OWNERS MANUAL
IMPORTANT: READ OWNERS MANUAL CAREFULLY
86006
86017
MODEL: PANTHER 20B1
MODEL: PANTHER 20TO
FOR YOUR CONVENIENCE, RECORD THE FOLLOWING
IMPORTANT INFORMATION
MODEL:__________________________________________
SERIAL NUMBER: _________________________________
DATE PURCHASED:________________________________
PURCHASED FROM: _______________________________
VS12002-SSS
13 Feb 2019 Rev 01

Advertisement

Table of Contents
loading

Summary of Contents for SSS Siedle PANTHER 20B1

  • Page 1 OWNERS MANUAL IMPORTANT: READ OWNERS MANUAL CAREFULLY 86006 86017 MODEL: PANTHER 20B1 MODEL: PANTHER 20TO FOR YOUR CONVENIENCE, RECORD THE FOLLOWING IMPORTANT INFORMATION MODEL:__________________________________________ SERIAL NUMBER: _________________________________ DATE PURCHASED:________________________________ PURCHASED FROM: _______________________________ VS12002-SSS 13 Feb 2019 Rev 01...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS INTRODUCTION ..........................2 GUIDE PURPOSE AND CONTENTS ........................2 HOW TO KEEP THIS GUIDE ........................... 2 DECLARATION OF CONFORMITY ........................2 ACCESSORIES AND MAINTENANCE ........................2 CHANGE AND IMPROVEMENT ..........................2 SCOPE OF APPLICATION............................2 MACHINE IDENTIFICATION DATA ........................2 TRANSPORT AND UNPACKING ..........................

  • Page 3: Introduction

    INTRODUCTION CAUTION! Some general and detailed machine information is not included in this guide. Please refer to Instruction for Use Manual on supplied CD-ROM reading by Adobe ® Reader ® NOTE The numbers in brackets refer to the components shown in Machine Description chapter. GUIDE PURPOSE AND CONTENTS The purpose of this Quick Start Guide is to provide the operator with all basic information to use the machine properly.

  • Page 4: Transport And Unpacking

    TRANSPORT AND UNPACKING When the carrier delivers the machine, make sure the packaging and machine are both whole and undamaged. If any damaged, make the carrier know the damage and before accepting the goods, reserve the right in compensation of the damage. Follow the instructions on packing strictly when unpacking the machine.

  • Page 5: General Safety Instruction

    GENERAL SAFETY INSTRUCTION Specific warnings and cautions to inform about potential damages to people and machine are shown below. DANGER!  This machine must be operated by trained and authorized personnel according to guidance of the manual.  Before performing any cleaning, maintenance, repair or replacement procedure, read all the instructions carefully, ensure to turn the machine OFF and disconnect the battery connector.
  • Page 6  Do not lean liquid containers on the machine, use the relevant can holder.  To avoid damaging the floor, do not allow the brush/pad to operate while the machine is stationary.  In case of fire, use a dry powder fire extinguisher. Do not use liquid fire extinguishers. ...

  • Page 7: Machine Description

    MACHINE DESCRIPTION MACHINE STRUCTURE (as shown in Figure 1) 1. Recovery tank lid 19. Front wheels on fixed axle (A). 2. Can holder Driving wheels (B) 3. Handlebar 20. Brush/pad-holder 4. Control panel 21. Brush/pad-holder deck 5. Serial number plate/technical data 22.

  • Page 8: Control Panel

    CONTROL PANEL (as shown in Figure 2) 33. Machine backward switch (B) 49. Charging green LED 34. Safe switch 50. Security cover of charging jack 35. Ignition key (0 - I) 51. Overload protector of brush 36. Discharged battery warning light (red) 52.

  • Page 9: Technical Parameters

    NOTE When charging, if the yellow LED (48) of charger is on, it may be caused by: Battery and charger does not match, battery is not connected well, or output is short-circuited. The red LED of charger flashing may be caused by charger internal short circuit. TECHNICAL PARAMETERS Model Parameter Type...

  • Page 10: Wiring Diagram

    WIRING DIAGRAM (86006) RD-BK RD-BK BN-BK BU-BK COMPONENTS GAUGE 24V BATTERIES RED/6AWG BATTERY CHARGER RED/10AWG CONTROL PANEL BOARD RED/20AWG ELECTROMAGNETIC SWITCH 24V (BRUSH MOTOR) BLACK/6AWG RELAY 24V (VACUUM MOTOR) BLACK/10AWG LOW POWER CIRCUIT FUSE BLACK/12AWG CIRCUIT BREAKER (BRUSH MOTOR) BLACK/20AWG BRUSH RELEASE FUSE BLACK/16AWG CIRCUIT BREAKER (VACUUM MOTOR)
  • Page 11 WIRING DIAGRAM (86017) COMPONENTS GAUGE 24V BATTERIES RED/6AWG BATTERY CHARGER RED/10AWG CONTROL PANEL BOARD RED/12AWG ELECTRONIC BOARD (TRACTION SYSTEM) RED/20AWG ELECTROMAGNETIC SWITCH 24V (BRUSH MOTOR) RED/14AWG RELAY 24V (VACUUM MOTOR) BLACK/6AWG RELAY 24V (TRACTION SYSTEM) BLACK/10AWG LOW POWER CIRCUIT FUSE BLACK/12AWG CIRCUIT BREAKER (BRUSH MOTOR) BLACK/14AWG...

  • Page 12: Operating Guide

    OPERATING GUIDE WARNING! On some points of the machine there are some adhesive plates indicating: － DANGER － WARNING － CAUTION － CONSULTATION While reading this Manual, the operator must pay particular attention to the symbols shown on the plates. Do not cover these plates for any reason and immediately replace them if damaged.

  • Page 13: Battery Installation And Battery Typesetting (Wet Or Gel/ Agm)

    BATTERY INSTALLATION AND BATTERY TYPESETTING (WET OR GEL/ AGM) According to the type of batteries (WET or GEL/AGM), set the machine and electronic board of the battery charger as follows: (only for disc machine) WET BATTERIES (NOTE: Turn the DIP switch 1 and 2 both to “OFF”.

  • Page 14: According To The Type Of Batteries (Wet Or Gel / Agm) Set The Machine

    Battery charger setting (for disc machines with on-board battery charger) Remove the screws (A, B, C, D, Figure 4.1). Open the charger and find the sw1 (E, Figure 4.1). Set the switches as the table of (Figure 4.1). Install the screws (A, B, C, D, Figure 4.1) after setting complete. ACCORDING TO THE TYPE OF BATTERIES (WET OR GEL / AGM), SET THE MACHINE AS FOL- LOWS: (only for orbital machine) NOTE...

  • Page 15: Brush/Pad-Holder Installation And Uninstallation

    Battery installation 1. Open the recovery tank cover (1) and check that the recovery tank (25) is empty; otherwise empty it with the drain hose. (22) 2. Close the recovery tank cover (1). 3. Overturn the recovery tank (25) carefully. 4.

  • Page 16: Adjusting The Balance Of Squeegee

    PAD INSTALLATION AND UNINSTALLATION (only for orbital machine) Lift the deck by pressing the switch (46). Install and uninstall the pad (A, Figure 5.1) ADJUSTING THE BALANCE OF SQUEEGEE Install the squeegee and screw up the nut (H), then connect the vacuum hose (G) to the squeegee. Adjust the squeegee by squeegee adjusting handle (A, Figure 6).

  • Page 17: Adjusting The Level Of Orbitaldeck (Only For Orbital Machine)

     (only for machine with traction) by pushing the machine with the hands on the handlebar (E) and by pressing the switch (F). If necessary, the forward speed can be adjusted with the adjuster (H). NOTE D C B To move the machine forward, press either the left or right switch (F) or both.

  • Page 18: Tank Emptying

    CAUTION! To avoid any damage to the floor surface, turn off the brushes/pad-holders when the machine stops in one place. Figure 9 Battery discharge during operation C B A Until the green warning light (A, Figure 10) stays on, the batteries allow the machine to work normally.

  • Page 19: After Using The Machine

    CAUTION! If the vacuum system turns off accidentally (for example, when the float is activated because of a sudden machine movement), to resume the operation: turn off the vacuum system by pressing the switch (D, Figure 10), then open the cover (C, Figure 11) and check that the float inside the grid (A) has gone down to the water level.

  • Page 20: Machine Long Inactivity

    MACHINE LONG INACTIVITY If the machine is not going to be used for more than 30 days, proceed as follows: Perform the procedures shown in After Using the machine paragraph. Disconnect the battery connector (54). FIRST PERIOD OF USE After the first 8 hours, check the machine fastening and connecting parts for proper tightening and check the visible parts for wear and leakage.

  • Page 21: Battery Charging

    BATTERY CHARGING NOTE Charge the batteries when the yellow (F, Figure 14) or red warning light (G) turns on, or when finishing cleaning. CAUTION! Keeping the batteries charged make their life last longer. CAUTION! When the batteries are discharged, charge them as soon as possible, as that condition makes their life shorter.

  • Page 22: Brush/Pad Cleaning

    Battery charging with battery charger installed on the machine Connect the battery charger cable (A, Figure 15) to the electrical mains (G) (the electrical mains voltage and frequency must be compatible with the battery charger values shown on the machine serial number plate (F). When the battery charger is connected to the electrical mains, all machine functions are automatically cut off.

  • Page 23: Squeegee Cleaning

    SQUEEGEE CLEANING NOTE The squeegee must be clean and its blades must be in good conditions in order to get a good drying. CAUTION! It is advisable to wear protective gloves when cleaning the squeegee because there may be sharp debris. Drive the machine on a level floor.

  • Page 24: Squeegee Blade Check And Replacement

    SQUEEGEE BLADE CHECK AND REPLACEMENT Clean the steel or the aluminum squeegee, as shown in the previous paragraph. Check that the edges (E, Figure 20) of the front blade (C) and the edges (F) of the rear blade (D) lay down on the same level, along their length;...

  • Page 25: Tank And Vacuum Grid With Float Cleaning, And Cover Gasket Check

    TANK AND VACUUM GRID WITH FLOAT CLEANING, AND COVER GASKET CHECK Drive the machine on a level floor. Ensure that the machine is off and the ignition key (54) has been removed. Turn the recovery tank lid (A, Figure 21) 90 degree position where it can be took off from the tank, and then take down the float ball filter (P) from the tank.

  • Page 26: Machine Working Hour Check

    MACHINE WORKING HOUR CHECK Turn the ignition key (A, Figure 22) to "I". Press the switch (B), the hour meter (C) begins to work and it at the same time shows the total number of working hours (scrubbing/drying) performed by the machine. Release the switch (B).

  • Page 27: Accessories/Options

    ACCESSORIES/OPTIONS In addition to the standard components, the machine can be equipped with the following accessories/options, according to the machine specific use: For further information concerning the above-mentioned optional accessories, contact an authorized Retailer. ACCESSORIES/OPTIONS See “Parts List” section GEL/AGM batteries Pads of different materials TROUBLESHOOTING Trouble...
  • Page 28 PARTS LIST TABLE OF CONTENTS GENERAL VIEW…………………………………………………………………….……………………………………………28 SOLUTION TANK ASSEMBLY………………………………………………..…………………………………………………30 RECOVERY TANK ASSEMBLY………………………………………….………………………………………………………32 CONTROL SYSTEM AND ELECTRICAL SYSTEM………….……………….……………………………………………34 CHASSIS ASSEMBLY (86006) ……………………………………………………..………………….………………………….37 CHASSIS ASSEMBLY (86017) ………………………………………………………………………………….…………………39 WHEELS ASSEMBLY (86006)……………………….….…………………………………………………………………………41 WHEELS ASSEMBLY (86017) ……………………………………….……………………………………………………………42 SOLUTION ASSEMBLY…………………………………………………………….…………………………………………………43 BRUSH ASSEMBLY……………………………………………….……………………………………………………………………45 ORBITAL HEAD ASSEMBLY…………………………………………………………………………………………………………47 SQUEEGEE ASSEMBLY………………………………….………………….………………………………………………………49 WEAR AND TEAR PARTS……….……………………….…………………………………………………………………………51 WHEN ORDERING PARTS...

  • Page 29: General View

    PARTS LIST GENERAL VIEW...
  • Page 30 PARTS LIST GENERAL VIEW Item Description SAFETY SWITCH ASSEMBLY WITHOUT TRACTION SAFETY SWITCH ASSEMBLY WITH TRACTION CONTROL PANEL ASSEMBLY SOLUTION TANK ASSEMBLY CONTROL BOX ASSEMBLY CHASSIS ASSEMBLY (86006) CHASSIS ASSEMBLY (86017) SQUEEGEE HOLDER ASSEMBLY 20 INCH SQUEEGEE ASSEMBLY WHEEL ASSEMBLY WITHOUT TRACTION WHEEL ASSEMBLY WITH TRACTION RECOVERY TANK LID ASSEMBLY RECOVERY TANK ASSEMBLY...

  • Page 31: Solution Tank Assembly

    PARTS LIST SOLUTION TANK ASSEMBLY...
  • Page 32 PARTS LIST SOLUTION TANK ASSEMBLY Item Part No. Description VS10603 DRAIN HOSE GASKET VS10101 SUCTION CONNECTER FRAME KIT VS10601 SUCTION HOSE BATTERY 105/130 Wet, 105/140 AGM (Ah) C20 VF90533 BATTERY SPACER PANEL VS10329 TRAY BATTERY VS10165 FILTER COVER KIT VF90265 SEAL PLATE KIT VS10103 HINGE KIT...

  • Page 33: Recovery Tank Assembly

    PARTS LIST RECOVERY TANK ASSEMBLY...
  • Page 34 PARTS LIST RECOVERY TANK ASSEMBLY Item Part No. Description VS10110 ELBOW ADAPTOR KIT VF90534 FLOAT KIT VF90011-SSS LOGO LABEL VS10302 RECOVERY TANK VS12314 RECOVERY TANK ORBITAL VS10111 RUBBER GASKET KIT VF90520 VACUUM MOTOR VS10112 GASKET VACUUM MOTOR KIT VS10113 VACUUM MOTOR COVER KIT VS10351 RECOVERY TANK LID VF90504...

  • Page 35: Control System And Electrical System

    PARTS LIST CONTROL SYSTEM AND ELECTRICAL SYSTEM...
  • Page 36 PARTS LIST Revised 12/2018 CONTROL SYSTEM AND ELECTRICAL SYSTEM Item Part No. Description VS10117 PCB BOX KIT VS10250 CONTROL PANEL BOARD DISC VS12202 CONTROL PANEL BOARD ORBITAL VS10118 CONTROL PANEL WITHOUT TRACTION DISC VS12101 CONTROL PANEL WITH TRACTION ORBITAL 9100001354 KEY SWITCH VS10120 ADJUST SPEED KNOB KIT...
  • Page 37 PARTS LIST CONTROL SYSTEM AND ELECTRICAL SYSTEM VS13260 CHARGER 24V 13A US VS10125 CHARGER FIX BRACKET KIT VF90280 CABLE SUPPORT KIT VF90277 HANDLE LIFT KIT VF90276 HAND BRACKET KIT VS10126 CHARGER SOKET KIT VS10502 CABLE SQUEEGEE LIFT VF89724 BATTERY CHARGING CABLE US VS10212 HARNESS BRUSH MOTER DISC VS10270...

  • Page 38: Chassis Assembly (86006)

    PARTS LIST CHASSIS ASSEMBLY (86006)
  • Page 39 PARTS LIST CHASSIS ASSEMBLY (86006) Item Part No. Description VS10138 FRONT PEDAL BRUSH LIFTING KIT VS10134 SCREW KIT-1 VS10136 SCREW KIT-3 VS10139 SPRING KIT VS10140 BACK PEDAL BRUSH LIFTING KIT VS10141 PEDAL SUPPORT KIT VS10406 CHASSIS VS10142 3 INCH CASTER KIT VS10135 SCREW KIT-2 VS10137...

  • Page 40: Chassis Assembly (86017)

    PARTS LIST CHASSIS ASSEMBLY (86017)
  • Page 41 PARTS LIST CHASSIS ASSEMBLY (86017) Item Part No. Description VS13760 CONNECTING ROD WITH SCREW K2 VS10136 SCREW KIT 1 VS10135 SCREW KIT 3 VS12410 ACTUATOR HOLDER VS13762 ACTUATOR KIT VS13763 SPRING HOLDER KIT VS13702 WIRE CLASPS KIT VS13757 3 INCH CASTER KIT VS13431 CHASSIS VS13761...

  • Page 42: Wheels Assembly (86006)

    PARTS LIST WHEEL ASSEMBLY (86006) WHEELS ASSEMBLY Item Part No. Description VS10143 8 INCH WHEEL WITHOUT TRACTION KIT VS10144 WHEEL SHAFT FIXED PLATE KIT VS10330 WHEEL-COVER VS10145 SPRING KIT VF14075 BEARING 6004RS...

  • Page 43: Wheels Assembly (86017)

    PARTS LIST WHEEL ASSEMBLY (86017) WHEELS ASSEMBLY Item Part No. Description VS10330 WHEEL-COVER VS13756 8 INCH WHEEL TRACTION KIT VS10147 TRACTION MOUNT KIT VS11704 250W MOTOR TRACTION VS11703 CARBON BRUSH KIT VS11707 CARBON CAP...

  • Page 44: Solution Assembly

    PARTS LIST SOLUTION ASSEMBLY...
  • Page 45 PARTS LIST SOLUTION ASSEMBLY Item Part No. Description VF90621 FILTER KIT VS10148 SCREW AND CLAMP KIT VF90282 SOLENOID VALVE VS10149 TUBE KIT VS13793 STEEL TUBE KIT 750mm A ：ONLY FOR DISC MACHINE (86006) B ：ONLY FOR ORBITAL MACHINE (86017)

  • Page 46: Brush Assembly

    PARTS LIST BRUSH ASSEMBLY (86006)
  • Page 47 PARTS LIST BRUSH ASSEMBLY (86006) Item Part No. Description VS10702 BRUSH MOTOR KIT VS10132 SHORT CONNECTION PLATE KIT VS10128 MOTOR FIXING PLATE KIT VS10337 ELBOW VS10129 BRUSH DECK KIT VS10130 PLATE DRIVE KIT VF90417 20 INCH BRUSH VF90471 20 INCH BRUSH Փ0.9mm VF90416 20 INCH PAD VF90454...

  • Page 48: Orbital Head Assembly

    PARTS LIST ORBITAL HEAD ASSEMBLY(86017)
  • Page 49 PARTS LIST ORBITAL HEAD ASSEMBLY(86017) Item Part No. Description VF91041 CARBON BRUSH KIT VS10706 ORBITAL MOTOR 750W VS13766 SUPPORT LOWER ISOLATOR SCREW KIT VS12106 WEIGHT BLOCK KIT VS13772 INLET PIPE KIT VS13771 OUTLET PIPE KIT 56382990 ISOLATOR-1.25 30 DURO 1/4-20 VS13510 FLEX PLATE ASSY 20INCH 997020...

  • Page 50: Squeegee Assembly

    PARTS LIST SQUEEGEE ASSEMBLY...
  • Page 51 PARTS LIST SQUEEGEE ASSEMBLY Item Part No. Description VS10401 FRONT-SQUEEGEE-SUPPORT VF82172 SPRING 70° VS13711 HARDWARE SQUEEGEE SUPPORT KIT HAND WHEEL KIT VF90141 VF90110 BACK-SQUEEGEE-SUPPORT VF81210 KNOB VF90109 SQUEEGEE-SUPPORT VF90135 20 INCH SQUEEGEE KIT VF90137 BUMPER ROLLER KIT VF90136 SQUEEGEE ROLL WHEEL KIT VF90118 20 INCH STRAP，SQUEEGEE FRONT VF90124...

  • Page 52: Wear And Tear Parts

    PARTS LIST WEAR AND TEAR PARTS Item Part No. Description VS10603 DRAIN HOSE GASKET VS10601 SUCTION HOSE VS10165 FILTER COVER KIT VS10202 WATER-PROOF SWITCH VS10109 WATER LEVEL PIPE KIT VF90536 OUTLET COVER KIT VS10110 ELBOW ADAPTOR KIT VF90534 FLOAT KIT VF90520 VACUUM MOTOR VF90504...
  • Page 53 PARTS LIST WEAR AND TEAR PARTS VF90282 SOLENOID VALVE VS10702 BRUSH MOTOR KIT VS10706 ORBITAL MOTOR 750W VS10337 ELBOW VF90417 20 INCH BRUSH VF90471 20 INCH BRUSH Փ0.9mm VF90454 20 INCH PAD WITH RETAINER VS10133 BUMPER ROLLER KIT HAND WHEEL KIT VF90141 VF81210 KNOB...

This manual is also suitable for:
