Contents Your dishwasher ........................Safety instructions ........................Installation ..........................Overflow guard function ......................Winter storage/transport ......................Packaging ..........................Disposal ............................ Before washing for the first time ................... Water hardness ......................... Basic settings ........................... Top up with rinse aid ........................ Top up with salt ........................Greener dishwashing ......................
Page 3
Installation ..........................Safety instructions ........................Setup ............................Drainage connection ......................... Connection to water supply ...................... Electrical connection ......................... Service ............................. Technical data and energy labelling ..................Technical data ........................... Information for consumers ......................Information for test institute ......................
Your dishwasher Install the dishwasher, see the chapter Installation. Then open the door and press The first time the dishwasher is switched on, it is important that you choose the right settings to ensure good dishwashing results. See the chapter Before washing for the first time. On/Off Start/Stop Select program...
Safety instructions Read the operating instructions and keep them in a safe place! Number of standard place settings: 13 Never use the dishwasher for any purpose other than that specified in these operating instructions. Do not load the dishwasher door or dishwasher baskets with anything other than dishes.
WARNING! Knives and other pointed items must be placed with the points down in the cutlery basket or horizontally in other baskets. WARNING! Children must be supervised – dishwasher detergent is corrosive! Installation See the chapter Installation. Overflow guard function The overflow guard starts pumping out the machine and turns off the water supply if the water level in the dishwasher exceeds the normal level.
Before washing for the first time Water hardness In order to achieve good dishwashing results, the dishwasher needs soft water (water with low mineral content). Hard water leaves a white coating on dishes and the dishwasher. Checking water hardness Water hardness is specified using German degrees of water hardness (°dH), French degrees of water hardness (°fH), English degrees of water hardness (°eH) or millimoles per litre (mmol/l).
Basic settings The first time the dishwasher is switched on, it is important that you choose the right settings to ensure good dishwashing results. See the chapter Settings. Set up: Rinse aid Water hardness Top up with rinse aid Drying is faster and a better result is achieved if you use rinse aid. You will also achieve a better dishwashing result with clear and spotless dishes.
Greener dishwashing Save energy and water When using a dishwasher in a residential setting, less energy and water are generally used compared to washing the dishes by hand. Do not rinse under running water Do not rinse the dishes under running water as this will lead to increased energy and water consumption. Simply scrape off large food particles before loading the dishwasher.
Loading the dishwasher Fragile dishes Some cookware is not dishwasher safe. This can be for several reasons. Some materials cannot withstand high heat, others can be damaged by dishwasher detergent. Exercise caution with, for example, handmade items, fragile decoration, crystal/glassware, silver, copper, tin, aluminium, wood and plastic.
3 positions Knife stand Raising and lowering the upper basket 1. Pull out the upper basket. 2. Grab the sides of the upper basket with both hands and lift it up. 3. If the upper basket is raised while in the top position, it will drop to the bottom position. Note that both sides of the basket must always be set to the same height.
Adjustable plate supports The adjustable plate supports can be folded down to make it easier to load pots and bowls. Cutlery basket Place cutlery with the handles facing down, except for knives, and spread them out as much as possible. Ensure that spoons do not stack inside each other. Place the cutlery basket in the lower basket.
Using the dishwasher Add detergent Follow the instructions on the detergent packaging. This dishwasher is fitted with a water softener, so use detergent and rinse aid doses suitable for soft water. Too much detergent can result in less effective dishwashing and also entails greater environmental impact.
On/Off Start/Stop Select program Display NOTE! The control panel only reacts to use when the door is open. On/Off Open the door and press . Also turn on the water tap if it is turned off. Select program Select a program to suit the type of dishes and how dirty they are. Eco 55° is always pre-selected. Press one or more times until the desired program is activated, which is indicated by an indicator light.
Glass 40° A gentle dishwashing program with a low temperature for washing fragile items made of crystal/glass. Remember to use a small amount of detergent and to place items so that they do not touch each other during the wash. See also Fragile dishes in the chapter Loading the dishwasher. Porcelain that has just been used without dried leftovers can also be washed using this program.
Stopping or changing a program Open the door. If you want to interrupt or change the program after starting the dishwasher, press and hold for three seconds. Top up with new detergent if the lid of the detergent dispenser has opened. Then select a new program, press and close the door.
Settings Open the door and press To open the dishwasher's settings menu, press and hold until SEt is shown on the display. to step through the menu. Open the dishwasher's settings menu Select alternative Confirm / Next setting To exit the menu, step through it or press Settings Alternatives Sounds...
Page 19
Settings Alternatives Pre-selected at factory: 00 Error readout Any error messages. When contacting the service department, you may be asked to provide the most recent error messages. Restore factory defaults Restores all settings to the factory defaults. Select rSt and press Exit To exit the dishwasher's settings menu, select End and press...
Care and cleaning Top up with rinse aid When the rinse aid needs topping up, the above symbol lights on the display. Lift up to open Press to close 1. Open the rinse aid compartment lid. 2. Carefully top up with rinse aid to the level marked MAX. 3.
Clean filter The filter traps larger food particles, which cannot get past the drainage pump. Empty the filter when necessary. It should be cleaned at regular intervals depending on how often the dishwasher is used. 1. Turn the locking ring anticlockwise and lift the filter straight up. 2.
Lower spray arm Pull the lower spray arm straight up to release it. Clean the outside of the dishwasher Door and door seal Open the door. Clean the sides of the door and the door seal regularly with a slightly damp cloth. Clean the door seal at the lower front edge of the dishwasher with a washing-up brush.
Page 23
7. Plug the machine in again. Drainage pump stop NOTE! Do not forget to refit the drainage pump stop. Unblocking the inlet hose filter If the water supply contains small particles, the outer filter on the inlet hose may become blocked, which results in the Water inlet fault error message.
Troubleshooting Error messages Action Overfilling water Clear the drainage pump. See the chapter Care and cleaning. If the problem persists, contact your nearest service centre. Water outlet fault See "Water remains in the dishwasher" under "Problem" in the table below. If the problem persists, contact your nearest service centre.
Page 25
Problem Possible causes Action Check whether the Delayed Press and hold for three start option has been selected. seconds if you want to cancel the Delayed start option. The plug is not plugged into the Check. wall socket. A fuse/circuit breaker has been Check.
Page 26
Problem Possible causes Action All stainless steel can cause In order to avoid marks and tar- spots on silver if they come into nishing, separate dishes made contact during dishwashing. from different metals, such as Aluminium can also cause spots silver, stainless steel and alu- on dishes.
Page 27
Problem Possible causes Action Debris in the drainage pump. Clean the drainage pump. See the chapter Care and cleaning. Drainage pump stop missing. Check that the yellow drainage pump stop on the right in the bottom drain is in place. See the chapter Care and cleaning.
Installation It is important that you read through and follow the instructions and directions below. Conduct installation and connection in accordance with the separate installation instructions. [mm] Remove the plastic strips if the recess dimension is 596-598 mm. Exercise caution! The edges may be sharp. Wear protective gloves! Cover door length.
If the dishwasher is built-in the surrounding furnishings must be resistant to any condensation from the dishwasher. Mount the protective film beneath the worktop and up around the edge. The function of the protective film is to protect the worktop from moisture. (The protective film is in the enclosed plastic bag.) Note that the door springs may need adjusting after a cover door has been fitted.
Page 30
The electric wall socket must be placed outside of the installation area to be easily accessible after installing the dishwasher. Do not use an extension cord!
Read the chapter Troubleshooting before contacting the service centre. If you have encountered a problem that you cannot resolve, please contact your nearest service centre for professional help, see www.gorenje.com. Our website also has information about spare part availability and what you can repair yourself.
In accordance with the EN 60436 standard. Information for consumers Information about your product can be found at www.gorenje.com, where you will also find a link to the European Product Database for Energy Labelling, EPREL. Or else visit https://eprel.ec.europa.eu directly. Follow the instructions to search by model name.
Page 33
GORENJE gospodinjski aparati, d.o.o. Partizanska 12, 3320 Velenje, Slovenia Phone: +386 (0)3 899 10 00 Fax: +386 (0)3 899 28 00 www.gorenje.com 867786-a1 We reserve the right to make changes.
