exacqVision DTA-Series Enterprise H410 Quick Start Guide

Introduction

The exacqVision DTA-Series is part of exacqVision's series of network video recorders (NVR). The DTA-Series provides high performance
hardware with an exacqVision surveillance video management software.

Installation

Before you start the exacqVision server, ensure that you adhere to the following requirements:

Electrical requirements

• Do not replace NVR batteries. There is a risk of explosion if the battery is replaced with an incorrect battery.
• Do not use this NVR in locations where children are likely to be present.
• Only a skilled person must install the socket-outlet protective earthing connection. Use a green-yellow wire minimum 18 AWG.
Figure 1: Socket-outlet protective earthing connection

Mounting and operating environment requirements

• Mount the exacqVision server in a dust-free and climate controlled location where the temperature is between 40°F to 95°F (4.5°C to 35°C),
and the humidity level is less than 80% non-condensing.
Note: Dust can cause components of the server to overheat, and elevated temperatures can contribute to premature hard drive
failures.
• If the hard drives dispatch separately to the system, insert each drive into the appropriate hard drive slot, if they are numbered.
• You can place a surge suppressor between the camera and the recorder of all outdoor cameras.
• The server must connect permanently to the ground wire. Ensure this connection is made by a skilled individual. Use an 18 AWG wire or
larger to make the connection, and label the grounding screw near the power connector with the following image.
Figure 2: Grounding wire

Electrical environment requirements

• For maximum reliability, connect the exacqVision server to an online UPS (uninterrupted power supply). An online UPS filters power surges
and dips that can damage the server.
• Connect a mouse and keyboard to the server.
• Connect the exacqVision server network interface cards (NIC) to the appropriate network switch ports.
• Ensure that only a skilled person replaces the battery.
• Use cables with a ferrite core to connect to monitors. If the cables do not have a ferrite core, the unit still performs as expected but may
not meet CE safety regulation standards.
