Havit TW925 User Manual

AJ
Product and accessories:
Earbuds *2
charging case *1
2 pairs of ear caps
(L/S size, M pre-installed)
Specification
Bluetooth Version：V5.1
Earbud Battery: 40mAh*2
Charging case battery: 200mAh
Charging case dimension:
55*35*20mm
Basic function
01 Power on and Bluetooth connection
1. Power on
Method 1: Remove earbuds from the charging case.
Method 2: If the earbuds are power off outside the case, touch and hold MFB button for 3 sec. on both sides to turn them on.
Turn on both earbuds, the earbuds indicators flash white, when the right earbud indicator flashes white and orange, the left
earbud indicator is turned off, the product is ready for use.
2. Turn on Bluetooth on your device and select "HAVIT TW925 " referring to your phone instructions.
3. Pairing mode can last up to 180 seconds if you miss the pairing time, you need to restart the device and operate follow the
procedural steps mentioned above.
*Note:
a). HAVIT TW925 remembers previously connected devices. When turned on, earbuds attempts to reconnect to previously
connected devices.
b). HAVIT TW925 will lose the connection when deviate the working range of Bluetooth. The earbuds will reconnect
automatically if you come back to the range in 3 minutes.
02 Power off
Method 1: Put the earbuds into the charging case,
they will automatically shut off.
Method 2: Touch and hold MFB for 3 seconds, the white
light flashes three times, and the earbuds are turned off.
03 Answering incoming calls
Short press left or right MFB to answer incoming calls.
04 End the call
Short press the left or right MFB to end the current call.
05 Decline incoming calls
Touch and hold the left or right MFB for 2 seconds to reject a
call.
06 One key for voice assistant
Double tap either the left or right MFB to activate voice
assistant.
USER MANUAL / UŽIVATELSKÝ MANUÁL
True wireless stereo earbuds TW925
TWS STEREO BEZDRÁTOVÁ SLUCHÁTKA TW925
Charging cable *1
User manual *1
Description of product structure:
1. MFB (Touch panel)
2. Indicator light
Earbud dimensions: 20*15*12mm*2
Net weight: 4.0g*2(Earbuds)
/20g(Charging case)
Wireless working range: 10M (without
obstacles )
Speaker: 8MM*2
3. MIC
4. Power LED indicator
5. Charging port
Speaker frequency: 20～20KHz
Input voltage / current: DC 5V/1A
Play time: 4-5H (60% volume)
Talk time: 3H/ Standby time: 100H
Charging time: About 2H
07 Music playing
1. Play/Pause: tap the left or right MFB once;
2. Long press the left MFB for 2s to switch to the previous
song
3. Long press the right MFB for 2s to switch to the next song
08 Mono mode (take out any earbuds as
a unilateral bluetooth earbud)
(note: single channel mode only needs to remove one of
earbuds from the charging case; If two earbuds are
removed before connection, the earbud will be used
in bilateral channel mode by default.)
1. Take out an earbud from charging case,the earbud
automatically turn on and reconnect to previously
connected devices.
2. Switch from one earbud to the other when playing music,
