green(thick) black(thin) white(thin) Motor hall blue(thin) green(thin) red(thin) D-162, Okhla Phase-I, Okhla Industrial Area, ( + ) - – New Delhi,110020...
  • Page 24 6. Common fault handling 6.1. After swipe a card or Face recognition, the gate won’t open or none react. Check the open signal wire connection was right or  loose,manually press the motherboard button or short connection to see whether it will open. If manual operation D-162, Okhla Phase-I, Okhla Industrial Area, ( + ) - –...
  • Page 25 won’t work, disconnect the power and reboot,the motor works,then need to replace the main board . 6.2.The gate keep opening and closing Adjust D-23 to 50  6.3.power off and reboot,the master gate stay open. To recheck whether the synchronization line is connected ...
  • Page 26 Cut the power supply, and reboot, see if the master and  slave motor can work normally, if not, replace the main board, if still not work, replace the motor. 6.5. Swing arm is out of sync when opening or closing the door after swiping the card Adjust D-10 and D-12, which arm is slower, increase the value 6.6.Swing arm hit the gate frame...

This manual is also suitable for:

Fb2200
