Summary of Contents for ProtoArc RGB C1
- Page 1 RGB C1 User Manual HDMI 2.1 audio and video transmission 8K 60HZ HD RGB light-emitting cable...
- Page 2 Working Connection Method RECEIVE SEND After inserting the male connector 1 SEND of HDMI cable into female interface of the output device, and the HDMI cable will emit light. Plug the male connector 2 RECEIVE of HDMI cable into the display device again to complete the audio and video expansion display.
- Page 3 What’s In Package HDMI 2.1 Cable*1 User Manual*1 Product Specifications HDMI Cable Length: 6.56 feet Material: PVC transparent black line coating+HDMI zinc alloy terminal+HDMI copper joint HDMI cable LED CAT luminous intensity: 150~600mcd HDMI cable version: HDMI 2.1 protocol standard. It supports 48 Gbps transmission speed total bandwidth, Quick Frame Transport (QFT).
- Page 4 Problem Description Possible Causes Troubleshooting Method 1. Please check the signal source port and signal channel mode of the input device. This product supports a variety of HDMI device connections, 8k 60HZ HD resolution display. No HDMI signal 2. When using, please make sure to source input connect the ports correctly, and select the right signal source.
- Page 5 Problem Description Possible Causes Troubleshooting Method 1. Detect whether the video source of the input device is caused by network Input device issues lag; 2. Check whether the input port is loose. The product adopts thicker tinned copper wire core for conduction, plus The transmission aluminum foil braided shielding Poor contact...
